Disassemble Land Rover Freelander L314

1. Remove inlet manifold chamber. See «30.15.37 SEALS -- INLET MANIFOLD CHAMBER -- UP TO 03MY»(ref-219267-S33433288832006021100000).
2. Remove and discard camshaft timing belt. See «CAMSHAFT TIMING BELT»(ref-158807-S16904230992005011200000).
3. Release right HO2S multiplug from coolant rail bracket and disconnect multiplug. (Scheme 209)
4. Using sequence shown, loosen then remove 4 nuts securing right exhaust manifold to cylinder head. (Scheme 210)
5. Remove exhaust manifold, remove and discard gasket.
6. Remove 4 bolts securing right front timing belt cover backplate to cylinder head and remove backplate. (Scheme 211)
7. Remove right camshaft cover gasket. See «CAMSHAFT COVER GASKET - RIGHT»(ref-158807-S13216424482005011200000).
8. Up to Model Year 2003: Remove 3 nuts and 3 bolts securing ignition coils to left inlet manifold and release coil earth lead. (Scheme 212)
9. Up to Model Year 2003: Remove ignition coils and position aside.
10. Release clip and disconnect coolant bleed hose from right inlet manifold, position hose aside. (Scheme 213)
11. Release injector harness clips from injector protection cover - if fitted, or from bosses on fuel rail. (Scheme 214)
12. Remove 2 bolts securing protection cover - if fitted and right fuel rail to right inlet manifold, remove cover. (Scheme 215)
13. Remove 2 bolts securing fuel rail to left inlet manifold. (Scheme 216)
14. Release injectors from manifolds and carefully lay fuel rail and injectors aside. CAUTION: Always fit plugs to open connections to prevent contamination.
15. Using sequence shown, progressively loosen and remove 8 cylinder head bolts. (Scheme 217)
16. Remove cylinder head. CAUTION: Support both ends of cylinder head on blocks of wood.
17. Remove and discard cylinder head gasket. CAUTION: Do not rotate crankshaft with left cylinder head fitted.
18. Fit cylinder liner clamps LRT-12-144 and secure with cylinder head bolts. see scheme 38 CAUTION: Ensure that feet of clamps do not protrude over bores.

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

1. Clean cylinder head face. CAUTION: Use suitable gasket removal spray and a plastic scraper.
2. Remove bolts securing cylinder liner clamps LRT-12-144 to cylinder block and remove clamps. see scheme 38 CAUTION: Do not rotate crankshaft.
3. Clean cylinder block face, dowels and dowel holes.
4. Clean cylinder head bolts and wipe dry.
5. Lightly lubricate threads and beneath heads of cylinder head bolts with clean engine oil.
6. Check that fitted height of dowels is between 10 to 11 mm (0.40 to 0.43 in) above cylinder block top face. Replace dowels if fitted height is incorrect. see scheme 33
7. Fit new cylinder head gasket onto cylinder block with the word "TOP" uppermost.
8. With assistance, fit cylinder head and carefully position right inlet to left inlet manifold.
9. Carefully enter cylinder head bolts, DO NOT DROP. Screw bolts into place by hand.
10. Using sequence shown, tighten cylinder head bolts progressively. see scheme 250: Stage 1 - 25 Nm (18 ft. lbs.) Stage 2 - 25 Nm (18 ft. lbs.) Stage 3 - 25 Nm (18 ft. lbs.) Stage 4 - Further 180°
11. Fit right camshaft cover gasket. See «CAMSHAFT COVER GASKET - RIGHT»(ref-158807-S13216424482005011200000).
12. Remove and discard lower "O" rings from injectors.
13. Clean injectors and injector locations in fuel rail.
14. Lubricate new "O" rings with castor oil and fit to injectors.
15. Position fuel rail assembly and secure injectors to inlet manifolds.
16. Position injector protection cover - if fitted to right fuel rail and secure injector harness to protection cover or fuel rail with clips..
17. Fit bolts securing fuel rail to inlet manifolds and tighten to 9 Nm (7 ft. lbs.).
18. Connect coolant bleed hose to inlet manifold and secure with clip.
19. Up to Model Year 2003: Position ignition coils to left inlet manifold.
20. Up to Model Year 2003: Position earth lead, fit nuts and bolts securing ignition coils to left inlet manifold and tighten to 9 Nm (7 ft. lbs.).
21. Clean camshaft timing belt cover backplate bolts and apply sealant, Part No. STC 50552 to the first 3 threads.
22. Position backplate, fit and tighten bolts to 9 Nm (7 ft. lbs.)
23. Fit new camshaft timing belt. See «CAMSHAFT TIMING BELT»(ref-158807-S16904230992005011200000).
24. Clean exhaust manifold and mating face on cylinder head.
25. Fit new exhaust manifold gasket. Position exhaust manifold, fit nuts and using sequence shown, tighten to 45 Nm (33 ft. lbs.). (Scheme 218)
26. Connect right HO2S multiplug, secure multiplug in coolant rail bracket.
