Blower and A/c Controls (Automatic): Specifications Kia Sedona II

SPECIFICATION

FREQUENCY SPECIFICATION

Scheme 31

1. Connect scantool to data link connector (DLC).
2. Engine "ON"
3. Monitor the "Humidity Sensor" Parameter on the Scantool while drying the humidity sensor with a hair drier or heat gun adjusted to a low heat setting.
4. Are the DTC B1200 present and is parameter of "Humidity Sensor" fixed? Parameter of "Humidity Sensor" will be fixed at 10%, if there is any fault in Humidity Sensor. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S30271477832007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S35528849852007110100000) " procedure.

Refer to DTC B1200 .

Scheme 32

1. Connect scantool to data link connector (DLC).
2. Engine "ON"
3. Monitor the "Humidity Sensor" Parameter on the Scantool while drying the humidity sensor with a hair drier or heat gun adjusted to a low heat setting.
4. Are the DTC B1201 present and is parameter of "Humidity Sensor" fixed? Parameter of "Humidity Sensor" will be fixed at 10%, if there is any fault in Humidity Sensor. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S03531013252007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S18819623262007110100000) " procedure.

Refer to DTC B1204 .

Scheme 33

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "Passenger's Air Mix Potentiometer" Parameter on the Scantool while operating temp, switch.
4. Are the DTC B1205 present and is parameter of "Passenger's Air Mix potentiometer" fixed? Parameter of "Passenger's Air Mix potentiometer" will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Passenger's Air Mix potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S00120636652007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S23027010572007110100000) " procedure.

Refer to DTC B1206 .

Scheme 34

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "DR. DIRECTION POTENTIO." parameter on the scantool while operating mode switch.
4. Are the DTC B1207 present and is parameter of "DR. DIRECTION POTENTIO." fixed? Parameter of "DR. DIRECTION POTENTIO." will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Driver Direction potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S39326249082007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S12358714072007110100000) " procedure.

Voltage value of Intake potentiometer as a function of position of Intake door

DOOR POSITION CHART

Scheme 35

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "Intake Potentiometer" Parameter on the Scantool while operating intake switch.
4. Are the DTC B1208 present and is parameter of "Intake Potentiometer" fixed? Parameter of "Intake Potentiometer" will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Intake potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S39863723132007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S32167727292007110100000) " procedure.

Refer to DTC B1208 .

Scheme 36

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "Intake Potentiometer" Parameter on the Scantool while operating intake switch.
4. Are the DTC B1209 present and is parameter of "Intake potentiometer" fixed? Parameter of "Intake potentiometer" will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Intake potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S41667096602007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S00068016592007110100000) " procedure.

TEMPERATURE SPECIFICATION

Scheme 37

1. Connect scantool to data link connector (DLC).
2. Engine "ON"
3. Monitor the "INCAR TEMP. SENSOR" Parameter on the Scantool.
4. Are the DTC B1233 present and is parameter of "INCAR TEMP. SENSOR" fixed? Parameter of "INCAR TEMP. SENSOR" will be fixed at 25°C (77°F), if there is any fault in INCAR TEMP. SENSOR. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S37602973122007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S29719501682007110100000) " procedure.

Refer to DTC B1233 .

Scheme 38

1. Connect scantool to data link connector (DLC).
2. Engine "ON"
3. Monitor the "INCAR TEMP. SENSOR" Parameter on the Scantool.
4. Are the DTC B1234 present and is parameter of "INCAR TEMP. SENSOR" fixed? Parameter of "INCAR TEMP. SENSOR" will be fixed at 25°C (77°F), if there is any fault in INCAR TEMP. SENSOR. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S28958233152007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S42540964612007110100000) " procedure.

TEMPERATURE SPECIFICATION

Scheme 39

1. Connect scantool to data link connector (DLC).
2. Engine "ON"
3. Monitor the "AMBIENT TEMP. SENSOR" Parameter on the Scantool. Parameter of "AMBIENT TEMP. SENSOR" will be fixed at 20°C, if there is any fault in AMBIENT TEMP. SENSOR.
4. Are the DTC B1237 present and is parameter of "AMBIENT TEMP. SENSOR" fixed? YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S35249595882007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S03850061702007110100000) " procedure.

