Engine Control System: Specifications Kia Sedona II рестайлинг

Testing & Diagnostics 30 illustrations ~178 words

Specification

(Throttle Position Sensor (TPS))

Throttle Angle (°)Output Voltage (V)
TPS1TPS2
00.05.0
100.54.5
200.94.1
301.43.6
401.83.2
502.32.7
602.72.3
703.21.8
803.61.4
904.10.9
1004.50.5
1105.00.0

VOLTAGE SPECIFICATION

Scheme 31

Scheme 31
ItemSensor Resistance (kohms)
TPS13.6 ~ 6.0 (20°C (68°F))
TPS22.7 ~ 4.1 (20°C (68°F))

RESISTANCE SPECIFICATION

(ETC Motor)

ItemSpecification
Coil Resistance (ohms)1.275 ~ 1.725 (20°C (68°F))

RESISTANCE SPECIFICATION

Scheme 32

Scheme 32: Circuit Diagram
Pressure (kPa)Output Voltage (V)
10.00.50
55.02.21
100.03.93
115.04.50

VOLTAGE SPECIFICATION

Scheme 33

Scheme 33

Scheme 34

Scheme 34: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
601400.54 ~ 0.66
801760.29 ~ 0.34

RESISTANCE SPECIFICATION

Scheme 35

Scheme 35: Circuit Diagram
Pressure (kPa)Output Voltage (V)
20.00.79
46.661.84
101.324.0

VOLTAGE SPECIFICATION

Scheme 36

Scheme 36

Scheme 37

Scheme 37: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

RESISTANCE SPECIFICATION

Scheme 38

Scheme 38: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)774 ~ 946 (20°C (68°F))
Air Gap (mm)0.5 ~ 1.5

COIL RESISTANCE SPECIFICATION

Scheme 39

Scheme 39: Wave Form

Scheme 40

Scheme 40: Circuit Diagram
ItemSpecification
Output Voltage (V)High: 5.0V
Low: 0.7V
Air Gap (mm)0.5 ~ 1.5

VOLTAGE SPECIFICATION

Scheme 41

Scheme 41: Wave Form

Scheme 42

Scheme 42: Circuit Diagram
ItemSpecification
Capacitance (pF)950 ~ 1, 350

CAPACITANCE SPECIFICATION

Scheme 43

Scheme 43: Circuit Diagram

Scheme 44

Scheme 44: Removal

Scheme 45

Scheme 45
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the knock sensor connector (A). (Bank 1) (Bank 2)
  3. Remove the intake manifold. Refer to «INTAKE AND EXHAUST SYSTEM»(/kia/sedona/ii-2010-2014/remont/exhaust/#intake-exhaust-system) .
  4. Remove the installation bolt (A), and then remove the sensor from the cylinder block.

(Bank 1)

Scheme 46

Scheme 46

(Bank 2)

Scheme 47

Scheme 47
A/F Ratio (lambda)Output Voltage (V)
RICHMin. 0.8
LEANMax. 0.1

VOLTAGE SPECIFICATION

ItemSpecification
Heater Resistance (ohms)3.3 ~ 4.1 (20°C (68°F))

RESISTANCE SPECIFICATIONS

Scheme 48

Scheme 48: Wave Form

Scheme 49

Scheme 49

Scheme 50

Scheme 50: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404052.15
20416.52
0326.0
20682.45
401041.11
601400.54
801760.29

RESISTANCE SPECIFICATION

Scheme 51

Scheme 51: Circuit Diagram
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.27 ~ 0.47
W.O.T.3.8 ~ 4.41.75 ~ 2.35

VOLTAGE SPECIFICATION

Scheme 52

Scheme 52

Scheme 53

Scheme 53: Circuit Diagram
Pressure (kPa)Output Voltage (V)
3.750.5
02.5
+3.754.5

VOLTAGE SPECIFICATION

Scheme 54

Scheme 54

Scheme 55

Scheme 55: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 56

Scheme 56: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 57

Scheme 57: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)9.4 ~ 10.4 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 58

Scheme 58: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)30.0 ~ 35.0 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 59

Scheme 59: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.8 ~ 21.8 (20°C (68°F))

COIL RESISTANCE SPECIFICATION

Scheme 60

Scheme 60: Circuit Diagram
