A/c Compressor Controls (Full Auto): Specifications Kia Sedona II

Automatic HVAC System 2 illustrations

SPECIFICATION

Temperature [°C (°F)]Resistance between terminals 2and 4 (kohms)
0 (32)97.71 ± 2.4%
15 (59)47.13 ± 1.7%
25 (77)30.00 ± 1.2%
35 (95)19.59 ± 1.6%
50 (122)10.81 ± 2.2%

TEMPERATURE SPECIFICATION

Note. In car sensor is negative type thermistor that resistance will rise with lower temperature, and reduce with higher temperature.

Scheme 1

Scheme 1: REPLACEMENT
Scheme 1: REPLACEMENT
  1. Disconnect the negative (-) battery terminal.
  2. Remove the A/C control panel. (Refer to «INTERIOR»(ref-269624) ).
  3. Disconnect the connector of in-car sensor. Loosen the mounting 2 screws and then remove the in-car sensor (A).
  4. Installation is the reverse order of removal.

Scheme 2

Scheme 2: COMPONENT LOCATION
Scheme 2: COMPONENT LOCATION
