Engine Control System - 2.0L: Specifications Kia Sportage III

Testing & Diagnostics 17 illustrations

Specification

Pressure (kPa (kgf/cm 2 , psi))Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

VOLTAGE SPECIFICATION CHART

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133: Circuit Diagram
Scheme 133: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
501221.56 ~ 1.74
601400.54 ~ 0.62
801760.29 ~ 0.34

RESISTANCE TEMPERATURE SPECIFICATION CHART

Scheme 134

Scheme 134: Circuit Diagram
Scheme 134: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

VOLTAGE SPECIFICATION CHART

Scheme 135

Scheme 135: Circuit Diagram
Scheme 135: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1, 150

RESISTANCE SPECIFICATION CHART

Scheme 136

Scheme 136: Circuit Diagram
Scheme 136: Circuit Diagram
Temperature (°C (°F))Resistance (kohms)
40(-40)52.15
20(-4)16.52
0(32)6.0
20(68)2.45
40(104)1.11
60(140)0.54
80(176)0.29

RESISTANCE SPECIFICATION CHART

Scheme 137

Scheme 137: Circuit Diagram
Scheme 137: Circuit Diagram
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

VOLTAGE REFERENCE CHART

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139: Circuit Diagram
Scheme 139: Circuit Diagram
Pressure (kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

PRESSURE VOLTAGE CHART

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141: Circuit Diagram
Scheme 141: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)1.25 (20°C (68°F))

RESISTANCE SPECIFICATION CHART

Scheme 142

Scheme 142: Circuit Diagram
Scheme 142: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 (20°C (68°F))

RESISTANCE SPECIFICATION CHART

Scheme 143

Scheme 143: Circuit Diagram
Scheme 143: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 (20°C (68°F))

RESISTANCE SPECIFICATION CHART

Scheme 144

Scheme 144: Circuit Diagram
Scheme 144: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)0.5 (20°C (68°F)

RESISTANCE SPECIFICATION CHART

Scheme 145

Scheme 145: Signal Waveform
Scheme 145: Signal Waveform

Scheme 146

Scheme 146: Circuit Diagram
Scheme 146: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)28.3 ~ 31.1 (20°C (68°F))

RESISTANCE REFERENCE CHART

Scheme 147

Scheme 147: Circuit Diagram
Scheme 147: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.9 ~ 22.9 (20°C (68°F))

RESISTANCE REFERENCE CHART

Scheme 148

Scheme 148: Circuit Diagram
Scheme 148: Circuit Diagram
