Multifunction Electronic Modules: Component Locations Land Rover Freelander L359

Communication Devices 1 illustration

COMPONENT LOCATION - LIN BUS (SHEET 2 OF 2)

Item NumberDescription
1Flap actuator module 1
2Flap actuator module 2
3Flap actuator module 3
4Air quality sensor
5Humidity sensor
6RH seat heat module
7LH seat heat module
8Selector lever module
9Headlamp levelling control module
10Automatic Temperature Control (ATC) module
11LH headlamp control unit
12Flap actuator module 4
13Flap actuator module 5
14Transmission Control Module (TCM)
15Generator control module
16RH headlamp control unit
17Engine Control Module (ECM)

Scheme 63

Scheme 63: COMPONENT LOCATION - MEDIUM SPEED CAN BUS
Item NumberDescription
1Integrated Control Module (ICM) - Lo-Line audio system
2Integrated Control Module (ICM) - Hi-Line audio system
3ATC module
4Instrument cluster
5Parking aid module
6Trailer module
7Driver's door module
8Seat memory module
9Diagnostic socket
10CJB
11Fuel fired heater module
12Passenger door module

Note. NOTE: Left hand drive vehicle shown

COMPONENT LOCATION - HIGH SPEED CAN BUS

Item NumberDescription
1Steering angle sensor
2Terrain Response control module
3Electronic rear differential control module
4Restraints Control Module (RCM)
5Headlamp levelling control module
6CJB
7Anti-lock Brake System module
8TCM
9Engine Control Module (ECM)
10Diagnostic socket
11Occupant Classification Sensor (OCS) - NAS only

COMPONENT LOCATION - MOST

Item NumberDescription
1Integrated control Module (ICM) - Face plate
2Integrated Head Unit (IHU) - Hi-Line
3Touch Screen Display (TAD)
4Integrated Head Unit (IHU) - Hi-Line
5Bluetooth phone module
6Amplifier/tuner
7Digital Audio Broadcast (DAB) receiver
8Navigation computer
