Scheme 31
Scheme 32
Description
Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the R position. This system is a supplemental system that shows behind the vehicle through the AV monitor or ECM mirror while backing up.
| WARNING | This system is a supplementary function only. It is the responsibility of the driver or always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there is a dead zone that can't see through the camera. |
Scheme 33
Scheme 34
- Remove the tailgate trim after removing the screws and clips. (Refer to the " «TAILGATE»(ref-537248-S03168982472013032200000) ")
- Remove the connector and nuts (2EA).
- Remove the back view camera(A).
