Lighting System - Hev: Specifications Kia Optima III

Exterior Lights 9 illustrations ~758 words

Specification

Light BulbWattageBulb Type
Headlights (Low)55 or 35 (HID)H11B / D1S
Headlights (High)55H7
Front turn signal2727/8W
Front side marker5W5W
Position light (With turn signal)88W
Side repeater lampLEDLED
Front fog lamp27GE881
Stop and tail lampLEDLED
Rear turn signal lamp2727W
Back-up lamp16 or 1816 & 18W
Rear side markerLEDLED
High mounted stop lampLED
License plate lamp5W5W
Front map lamp10W10W
Center room lamp10C10W
Trunk room lamp5C5W
Rear personal lamp10C10W

Scheme 221

Scheme 221: Component Location(1)

Scheme 222

Scheme 222: Component Location(2)

Scheme 223

Scheme 223: Component(1)

Scheme 224

Scheme 224: Component(2)

Scheme 225

Scheme 225: HID Head Lamp

Scheme 226

Scheme 226
  1. Bulb Elements Xenon gas: Xenon gas activates the initial reaction for rapid illuminating. Molybdenum electrode: anode arcing Metal halide salts: color composing component Lightening principle When Xenon gas and metal halide salt will discharge the molybdenum anode in a capsule, it emits light.
  2. Ignitor Ignitor (A) is an electromagnetic transformer that receives current from ballast and boost voltage to light on the arc light source in any environment.
  3. Ballast Ballast (A) delivers an instant high voltage pulse to the ignitor electrode, to initialize discharge in the source. Ballast supplies the stable power to the bulb and the ignitor during initialization and normal state of arc.
  4. Stability Durable for vibration as there is no filament. Does not operate if polarity are changed. Doesn't operate if the input voltage is not in the range of 10-16V. Doesn't operate if the circuit is short. Doesn't operate if the bulb burnt out.

Scheme 227

Scheme 227: Inspection

Scheme 228

Scheme 228

Scheme 229

Scheme 229
  1. Check-points upon head lamp failure (HID) Check the battery voltage. (Low beam will be on when the battery voltage above 9V.) Check the fuse and relay. Check the polarity of ballast. (If the polarity are changed, low beam doesn't lighten) Check the bulb connector securely. Visually bulb checking (no filament): damaged glass, damaged for upper parts and lower parts of glass tube. After (1)~(5), replace the ballast and the ignitor. (ballast assembly). CAUTION: If a headlamp goes out after a period of operation but will immediately relights when the headlamp switch is cycled it is likely the HID lamp needs to be replaced.
  2. Service procedure and warning (HID) No. Item Service procedures Warning Remarks 1 Replacement of lamp assembly Disconnect the power connector from the lamp. Remove and replace the lamp assembly. Connect the power connector. Disconnect the head lamp power connector to avoid high voltage. Other description is the same as the halogen bulbs. 2 Replacement of the Bulb Disconnect the power connector from the lamp. (head lamp, turn signal, head lamp leveling device) Remove the lamp assembly. Remove the ballast and dust cover. Remove the bulb socket and replace the bulb. Installation is the reverse of removal. Disconnect the head lamp power connector to avoid high voltage. Be careful not to damage the bulb and use genuine bulbs only. Do not apply excessive force and fit it correctly. 3 Replacement of the Ballast (with built-in ignitor) Disconnect the power connector from the lamp. Remove the lamp and then the ballast and the dust cover. Remove the head lamp leveling device and then the bulb socket. Connect the bulb socket on the replacement ballast and install the leveling device. Installation is the reverse of removal. Disconnect the head lamp power connector to avoid high voltage. Replace the ballast only and install the used lamp. Replace the sub assembly except the ballast. 4 Others Power supply should be according to the rated capacity. Use the rated fuse and wire. Bulb socket shall be free from moisture or dirt. Do not apply the ballast severe shock, water, or extreme All parts should be serviced only at specified service centers. HID lamp should not be installed on other cars (Dangerous, fire may occur.) CAUTION: HID lamp shall not be used on other cars. (Fire may occur.) Fire may occur when HID lamp initially lights due to the fact that arc-discharge generates high voltage (max. 30, 000V) and high current (12-13A), and are different from the halogen lamp specification.
  3. Understanding of color change by replacement of HID bulb. The cause of HID color change. (Change of color is HID feature) The change of color occur during mixing three Elements in the HID bulb. Color Coordinates by Lifetime Chemical compounds in an arc tube: Xenon gas(an inert gas, protection of arc tube) Mercury(increase voltage, protection of arc tube, blue in the first 3 second) Metal halide Natrium(Yellow): 0.12mg Scandium(Blue): 0.06mg Iodine(Halogen): 0.02mg Change of Color by Lighting Up Time It needs 4 seconds at least for stabilization. At first, you can see the blue for 3 seconds because of Mercury. After stabilization, change of color occur by metal halide. 0 Hour: Yellow(Na is more than Sc.) 10 Hour: Bright Blue (Na and Sc are similar ratio.) 1000 Hour more: Blue (Sc is more than Na.) The end of lifetime: When HID used up Natrium and Scandium, a beam of light will be dark suddenly. so you can see the red, purple and turn on and off.