TEMPERATURE SPECIFICATION

Scheme 40

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "AMBIENT TEMP. SENSOR" Parameter on the Scantool. Parameter of "AMBIENT TEMP. SENSOR" will be fixed at 20°C (67°F), if there is any fault in AMBIENT TEMP. SENSOR.
4. Are the DTC B1238 present and is parameter of "AMBIENT TEMP. SENSOR" fixed? YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S30410763562007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S28473833692007110100000) " procedure.

Resistance value of evaporator sensor as a function of temperature.

TEMPERATURE SPECIFICATION

Scheme 41

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "EVAPORATIVE SENSOR" Parameter on the Scantool.
4. Are the DTC B1241 present and is parameter of "EVAPORATIVE SENSOR" fixed? Parameter of "EVAPORATIVE SENSOR" will be fixed at -2°C (28.4°F), if there is any fault in EVAPORATIVE SENSOR. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S38976055052007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S29932888852007110100000) " procedure.

Refer to DTC B1241 .

Scheme 42

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "EVAPORATIVE SENSOR" Parameter on the Scantool.
4. Are the DTC B1242 present and is parameter of "EVAPORATIVE SENSOR" fixed? Parameter of "EVAPORATIVE SENSOR" will be fixed at -2° (28.4°F), if there is any fault in EVAPORATIVE SENSOR. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S40528789362007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S30238505242007110100000) " procedure.

Refer to DTC B1245 .

Scheme 43

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "Driver Air Mix Potentiometer" Parameter on the Scantool while operating temp, switch.
4. Are the DTC B1246 present and is parameter of "Driver Air Mix potentiometer" fixed? Parameter of "Driver Air Mix potentiometer" will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Driver Air Mix potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S37926867662007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S36417825282007110100000) " procedure.

Refer to DTC B1249 .

Scheme 44

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "DR. DIRECTION POTENTIO." parameter on the scantool while operating mode switch.
4. Are the DTC B1250 present and is parameter of "DR. DIRECTION POTENTIO." fixed? Parameter of "DR. DIRECTION POTENTIO." will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Driver Direction potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S03876598052007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S11866380532007110100000) " procedure.

Refer to DTC B1260 .

Scheme 45

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "Rear Air Mix Potentiometer" Parameter on the Scantool while operating temp, switch.
4. Are the DTC B1261 present and is parameter of "Rear Air Mix potentiometer" fixed? Parameter of "Rear Air Mix potentiometer" will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Rear Air Mix potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S25018930902007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S25575120782007110100000) " procedure.

Refer to DTC B1262 .

Scheme 46

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "DR. DIRECTION POTENTIO." parameter on the scantool while operating mode switch.
4. Are the DTC B1263 present and is parameter of "DIRECTION POTENTIO." fixed? Parameter of "DIRECTION POTENTIO." will be fixed at 100% (or any value above 90%), or 0% (or any value below 10%), if there is any fault in Driver Direction potentiometer. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S10244806612007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S12528850952007110100000) " procedure.

Refer to DTC B1208 .

Scheme 47

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "Intake Potentiometer" Parameter on the Scantool while operating Intake switch.
4. Are the DTC B2408 present and is parameter of "Intake Potentiometer" fixed? There is any fault in Intake potentiometer. If the parameter of "Intake potentiometer" is 30% or less when the actuator operates to the fresh position, or If the parameter is 60% and more when the actuator operates to the recirculation position. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S41021069722007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S05723249312007110100000) " procedure.

Refer to DTC B1249 .

Scheme 48

1. Connect scantool to Data Link Connector (DLC).
2. Engine "ON"
3. Monitor the "DR DIRECTION POTENTIO" parameter on the scantool while operating mode switch.
4. Are the DTC B2409 present and is parameter of "Driver DIRECTION POTENTIO." fixed? There is any fault in Driver Direction Motor. If the parameter of "Driver DIRECTION POTENTIO." is 10% or less on "VENT" mode, or If the parameter is 90% or more on "DEF" mode. YES Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-269664-S09370688752007110100000) procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or A/C controller's connector or was repaired and A/C controller memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-269664-S27847866562007110100000) " procedure.
