Air Conditioning System - Hev: Overview Kia Optima III

Scheme 268

1. R-134a liquid refrigerant is highly volatile. A drop on the skin of your hand could result in localized frostbite. When handling the refrigerant, be sure to wear gloves.
2. It is standard practice to wear goggles or glasses to protect your eyes, and gloves to protect your hands. If the refrigerant splashes into your eyes, wash them with clean water immediately.
3. The R-134a container is highly pressurized. Never leave it in a hot place, and check storage temperature is below 52°C (126°F).
4. An electronic leak detector should be used to check the system for refrigerant leakage. Bear in mind that the R-134a, upon coming into contact with flame, produces phosgene, a highly toxic gas.
5. Use only recommended lubricant for R-134a systems. If lubricants other than the recommended one used, system failure may occur.
6. PVE or POE lubricant absorbs moisture from the atmosphere at a rapid rate, therefore the following precautions must be observed: When removing refrigerant components from a vehicle, cap the components immediately to prevent entry of moisture. When installing refrigerant components to a vehicle, do not remove the cap until just before connecting the components. Complete the connection of all refrigerant tubes and hoses without delay to prevent the A/C system from taking on moisture. Use the recommended lubricant from a sealed container only.
7. Do not use the same A/C recovery / charging station as conventional belt-driven compressors.
8. Since the electric compressor uses high-voltage, you should use PVE or POE oil which have high Volumetric Resistivity. WARNING: If the PVE or POE oil of the system gets mixed with PAG oil, then dielectric breakdown due to decreased volumetric resistivity can occur and inoperative A/C compressor may result, A/C compressor may not work.
9. If an accidental discharge in the system occurs, ventilate the work area before resume of service.

Scheme 269

1. Never open or loosen a connection before discharging the system.
2. Seal the open fittings of components with a cap or plug immediately to prevent intrusion of moisture or dust.
3. Do not remove the sealing caps from a Replacement component until it is ready to be installed.
4. Before connecting an open fitting, always install a new sealing ring. Coat the fitting and seal with refrigerant oil before making the connection.

Oil Return Operation

There is close affinity between the oil and the refrigerant.

During normal operation, part of the oil recirculation with the refrigerant in the system. When checking the amount of oil in the system, or replacing any component of the system, the compressor must be run in advance for oil return operation. The procedure is as follows

1. Open all the doors and the engine hood.
2. Start the engine and air conditioning switch to "ON" and set the blower motor control knob at its highest position.
3. Run the compressor for more than 20 minutes between 800 and 1, 000 rpm in order to operate the system.
4. Stop the engine.

Scheme 270

Description

Through the development of electric compressors, fuel efficiency is improved and air conditioner can be implemented when the engine stopped.

A/C pressure transducer convert the pressure value of high pressure line into voltage value after measure it. By converted voltage value, engine ECU controls cooling fan by operating it high speed or low speed. Engine ECU stop the operation of compressor when the temperature of refrigerant line is so high or so low irregularly to optimize air conditioning system.

Scheme 271

Scheme 272

1. Measure the pressure of high pressure line by measuring voltage output between NO. 1 and NO. 2 terminals.
2. Inspect the voltage value whether it is sufficient to be regular value or not. Voltage = 0.00878835 * Pressure + 0.5[PSIA]
3. If the measured voltage value is not specification, replace the A/C pressure transducer.

Scheme 273

Scheme 274

1. Disconnect the negative (-) battery terminal.
2. Recover the refrigerant with a recovery/charging station.
3. Disconnect the A/C pressure transducer connector (3P) (A). Tightening torque: 10~12N.m (1.0~1.2kgf.m, 7.4~8.8lbf.ft) CAUTION: Take care that liquid & suction pipe are not bent.
4. Installation is the reverse order of removal.

The evaporator temperature sensor will detect the evaporator core temperature and interrupt compressor relay power in order to prevent evaporator freezing by excessive cooling

Scheme 275

1. Ignition "OFF"
2. Disconnect evaporator temperature sensor.
3. Using the multi-tester, Measure resistance between terminal "1" and "2" of evaporator temperature sensor. RESISTANCE SPECIFICATION Evaporator core temperature[°C(°F)] Resistance[Kohms] -10 43.35 0 27.62 10 18.07 20 12.11 30 8.3 40 5.81

Scheme 276

Scheme 277

1. Disconnect the negative (-) battery terminal.
2. Loosen the mounting screw and then remove the crash pad lower cover (A).
3. Remove the evaporator temperature sensor (A), by pulling it after rotating 90° in a counterclockwise direction.
4. Installation is the reverse order of removal.

1. The photo sensor is located at the right of defrost nozzle.
2. The photo sensor contains a photovoltaic (sensitive to sunlight) diode. The solar radiation received by its light receiving portion, generates an electromotive force in proportion to the amount of radiation received which is transferred to the automatic temperature control module so that the solar radiation compensation will be performed.

Scheme 278

1. Ignition "ON"
2. Using the scan tool.
3. Emit intensive light toward photo sensor using a lamp, and check the output voltage change.
4. The voltage will rise with higher intensive light and reduce with lower intensive light. Photo Sensor Connector Terminal Call-out 1. Auto Light Signal 5. Led GND (To BCM) 2. Auto Light Signal 6. Photo Signal (LH) 3. Photo Signal (RH) 7. Photo Power (SW) 4. Led power (BAT) 8. 5V (Vcc)

Scheme 279

1. Disconnect the negative (-) battery terminal.
2. With the (-) driver, remove the photo sensor (A) from the center of defrost nozzle.
3. Install in the reverse order of removal.

1. The ambient temperature sensor is located at the front of the condenser and detects ambient air temperature. It is a negative type thermistor; resistance will increase with lower temperature, and decrease with higher temperatures.
2. The sensor output will be used for discharge temperature control, temperature regulation door control, blower motor level control, mix mode control and in-car humidity control. NOTE: If the ambient temperature is below 0°C (32.0°F), the A/C compressor will be stopped. The compressor will be operated by manual operating.

Scheme 280

1. Ignition "OFF"
2. Disconnect ambient temperature sensor.
3. Check the resistance of ambient temperature sensor between terminals 1 and 2 whether it is changed by changing of the ambient temperature. Ambient Temperature Sensor Connector Terminal Call-out 1. Sensor Ground 2. Ambient Sensor Signal RESISTANCE SPECIFICATION Ambient temperature [°C(°F)] Resistance between terminals 1 and 2 (kohms) -30 (-22) 480.41 -20 (-4) 271.21 -10 (14) 158.18 0 (32) 95.10 10 (50) 58.80 20 (68) 37.32 30 (86) 23.76 40 (104) 16.13 50 (122) 10.95
4. If the measured resistance is not specification, substitute with a known-good ambient temperature sensor and check for proper operation.
5. If the problem is corrected, replace the ambient temperature sensor.

Scheme 281

Scheme 282

1. Disconnect the negative (-) battery terminal.
2. Loosen the mounting bolts and then remove the under cover (A).
3. Disconnect the connector and then remove the ambient temperature sensor (A).
4. Installation is the reverse order of removal.

Scheme 283

1. The function of cluster ion generator is cleaning air by sterilizing and dissolving of air conditioner.
2. The function of cluster ion generator is controlling mold caused by stench of air conditioner and external inflow of air.
