COMPONENT LOCATIONS
For component locations Rio, Sephia, Spectra and Sportage (Scheme 39)- (Scheme 41). For Optima & Magentis (Canadian) component locations, see COMPONENT LOCATIONS (OPTIMA & MAGENTIS (CANADIAN)) table.
Scheme 39
Scheme 40
Scheme 41
| Component | Location | |
|---|---|---|
| Camshaft Position Sensor | Rear of Right Cylinder Head | |
| Catalytic Converter | Under Car, At Center Of Car | |
| Front Catalytic Converter | Left Side Of Engine, Facing Radiator | |
| Rear Catalytic Converter | Right Side Of Engine, Facing Firewall | |
| Crankshaft Position Sensor | ||
| 2.4L | Behind Front Engine Cover, At Crankshaft | |
| 2.5L | On Bellhousing, Positioned Over Flywheel | |
| Data Link (check) Connector | Under Dash, On Left | |
| Data Link (OBD-II) Connector | Under Dash, On Left | |
| Engine Coolant Temp Sensor | Next To Thermostat | |
| Evaporative Emissions Canister | Rear Of Car, Near Fuel Tank | |
| Evaporative Emissions Purge Solenoid | ||
| 2.4L | At End Of Intake Plenum, Above Alternator | |
| 2.5L | On Firewall Next To Intake Plenum | |
| Exhaust Gas Recirculation Solenoid | ||
| 2.4L | On Firewall Next To Intake Plenum | |
| Exhaust Gas Recirculation Valve | ||
| 2.4L | Bottom Of Intake Plenum, Near Throttle Body | |
| Fuel Tank Pressure Sensor | Mounted On Fuel Tank | |
| Heated Oxygen Sensors (Front) | Mounted Above Catalytic Converters | |
| Heated Oxygen Sensors (Rear) | Mounted After Catalytic Converters | |
| Intake Air Temp Sensor | ||
| 2.4L | Component Of Mass Air Flow Sensor | |
| 2.5L | Mounted At Back Side Of Intake Plenem | |
| Main Fuse/Relay Box | Engine Compartment | |
| Mass Air Flow Sensor | Mounted On Intake Hose, Before Throttle Body | |
| Manifold Absolute Pressure Sensor | ||
| 2.4L | Mounted On Intake Plenum | |
| Power Steering Switch | Mounted On Power Steering Pump | |
| Throttle Position Sensor | Mounted On Throttle Body | |
| Transmission Control Module | Mounted In car, Below and Behind Radio | |
| Transmission Position Switch | Mounted On Top Front Of Transmission | |
| Transmission Solenoids Connector | Left Of Transmission Position Switch | |
| Vehicle Speed Sensor | Mounted At Back Of Transmission | |
COMPONENT LOCATIONS (OPTIMA & MAGENTIS (CANADIAN))
