Air Conditioning System Diagnosis - Hev: Specifications Kia Optima III

Automatic HVAC System 47 illustrations ~3283 words

Specification

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3±0.15V
Max.warm4.7±0.15V

Scheme 348

Scheme 348: Diagnostic Circuit Diagram

Scheme 349

Scheme 349: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool. Perform Actuation Test for "Passenger Air Mix Door - 0% / 50% / 100%. With performing Actuation test, check that the value of Air Mix Door Potentiometer is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S18381979542013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S16946564512013031200000) " procedure.

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3±0.15V
Max.warm4.7±0.15V

Scheme 350

Scheme 350: Diagnostic Circuit Diagram

Scheme 351

Scheme 351: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool. Perform Actuation Test for "Passenger Air Mix Door - 0% / 50% / 100%. With performing Actuation test, check that the value of Air Mix Door Potentiometer is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S32656407432013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S19120099812013031200000) " procedure.

Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3±0.15V
REC4.7±0.15V

Scheme 352

Scheme 352: Diagnostic Circuit Diagram

Scheme 353

Scheme 353: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Intake Potentiometer" parameter on the current data with scantool Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S37032801822013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S33621651872013031200000) " procedure.

Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3±0.15V
REC4.7±0.15V

Scheme 354

Scheme 354: Diagnostic Circuit Diagram

Scheme 355

Scheme 355: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Intake Potentiometer" parameter on the current data with scantool Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S17239176392013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S03382009902013031200000) " procedure.

Resistance value of incar temp sensor as a function of temperature.

Temperature(°C/°F)Resistance(kohms)
20/-4285.6
10/14169
0/3297.7
10/5059.67
20/6837.4
30/8624.1
40/10415.9
50/12210.8

Scheme 356

Scheme 356: Diagnostic Circuit Diagram

Scheme 357

Scheme 357: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor 1" parameter.
  4. Is the Incar temperature sensor normal? YES This is a intermittent problem caused by poor contact of component or A/C Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S36535043712013031200000) " procedure. NO Substitute with a known good In-Car Temp. Sensor and check for proper operation. If the problem is corrected, replace In-Car Temp. Sensor and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S36535043712013031200000) " procedure.

Resistance value of incar temp sensor as a function of temperature.

Temperature(°C/°F)Resistance(kohms)
20/-4285.6
10/14169
0/3297.7
10/5059.67
20/6837.4
30/8624.1
40/10415.9
50/12210.8

Scheme 358

Scheme 358: Diagnostic Circuit Diagram

Scheme 359

Scheme 359: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor 1" parameter.
  4. Is the Incar temperature sensor normal? YES This is a intermittent problem caused by poor contact of component or A/C Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S42204823012013031200000) " procedure. NO Substitute with a known good In-Car Temp. Sensor and check for proper operation. If the problem is corrected, replace In-Car Temp. Sensor and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S42204823012013031200000) " procedure.

Resistance value of ambient temperature sensor as a function of temperature.

Temperature(°C/°F)Resistance(kohms)
20/-4271.4
0/3295.1
25/7730
50/12211
60/1407.58

Scheme 360

Scheme 360: Diagnostic Circuit Diagram

Scheme 361

Scheme 361: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-535806-S32229130172013031200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S02589345632013031200000) " procedure.

Resistance value of ambient temperature sensor as a function of temperature.

Temperature(°C/°F)Resistance(kohms)
20/-4271.4
0/3295.1
25/7730
50/12211
60/1407.58

Scheme 362

Scheme 362: Diagnostic Circuit Diagram

Scheme 363

Scheme 363: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-535806-S39680312712013031200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S03963819462013031200000) " procedure.

Resistance value of evaporator sensor as a function of temperature.

Temperature(°C/°F)Resistance(kohms)
10/-443.3
0/3227.6
10/5018
20/6812.1
30/868.3
40/1045.8

Scheme 364

Scheme 364: Diagnostic Circuit Diagram

Scheme 365

Scheme 365: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool.
  4. Is the Evaporator Sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-535806-S07555911552013031200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S36974917382013031200000) " procedure.

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3±0.15V
Max. warm4.7±0.15V

Scheme 366

Scheme 366: Diagnostic Circuit Diagram

Scheme 367

Scheme 367: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0% / 50% / 100% in order. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S11971028332013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S00459475692013031200000) " procedure.

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3±0.15V
Max. warm4.7±0.15V

Scheme 368

Scheme 368: Diagnostic Circuit Diagram

Scheme 369

Scheme 369: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0% / 50% / 100% in order. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S25971257992013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S08444108672013031200000) " procedure.

Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3±0.15V
BI-LEVEL1.4±0.4V
FLOOR2.5±0.4V
MIX3.6±0.4V
DEF4.7±0.15V

Scheme 370

Scheme 370: Diagnostic Circuit Diagram

Scheme 371

Scheme 371: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potentiometer" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face / Foot / Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S01712908772013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S15785656122013031200000) " procedure.

Resistance value of evaporator sensor as a function of temperature.

Temperature(°C/°F)Resistance(kohms)
10/-443.3
0/3227.6
10/5018
20/6812.1
30/868.3
40/1045.8

Scheme 372

Scheme 372: Diagnostic Circuit Diagram

Scheme 373

Scheme 373: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool.
  4. Is the Evaporator Sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-535806-S05028121682013031200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S24264566762013031200000) " procedure.

Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3±0.15V
BI-LEVEL1.4±0.4V
FLOOR2.5±0.4V
MIX3.6±0.4V
DEF4.7±0.15V

Scheme 374

Scheme 374: Diagnostic Circuit Diagram

Scheme 375

Scheme 375: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potentiometer" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face / Foot / Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S21766383952013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S08040139582013031200000) " procedure.

Hz of Defogger sensor according to Humidity

(%RH)(Hz)
037.19
2036.4
4035.6
6034.8
8034
10033.2

Scheme 376

Scheme 376: Diagnostic Circuit Diagram

Scheme 377

Scheme 377: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts.
  3. Select and monitor "Auto defogger humidity sensor" parameter on scantool.
  4. Is the defogger sensor normal? YES Go to " «INSPECTION & REPAIR»(ref-535806-S27677349602013031200000) " procedure. NO This may be a intermittent problem caused by poor contact of component or the Control Unit. Thoroughly check for looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S08629397582013031200000) " procedure.

Hz of Defogger sensor according to Humidity

(%RH)(Hz)
037.19
2036.4
4035.6
6034.8
8034
10033.2

Scheme 378

Scheme 378: Diagnostic Circuit Diagram

Scheme 379

Scheme 379: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Select and monitor "Auto defogger humidity sensor" parameter on scantool.
  4. Is the defogger sensor abnormal? YES Go to " «INSPECTION & REPAIR»(ref-535806-S30986726092013031200000) " procedure. NO This may be a intermittent problem caused by poor contact of component or the Control Unit. Thoroughly check for looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S03659186642013031200000) " procedure.

Voltage output according to Actuator position

Door positionVoltage
CLOSE(VENT, B/L)About 4.7V
FLOORAbout 3.94V
MIXAbout 3.29V
OPEN(DEF)About 1V

Scheme 380

Scheme 380: Diagnostic Circuit Diagram

Scheme 381

Scheme 381: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select and monitor "Auto defogger mode direction potentiometer" parameter on current data. Perform Actuation Test for "Auto Defogger Mode Door -0%(close)/50%/100%(open)" in order. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0%(close): About 90%, 50%: About 55%, 100%(open): About 20%. Does the value of auto defogger mode actuator follow the specification? YES This may be a intermittent problem caused by poor contact of component or the Control Unit. Thoroughly check for looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S39552435392013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S34748712772013031200000) " procedure.

Voltage output according to Actuator position

Door positionVoltage
CLOSE(VENT, B/L)About 4.7V
FLOORAbout 3.94V
MIXAbout 3.29V
OPEN(DEF)About 1V

Scheme 382

Scheme 382: Diagnostic Circuit Diagram

Scheme 383

Scheme 383: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select and monitor "Auto defogger mode direction potentiometer" parameter on current data. Perform Actuation Test for "Auto Defogger Mode Door -0%(close)/50%/100%(open)" in order. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0%(close): About 90%, 50%: About 55%, 100%(open): About 20%. Does the value of auto defogger mode actuator follow the specification? YES This may be a intermittent problem caused by poor contact of component or the Control Unit. Thoroughly check for looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S05042294362013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S21637571192013031200000) " procedure.

The voltage of auto defogger mode actuator in accordance with position

Door positionVoltage
CLOSE(VENT, B/L)About 4.7V
FLOORAbout 3.94V
MIXAbout 3.29V
OPEN(DEF)About 1V

Scheme 384

Scheme 384: Diagnostic Circuit Diagram

Scheme 385

Scheme 385: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select and monitor "Auto defogger mode actuator" parameter on current data. Perform Actuation Test for "auto defogger actuator -0%(close)/50%/100%(open)" in order. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0%(close): About 90%, 50%: About 55%, 100%(open): About 20%. Does the value of auto defogger mode actuator follow the specification? YES This may be a intermittent problem caused by poor contact of component or the Control Unit. Thoroughly check for looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Monitoring with a DVOM on min/max or VMI while wiggling connectors may help find the problem. Any change in voltage indicate a possible problem. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S36604747392013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S07872123142013031200000) " procedure.

In the HVAC water pump operating mode

Water pump relay sig.Water pump F/B
NormalGNDB+

Scheme 386

Scheme 386: Diagnostic Circuit Diagram

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3±0.15V
Max. warm4.7±0.15V

Scheme 387

Scheme 387: Diagnostic Circuit Diagram

Scheme 388

Scheme 388: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0% / 50% / 100% in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S28347860802013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S16742372552013031200000) " procedure.

Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3±0.15V
REC4.7±0.15V

Scheme 389

Scheme 389: Diagnostic Circuit Diagram

Scheme 390

Scheme 390: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Intake Potentiometer" parameter on the current data with scantool. Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S36706902112013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S26748973292013031200000) " procedure.

Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3±0.15V
BI-LEVEL1.4±0.4V
FLOOR2.5±0.4V
MIX3.6±0.4V
DEF4.7±0.15V

Scheme 391

Scheme 391: Diagnostic Circuit Diagram

Scheme 392

Scheme 392: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potention" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face / Foot / Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S01260488402013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S33769291632013031200000) " procedure.

Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3±0.15V
Max.warm4.7±0.15V

Scheme 393

Scheme 393: Diagnostic Circuit Diagram

Scheme 394

Scheme 394: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool. Perform Actuation Test for "Passenger Air Mix Door - 0% / 50% / 100% in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535806-S05399871602013031200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-535806-S07070921452013031200000) " procedure.
