Airbag Modules - Except Hev: Other Kia Optima III

Driver Airbag (DAB)

If any improper parts are found during the following inspection, replace the airbag module with a new one.

Scheme 11

1. Check pad cover for dents, cracks or deformities.
2. Check the airbag module for denting, cracking or deformation.
3. Check hooks and connectors for damage, terminals for deformities, and harness for binds.
4. Check airbag inflator case for dents, cracks or deformities.
5. Install the airbag module to the steering wheel to check for fit or alignment with the wheel.

Scheme 12

1. If, as a result of the following checks, even one abnormal point is discovered, replace the clock spring with a new one.
2. Check connectors and protective tube for damage, and terminals for deformities.

Scheme 13

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable from battery and wait for at least three minutes before beginning work.
3. Connect the clock spring harness connector and horn harness connector to the clock spring.
4. Set the center position by setting the marks between the clock spring and the cover into line. The marks should be matched by turning the clock spring clockwise to the stop and then 2.0 revolutions counterclockwise.
5. Install the steering wheel column shroud and the steering wheel. Refer to «STEERING COLUMN AND SHAFT»(ref-429546-S03884827802011101500000) .
6. Connect the Driver Airbag (DAB) module connector and horn connector, and then install the Driver Airbag (DAB) module on the steering wheel.
7. Connect the battery negative cable.
8. After installing the airbag, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off. Make sure horn button works.

Deploying Airbags In The Vehicle

If an SRS equipped vehicle is to be entirely scrapped, the airbags or side airbags should be deployed while still in the vehicle. The airbags or side airbags should not be considered as salvageable parts and should never be installed in another vehicle.

1. Turn the ignition switch OFF, and disconnect the battery negative cable and wait at least three minutes.
2. Confirm that each airbag or side airbag is securely mounted.
3. Confirm that the special tool is functioning properly by following the check procedure. Driver's Airbag : Remove the driver's airbag and install the SST (0957A-3Q100). Install the driver's airbag on the steering wheel. Front Passenger's Airbag : Remove the glove box housing, and then disconnect the connector between the front passenger's airbag and SRS main harness. Install the SST (0957A-2E110). Side Airbag : Disconnect the 2P connector between the side airbag and wire harness. Install the SST (0957A-3F100). Curtain Airbag : Disconnect the 2P connector between the curtain airbag and wire harness. Install the SST (0957A-3Q100). Seat Belt Pretensioner : Disconnect the 2P connector from the seat belt pretensioner. Install the SST (0957A-3Q100). Anchor Pretensioner : Disconnect the 2P connector from the anchor pretensioner. Install the SST (0957A-3Q100).
4. Place the deployment tool at least thirty feet (10 meters) away from the airbag.
5. Connect a 12 volt battery to the tool.
6. Push the tool's deployment switch. The airbag should deploy (deployment is both highly audible and visible: a loud noise and rapid inflation of the bag, followed by slow deflation)
7. Dispose of the complete airbag. No parts can be reused. Place it in a sturdy plastic bag and seal it securely.

Deploying The Airbag Out Of The Vehicle

If an intact airbag has been removed from a scrapped vehicle, or has been found defective or damage during transit, storage or service, it should be deployed as follows

1. Confirm that the special tool is functioning properly by following the check procedure.
2. Position the airbag facing up, outdoors on flat ground at least thirty feet (10 meters) from any obstacles or people.

Disposal Of Damaged Airbag

1. If installed in a vehicle, follow the removal procedure of driver's airbag, front passenger's and side airbag.
2. In all cases, make a short circuit by twisting together the two airbag inflator wires.
3. Package the airbag in exactly the same packing that the new replacement part came in.
