Scheme 49
GENERAL DESCRIPTION
Humidity sensor located at crush pad, detects in-car humidity for in-car humidity control. If ambient air temperature or in-car humidity is outside certain range, it will turn on A/C to control in-car humidity for preventing in-car fogging. Air conditioner operation depends on ambient temperature and humidity.
DTC DESCRIPTION
The A/C controller sets DTC B1200 if there is an open circuit in humidity sensor signal harness or the measured frequency value of sensor is more than threshold value (about 7,100Hz)
Refer to DTC B1200 .
The A/C controller sets DTC B1201 if there is a short circuit in humidity sensor signal harness or the measured frequency value of sensor is less than threshold value (about 6,186Hz)
Temperature control actuator located at heater unit, regulates the temperature by the procedure as follows. Signal from control unit adjusts position of temp, door by operating temp, motor and then temperature will be regulated by the hot/cold air ratio decided by position of temp. door.
The A/C controller sets DTC B1204 if there is an open circuit or poor connection in the air mix potentiometer.
Refer to DTC B1204 .
The A/C controller sets DTC B1205 if there is a short to power in the air mix potentiometer.
The mode control actuator mounted on heater unit, adjusts position of mode door by operating Direction Motor based on signal of A/C control unit. Pressing mode select switch makes the mode control actuator shift in order of vent--> B/L --> floor --> mix.
The A/C controller sets DTC B1249 if there is an open circuit or poor connection in the Direction potentiometer.
Refer to DTC B1206 .
The A/C controller sets DTC B1207 if there is a short to power in the Direction potentiometer.
Intake door located at heater unit controls the inlet of car. When driver operates the intake switch, A/C controller recirculation receives mode signal from intake switch and operates intake door actuator to turn intake door to intended position, (with fresh mode signal, intake door is closed and with fresh mode signal, intake door is opened).
The A/C controller sets DTC B1208 if there is an open circuit or poor connection in the intake potentiometer.
DTC DETECTING CONDITION
Refer to DTC B1208 .
The A/C controller sets DTC B1209 if there is a short to power in the Intake potentiometer.
The incar temperature sensor located at crush pad, control unit contains a thermistor which measures the temperature of the inside. The signal, decided by the resistance value which changes in accordance with perceived inside temperature, is delivered to heater control unit and according to this signal, the control unit regulates incar temperature to intended value.
The A/C controller sets DTC B1233 if there is a short circuit in incar temp, sensor signal harness or the measured resistance value of sensor is less than threshold value (about 7.46kohms)
Refer to DTC B1233 .
The A/C controller sets DTC B1234 if there is an open circuit in incar temp, sensor signal harness or the measured resistance value of sensor is more than threshold value (about 509.57kohms )
The ambient temperature senor located at the center stay of the condenser, detects ambient air temperature. It is a negative type thermistor whose resistance is inversely proportional to temperature. Its output is used for discharge temperature sensor, sensor fail-safe, temperature regulation door lock, blower motor level control, mix mode control and in-car humidity control.
The A/C controller sets DTC B1237 if there is a short circuit in ambient temp, sensor signal harness or the measured resistance value of sensor is less than threshold value (about 7.48kohms)
The ambient temperature senor located at the center stay of the condenser, detects ambient air temperature. It is a negative type thermistor whose resistance is inversely proportional to temperature. Its output is used for discharge temperature sensor, sensor fail-safe, temperature regulation door lock, blower motor level control, mix mode control and in-car humidity control.
The A/C controller sets DTC B1238 if there is an open circuit in ambient temp, sensor signal harness or the measured resistance value of sensor is more than threshold value (about 527kohms)
The Evaporator temperature sensor located on heater unit, detects the core temperature and interrupts compressor relay power, in order to prevent evaporator freezing by excessive cooling. It is a negative type thermistor whose resistance is inversely proportional to temperature.
The A/C controller sets DTC B1241 if there is a short circuit in evaporator temp, sensor signal harness or the measured resistance value of sensor is less than threshold value (about 0.9kohms)
Refer to DTC B1241 .
The A/C controller sets DTC B1242 if there is an open circuit in evaporator temp, sensor signal harness or the measured resistance value of sensor is more than threshold value (about 13.6kohms)
Temperature control actuator located at heater unit, regulates the temperature by the procedure as follows. Signal from control unit adjusts position of temp, door by operating temp, motor and then temperature will be regulated by the hot/cold air ratio decided by position of temp. door.
