Inspection
- Check each part for cracks, damage or wear, and replace the coolant pump assembly if necessary.
- Check the bearing for damage, abnormal noise and sluggish rotation, and replace the coolant pump assembly if necessary.
- Check for coolant leakage. If coolant leaks from hole, the seal is defective. Replace the coolant pump assembly. NOTE: A small amount of "weeping" from the bleed hole is normal.
Troubleshooting
| Symptoms | Possible Causes | Remedy | ||
|---|---|---|---|---|
| Coolant leakage | From the thermostat gasket | Check the mounting bolts | Check the torque of the mounting bolts | Retighten the bolts and check leakage again. |
| Check the gasket for damage | Check gasket or seal for damage | Replace gaskets and reuse the thermostat. | ||
| Cooled excessively | Low heater performance (cool air blows out) Thermogauge indicates 'LOW' | Visually check after removing the radiator cap. | Insufficient coolant or leakage. | After refilling coolant, recheck. |
| GDS check & Starting engine | Check DTCs Check the fan motor performance as temperature varies. Check connection of the fan clutch or the fan motor. * If the fan clutch is always connected, there will be a noise at idle. | Check the engine coolant sensor, wiring and connectors. Check the fan motor, the relay and the connector. Replace the components. | ||
| Remove the thermostat and inspect | Check if there are dusts or chips in the thermostat valve. Check adherence of the thermostat. | Clean the thermostat valve and reuse the thermostat. Replace the thermostat, if it doesn't work properly. | ||
| Heated excessively | Engine overheated Thermogauge indicates 'HI' | Visually check after removing the radiator cap. | Insufficient coolant or leakage. * Be careful when removing a radiator cap of the overheated vehicle. Check air in cooling system. | After refilling coolant, recheck. Check the cylinder head gaskets for damage and the tightening torque of the mounting bolts. |
| GDS check & Starting engine | Check DTCs Check the fan motor performance as temperature varies. Check if the fan clutch slips. Check the water pump adherence or impeller damaged. | Check the engine coolant sensor, wiring and connectors. Check the fan motor, the relay and the connector. Replace the fan clutch, if it doesn't work properly. Replace the water pump, if it doesn't work properly. | ||
| Immerse the thermostat in boiling water and inspection. | After removing the thermostat, check it works properly. * Check the thermostat opens at the valve opening temperature. | Replace the thermostat, if it doesn't work properly. | ||
Scheme 29
Scheme 30
Scheme 31
Scheme 32
- Drain engine coolant so its level is below water temperature control assembly.
- Remove the air cleaner assembly. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
- Disconnect the radiator upper hose (A).
- Disconnect the heater hose (A).
- Disconnect the bypass hose (A) and the throttle body coolant hose (B).
- Remove the water temperature control assembly (A) with the O-ring (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Installation is reverse order of removal. NOTE: Install a new O-ring. Clean surface on the O-ring and install the O-ring after wetting with water.
