SPECIFICATIONS
| Item | Specification |
|---|
| Compressor oil type | Sanden SP-10 PAG oil |
| Compressor oil - vehicles fitted with 2 zone | 120 cm 3 |
| Compressor oil - vehicles fitted with 4 zone | 170 cm 3 |
| Item | Specification |
|---|
| Refrigerant type | R134A |
| Air conditioning refrigerant - vehicles fitted with 2 zone | 700 grammes (24.69 ounces) |
| Air conditioning refrigerant - vehicles fitted with 4 zone | 880 grammes (31 ounces) |
SYSTEM REFRIGERANT SPECIFICATION/CAPACITY
| Description | Nm | Lb-ft |
|---|
| Compressor mounting bolts | 25 | 18 |
| Compressor mounting bracket bolts |
| M8 bolt | 25 | 18 |
| M10 bolt | 48 | 35 |
| Accessory drive belt tensioner bolt |
| Vehicles fitted with M8 bolt | 25 | 18 |
| Vehicles fitted with M10 bolt | 48 | 35 |
| Refrigerant line to bulkhead bolts | 6 | 4 |
| Thermostatic expansion valve (TXV) to refrigerant line clamp bolts | 5 | 4 |
| Refrigerant line to compressor bolt | 22 | 16 |
| Refrigerant line to condenser | 10 | 7 |
| Refrigerant liquid line to front evaporator bolts - vehicles fitted with 4 zone | 9 | 7 |
| Refrigerant suction lines to front evaporator bolts - vehicles fitted with 4 zone | 18 | 13 |
| Refrigerant lines to rear evaporator bolts - vehicles fitted with 4 zone | 9 | 7 |
Scheme 16
Scheme 16: COMPONENT LOCATION - TdV8
| Item Number | Description |
|---|
| 1 | Condenser |
| 2 | High pressure servicing connection |
| 3 | Refrigerant pressure sensor |
| 4 | Low pressure servicing connection |
| 5 | Thermostatic expansion valve |
| 6 | Evaporator |
| 7 | Air conditioning (A/C) compressor |
| 8 | Receiver drier module |
Scheme 17
Scheme 17: COMPONENT LOCATION - 4.2L/4.4L
| Item Number | Description |
|---|
| 1 | Thermostatic expansion valve |
| 2 | Evaporator |
| 3 | Low pressure servicing connection |
| 4 | A/C compressor |
| 5 | Receiver drier module |
| 6 | Condenser |
| 7 | High pressure servicing connection |
| 8 | Refrigerant pressure sensor (reference) |