The A/C controller sets DTC B1245 if there is an open circuit or poor connection in the air mix potentiometer.
Refer to DTC B1245 .
The A/C controller sets DTC B1246 if there is a short to power in the air mix potentiometer.
The mode control actuator mounted on heater unit, adjusts position of mode door by operating Direction Motor based on signal of A/C control unit. Pressing mode select switch makes the mode control actuator shift in order of vent --> B/L --> floor --> mix.
The A/C controller sets DTC B1249 if there is an open circuit or poor connection in the Direction potentiometer.
Refer to DTC B1249 .
The A/C controller sets DTC B1250 if there is a short to power in the Direction potentiometer.
Temperature control actuator located at heater unit, regulates the temperature by the procedure as follows. Signal from control unit adjusts position of temp, door by operating temp, motor and then temperature will be regulated by the hot/cold air ratio decided by position of temp. door.
The A/C controller sets DTC B1260 if there is an open circuit or poor connection in the air mix potentiometer.
Refer to DTC B1260 .
The A/C controller sets DTC B1261 if there is a short to power in the air mix potentiometer.
The mode control actuator mounted on heater unit, adjusts position of mode door by operating Direction Motor based on signal of A/C control unit. Pressing mode select switch makes the mode control actuator shift in order of vent --> B/L --> floor --> mix.
The A/C controller sets DTC B1262 if there is an open circuit or poor connection in the Direction potentiometer.
Refer to DTC B1262 .
The A/C controller sets DTC B1263 if there is a short to power in the Direction potentiometer.
Temperature control actuator located at heater unit, regulates the temperature by the procedure as follows. Signal from control unit adjusts position of temp, door by operating temp, motor and then temperature will be regulated by the hot/cold air ratio decided by position of temp. door.
The A/C controller sets DTC B2405 if the air mix actuator doesn't move to intended position within 40sec (In this case, A/C controller try to move temp, door for 2sec. 3 times, every 20 sec. before setting DTC).
Temperature control actuator located at heater unit, regulates the temperature by the procedure as follows. Signal from control unit adjusts position of temp, door by operating temp, motor and then temperature will be regulated by the hot/cold air ratio decided by position of temp. door.
The A/C controller sets DTC B2406 if the air mix actuator doesn't move to intended position within 40sec (In this case, A/C controller try to move temp, door for 2sec. 3 times, every 20 sec. before setting DTC).
Refer to DTC B1208 .
The A/C controller sets DTC B2408 if the intake motor Doesn't move to intended position within 40sec (The A/C controller attempts to move the intake door for a 2 second duration at a frequency of 3 times every 20 seconds before storing a DTC.)
Refer to DTC B1249 .
The A/C controller sets DTC B2409 if the direction motor doesn't move to intended position within 40sec (In this case, A/C controller try to move mode door for 2sec. 3 times, every 20 sec. before setting DTC).
The mode control actuator mounted on heater unit, adjusts position of mode door by operating Direction Motor based on signal of A/C control unit. Pressing mode select switch makes the mode control actuator shift in order of vent --> B/L --> floor --> mix.
The A/C controller sets DTC B2411 if the direction motor doesn't move to intended position within 40sec (In this case, A/C controller try to move mode door for 2sec. 3 times, every 20 sec. before setting DTC).
Temperature control actuator located at heater unit, regulates the temperature by the procedure as follows. Signal from control unit adjusts position of temp, door by operating temp, motor and then temperature will be regulated by the hot/cold air ratio decided by position of temp. door.
The A/C controller sets DTC B2415 if the air mix actuator doesn't move to intended position within 40sec (In this case, A/C controller try to move temp, door for 2sec. 3 times, every 20 sec. before setting DTC).
The mode control actuator mounted on heater unit, adjusts position of mode door by operating Direction Motor based on signal of A/C control unit. Pressing mode select switch makes the mode control actuator shift in order of vent --> B/L --> floor --> mix.
The A/C controller sets DTC B2416 if the direction motor doesn't move to intended position within 40sec (In this case, A/C controller try to move mode door for 2sec. 3 times, every 20 sec. before setting DTC).
