Lighting System - Except Hev: Other Kia Optima III

Characteristic

1. Durable for vibration as there is no filament.
2. HID lamp had a more long life than halogen lamp.
3. Does not operate if polarity is changed.
4. Operating input voltage : 9-16V

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Disconnect the negative (-) battery terminal.
2. Remove the front bumper. Refer to «FRONT BUMPER»(ref-429584-S24274374532011101500000) .
3. Loosening the head lamp mounting bolts (A) (2 EA) and disconnect the head lamp connector (B). Then, remove the head lamp assembly (C). NOTE: Take care not to scratch the head lamp lens or fender. NOTE: Take care that holding clip (A) is not damaged.
4. In case of HID type, disconnect the head lamp leveling actuator connector (A).
5. Remove the dust caps from the head lamp assembly after turning in the counter clock-wise direction. Head Lamp (High) Cap Head Lamp (Low) Cap

Head Lamp Aiming Instructions

The head lamps should be aimed with the proper beam-setting equipment, and in accordance with the equipment manufacturer's instructions.

Note. If there are any regulations pertinent to the aiming of head lamps in the area where the vehicle is to be used, adjust so as to meet those requirements.

Alternately turn the adjusting gear to adjust the head lamp aiming. If beam-setting equipment is not available, proceed as follows

Scheme 46

1. Inflate the tires to the specified pressure and remove any loads from the vehicle except the driver, spare tire, and tools.
2. The vehicle should be placed on a flat floor.
3. Draw vertical lines (Vertical lines passing through respective head lamp centers) and a horizontal line (Horizontal line passing through center of head lamps) on the screen.
4. With the head lamp and battery in normal condition, aim the head lamps so the brightest portion falls on the horizontal and vertical lines. Horizontal (HI & LOW)

Front Fog Lamp Aiming

The front fog lamps should be aimed as the same manner of the head lamps aiming.

With the front fog lamps and battery normal condition, aim the front fog lamps by turning the adjusting screw (A) with a driver.

Scheme 47

Scheme 48

VEHICLE CONDITION CHART

Scheme 49

Scheme 50

1. Head Lamp (Low beam) Turn the low beam on without driver aboard. The cut-off line should be projected in the cut-off line shown in the picture. If head lamp leveling device is equipped, adjust the head lamp leveling device switch with 0 positions.
2. Turn the front fog lamp on without the driver aboard. The cut-off line should be projected in the allowable range (shaded region)

Scheme 51

1. Turn the head lamp switch off.
2. Disconnect the power connector from the lamp.
3. Remove the head lamp (Low) cap.
4. Disconnect the connector (A).
5. Turn the bulb and socket (A) counter clockwise to remove the turn signal bulb.
6. Installation is the reverse of removal.

Scheme 52

1. Turn the head lamp switch off.
2. Disconnect the power connector from the lamp.
3. Remove the head lamp (Low) cap.
4. Remove the clip (B) and ignitor connector (A) from the lamp assembly.
5. Remove the head lamp (Low) ignitor.
6. Installation is the reverse of removal. CAUTION: Turn the head lamp switch off to avoid high voltage Be careful not to damage the bulb and use genuine bulbs only Do not apply excessive force and fit it correctly. Confirm the bulb locking

Scheme 53

1. Turn the head lamp switch off.
2. Remove the head lamp assembly.
3. Disconnect the power connector from the lamp.
4. Remove the ballast (A) after removing the screws (3 EA) and connector. NOTE: Be careful not to be damaged when disconnecting the ballast connector.
5. Installation is the reverse of removal. NOTE: Turn the head lamp switch off to avoid high voltage. CAUTION: HID lamp shall not be used on other cars. (Fire may occur.) Fire may occur when HID lamp initially lights due to the fact that arc-discharge generates high voltage (max. 20, 000 V) and high current (12-13A), and are different from the halogen lamp specification. Install the dust cover after confirming the locking state between bulb and bulb holder. When testing the HID head lamp, turn the power on or off with switch between power supply and lamp because of high voltage. Do not operate the head lamp switch with the bulb not installed, because it generates spark momently.

Scheme 54

1. Turn the head lamp power off.
2. Disconnect the power connector from the lamp.
3. Remove the head lamp (High) cap.
4. Remove the connector (A) and fixing clip (B).
5. Remove the head lamp (High) bulb.
6. Installation is the reverse of removal.

Scheme 55

1. Turn the head lamp power off.
2. Remove the lamp assembly.
3. Turn the bulb socket (A) counterclockwise to remove the bulb (B).
4. Installation is the reverse of removal.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Check that the switch operates properly after disconnecting the room lamp connector (A). A type B type

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Disconnect the negative (-) battery terminal.
2. Carefully remove the lamp lens (A) from the room lamp with a flat-tip screwdriver. NOTE: Take care not to damage the part (B) A type B type
3. Replace the bulbs (A) and remove the screws if it is necessary.
4. Remove the room lamp assembly (A) after disconnecting the connector (B).

Scheme 64

1. Disconnect the negative (-) battery terminal.
2. Remove the vanity lamp (A) by pressing the clip (B) with a small screwdriver.
3. Remove the vanity lamp assembly after disconnecting the connector.

Room Lamp

1. Reconnect the connector.
2. Install the room lamp assembly.
3. Install the lens.

Vanity Lamp

1. Reconnect the vanity lamp connector.
2. Install the vanity lamp.

Scheme 65

Side Repeater Lamp

1. Install the bulb to the side repeater lamp assembly.
2. Install the side repeater lamp.

Door Mirror Turn Signal Lamp

1. Install the door mirror turn signal lamp to the door mirror.
2. Install the door mirror.
3. Connect the battery terminal (-).

Scheme 66

Scheme 67

1. The lamp switch inputs can be checked using the GDS.
2. To check the input value of lamp switch, select option "Body Control Module".
3. To consult the present input/output value of BCM, "Current DATA". It provides information of BCM input/output conditions of power supply, turn signal/brake lamp, headlamp, door, locks, outside mirror, wiper, auto-light and transmitters etc.
4. To check the input value of lamp switch in force mode, select option "Actuation Test".

SYMPTOM CHART
