Engine Control System - 2.4L: Specifications Kia Sportage III

Testing & Diagnostics 16 illustrations ~149 words

Specifications

Pressure (kPa (kgf/cm 2 , psi))Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

PRESSURE AND VOLTAGE SPECIFICATIONS

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36: Circuit Diagram
Scheme 36: Circuit Diagram
Temperature (°C (°F))Resistance (kohms)
40(-40)40.93 - 48.35
20(-4)13.89 - 16.03
0(32)5.38 - 6.09
10(50)3.48 - 3.90
20(68)2.31 - 2.57
40(104)1.08 - 1.21
50(122)0.76 - 0.85
60(140)0.54 - 0.62
80(176)0.29 - 0.34

TEMPERATURE AND RESISTANCE SPECIFICATIONS

Scheme 37

Scheme 37: Circuit Diagram
Scheme 37: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 - 16.83
0325.79
20682.31 - 2.59
401041.15
601400.59
801760.32

TEMPERATURE AND RESISTANCE SPECIFICATIONS

Scheme 38

Scheme 38: Circuit Diagram
Scheme 38: Circuit Diagram
ItemSpecification
Capacitance (pF)850 - 1, 150

KS SPECIFICATIONS

Scheme 39

Scheme 39: Circuit Diagram
Scheme 39: Circuit Diagram

Scheme 40

Scheme 40: Removal
Scheme 40: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Drain the engine coolant. Refer to " «COOLING SYSTEM»(ref-584454) ".
  3. Remove the radiator upper hose. Refer to " «REMOVAL AND INSTALLATION»(ref-584454-S24590840092013110400000) ".
  4. Disconnect the knock sensor connector (A).
  5. Remove the intake manifold. Refer to " «INTAKE AND EXHAUST SYSTEM»(/kia/sportage/iii-2010-2014/remont/exhaust/#intake-exhaust-system-24l) ".
  6. Remove the installation bolt (A), and then remove the sensor from the cylinder block.

Scheme 41

Scheme 41
Scheme 41
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T.0.7 - 0.80.29 - 0.46
W.O.T.3.85 - 4.351.93 - 2.18

APS VOLTAGE SPECIFICATIONS

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43: Circuit Diagram
Scheme 43: Circuit Diagram

Specification

Pressure (kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

PRESSURE AND VOLTAGE SPECIFICATIONS

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45: Circuit Diagram
Scheme 45: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 - 15.2 (20°C (68°F))

COIL RESISTANCE SPECIFICATIONS

Scheme 46

Scheme 46: Circuit Diagram
Scheme 46: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 - 22.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 47

Scheme 47: Circuit Diagram
Scheme 47: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 - 7.9 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 48

Scheme 48: Circuit Diagram
Scheme 48: Circuit Diagram
ItemSpecification
Coil resistance (ohms)30.0 - 35.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 49

Scheme 49: Circuit Diagram
Scheme 49: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 - 21.8 (20°C (68°F)

COIL RESISTANCE SPECIFICATION

Scheme 50

Scheme 50: Circuit Diagram
Scheme 50: Circuit Diagram
