Refilling And Bleeding

Scheme 36

Scheme 37

1. Make sure the engine and radiator are cool to the touch.
2. Remove radiator cap (A).
3. Remove the under cover. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
4. Loosen the drain plug (A) and drain the coolant.
5. Tighten the radiator drain plug securely.
6. After draining engine coolant in the reservoir tank, clean the tank.
7. Fill the radiator with water through the radiator cap and tighten the cap. NOTE: To most effectively bleed the air, pour the water slowly and press on the upper/lower radiator hoses.
8. Start the engine and allow to come to normal operating temperature. Wait for the cooling fans to turn on several times. Accelerate the engine to aid in purging trapped air. Shut engine off.
9. Wait until the engine is cool.
10. Repeat step 1 to 9 until the drained water runs clear.
11. Fill fluid mixture with coolant and water (55~60%) (except for North America, Europe and China: 45~50%) slowly through the radiator cap. Push the upper/lower hoses of the radiator so as bleed air easily. NOTE: Use only genuine antifreeze/coolant. For best corrosion protection, the coolant concentration must be maintained year-round at 55% (except for North America, Europe and China: 45%) minimum. Coolant concentrations less than 55% (except for North America, Europe and China: 45%) may not provide sufficient protection against corrosion or freezing. Coolant concentrations greater then 60% will impair cooling efficiency and are not recommended. CAUTION: Do not mix different brands of antifreeze/coolants. Do not use additional rust inhibitors or antirust products; they may not be compatible with the coolant.
12. Start the engine and run until coolant circulates. When the cooling fan operates and coolant circulates, refill coolant through the radiator cap.
13. Repeat step 12 until the cooling fan 3 ~ 5 times and bleed air sufficiently out of the cooling system.
14. Install the radiator cap and fill the reservoir tank to the "MAX" (or "FULL") line with coolant.
15. Run the vehicle under idle until the cooling fan operates 2 ~ 3 times.
16. Stop the engine and wait coolant gets cool.
17. Repeat step 11 to 16 until the coolant level doesn't fall any more, bleed air out of the cooling system. NOTE: It takes time to bleed out all the air in the cooling system. Refill coolant when coolant gets cool completely, then recheck the coolant level in the reservoir tank for 2~3 days after replacing coolant. Coolant capacity: 6.4 L (1.69 U.S.gal., 6.76 U.S.qt., 5.63 lmp.qt.)

Scheme 38

Scheme 39

1. Remove the radiator cap, wet its seal with engine coolant, and then install it on a pressure tester.
2. Apply a pressure of 93.16 ~ 122.58 kPa (0.95 ~ 1.25 kgf/cm 2 , 13.51 ~ 17.78 psi).
3. Check for a drop in pressure.
4. If the pressure drops, replace the cap.

Scheme 40

1. Wait until engine is cool, then carefully remove the radiator cap and fill the radiator with engine coolant, then install it on the pressure tester (A).
2. Apply a pressure tester to the radiator and apply a pressure of 93.16 ~ 122.58 kPa (0.95 ~ 1.25 kgf/cm 2 , 13.51 ~ 17.78 psi).
3. Inspect for engine coolant leaks and a drop in pressure.
4. Remove the tester and reinstall the radiator cap. NOTE: Check for engine oil in the coolant and/or coolant in the engine oil.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. Disconnect the battery negative terminals. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
2. Remove the air cleaner assembly. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
3. Remove the front bumper. (Refer to " «FRONT BUMPER»(ref-537203-S05751684872013032200000) ")
4. Disconnect the over flow hose (A) from the filler neck.
5. Disconnect the fan motor connector (A)
6. Remove the under cover. (Refer to «ENGINE AND TRANSAXLE ASSEMBLY»(ref-537192-S30675217252013032200000) in this group)
7. Loosen the drain plug (A) and drain the engine coolant. Remove the radiator cap to help drain the coolant faster.
8. Disconnect the radiator upper hose (A).
9. Disconnect the radiator lower hose (A).
10. Disconnect the ATF cooler hoses (A) (A/T only). (Refer to " «AUTOMATIC TRANSAXLE»(ref-537206-S17871285202013032200000) ")
11. Remove the horn (A), the intake shield cover (B) and the air guard (C).
12. Remove the radiator upper mounting bracket (A). Tightening torque: 7.8 ~ 11.8N.m (0.8 ~ 1.2kgf.m, 5.8 ~ 8.7lb-ft)
13. Remove the hood latch (B). (Refer to " «HOOD»(ref-537248-S39970386542013032200000) ")
14. Separate the condenser from the radiator and then remove the radiator assembly (A).
15. Remove the cooling fan (B) from the radiator (A).
16. Installation is the reverse order of removal.
17. Fill the radiator with coolant and check for leaks. NOTE: Bleed air from the cooling system. Start engine and let it run until it warms up (until the radiator fan operates 3 or 4 times). Turn off engine. Check the coolant level and add coolant if needed. This will allow trapped air to be removed from the cooling system. Put the radiator cap on tightly, then run engine again and check for leaks.

Scheme 51

Scheme 52

Scheme 53

1. Loosen the drain plug, and then drain the engine coolant. Remove the radiator cap to help drain the coolant faster.
2. Remove the drive belt. (Refer to «REMOVAL»(ref-537285-S30253579552013032200000) .
3. Remove the water pump pulley (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
4. Remove the water pump assembly (A) with the gasket (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
5. Installation is reverse order of removal NOTE: Install a new water pump gasket.
6. Fill the engine coolant.
7. Start the engine and check for leaks.
8. Recheck the coolant level.
