Contents Section: Automatic Trans All sections

Troubleshooting: Specifications Kia Optima II рестайлинг

Automatic Trans 84 illustrations ~1463 words

Specification

TEMP. (°C)RESISTANCE (kohms)TEMP. (°C)RESISTANCE (kohms)
40 (40°F)139.580 (176°F)1.08
20 (4°F)47.7100 (212°F)0.63
0 (32°F)18.6120 (248°F)0.38
20 (68°F)8.1140 (284°F)0.25
40 (104°F)3.8160 (320°F)0.16
60 (140°F)1.98

TEMPERATURE RESISTANCE REFERENCE

Scheme 62

Scheme 62: Diagnostic Circuit Diagram

Scheme 63

Scheme 63: Monitor Scan Tool Data
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scan tool. Specification: Increasing Gradually
  4. Does "TRANSAXLE OIL TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S15085896222010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S17340962542010042200000) " procedure.
TEMP. (°C)RESISTANCE (kohms)TEMP. (°C)RESISTANCE (kohms)
40 (40°F)139.580 (176°F)1.08
20 (4°F)47.7100 (212°F)0.63
0 (32°F)18.6120 (248°F)0.38
20 (68°F)8.1140 (284°F)0.25
40 (104°F)3.8160 (320°F)0.16
60 (140°F)1.98

TEMPERATURE RESISTANCE REFERENCE

Scheme 64

Scheme 64: Diagnostic Circuit Diagram

Scheme 65

Scheme 65: Monitor Scan Tool Data
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scan tool. Specification: Increasing Gradually
  4. Does "TRANSAXLE OIL TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S20512177932010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S20306722392010042200000) " procedure.

Input shaft & Output shaft speed sensor

  1. Type: Hall sensor
  2. Current consumption: 22mA (MAX)
  3. Sensor body and sensor connector have been unified as one.

Scheme 66

Scheme 66: Diagnostic Circuit Diagram

Scheme 67

Scheme 67

Scheme 68

Scheme 68: Signal Waveform & Data

Scheme 69

Scheme 69

Scheme 70

Scheme 70: Monitor Scan Tool Data

Scheme 71

Scheme 71

Scheme 72

Scheme 72

Scheme 73

Scheme 73

Scheme 74

Scheme 74

Scheme 75

Scheme 75
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "INPUT SPEED SENSOR" parameter on the scan tool
  4. Driving at speed of over 19 Mile/h (30 Km/h) Specification: Increasing Gradually
  5. Does "Input Speed Sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S01848476592010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S31409756852010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms @ 68°F (20°C)
  5. Surge voltage: 56 V

Scheme 76

Scheme 76: Diagnostic Circuit Diagram

Scheme 77

Scheme 77

Scheme 78

Scheme 78: Signal Waveform & Data

Scheme 79

Scheme 79: Monitor Scan Tool Data

Scheme 80

Scheme 80

Scheme 81

Scheme 81

Scheme 82

Scheme 82

Scheme 83

Scheme 83

Scheme 84

Scheme 84
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TCC SOL. VALVE" parameter on the scan tool
  4. Select "D RANGE" and Operate "TCC SOLENOID DUTY" more than 80%
  5. Does "TCC SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S23150001112010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S05131251992010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms (68°F or 20°C)
  5. Surge voltage: 56 V

Scheme 85

Scheme 85: Diagnostic Circuit Diagram

Scheme 86

Scheme 86

Scheme 87

Scheme 87: Signal Waveform & Data

Scheme 88

Scheme 88: Monitor Scan Tool Data

Scheme 89

Scheme 89

Scheme 90

Scheme 90

Scheme 91

Scheme 91

Scheme 92

Scheme 92

Scheme 93

Scheme 93

Scheme 94

Scheme 94
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "PRESS CONTROL SOL. VALVE" parameter on the scan tool.
  4. Shift gear at each position.
  5. Does "PRESS CONTROL SOL DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S22408260282010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S22256714762010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms(68°F or 20°C)
  5. Surge voltage: 56 V

Scheme 95

Scheme 95: Diagnostic Circuit Diagram

Scheme 96

Scheme 96

Scheme 97

Scheme 97: Signal Waveform & Data

Scheme 98

Scheme 98: Monitor Scan Tool Data

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102

Scheme 103

Scheme 103

Scheme 104

Scheme 104

Scheme 105

Scheme 105
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "LR SOL. VALVE" parameter on the scan tool
  4. Shift gear position.
  5. Does "LR SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S08909875852010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S16706982482010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms(68°F or 20°C)
  5. Surge voltage: 56 V

Scheme 106

Scheme 106: Diagnostic Circuit Diagram

Scheme 107

Scheme 107

Scheme 108

Scheme 108: Signal Waveform & Data

Scheme 109

Scheme 109: Monitor Scan Tool Data

Scheme 110

Scheme 110

Scheme 111

Scheme 111

Scheme 112

Scheme 112

Scheme 113

Scheme 113

Scheme 114

Scheme 114

Scheme 115

Scheme 115
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "UD SOL. VALVE" parameter on the scan tool
  4. Shift gear position.
  5. Does "UD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S05632435352010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S28214330852010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms (68°F or 20°C)
  5. Surge voltage: 56 V

Scheme 116

Scheme 116: Diagnostic Circuit Diagram

Scheme 117

Scheme 117

Scheme 118

Scheme 118: Signal Waveform & Data

Scheme 119

Scheme 119: Monitor Scan Tool Data

Scheme 120

Scheme 120

Scheme 121

Scheme 121

Scheme 122

Scheme 122

Scheme 123

Scheme 123

Scheme 124

Scheme 124

Scheme 125

Scheme 125
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "2nd SOL. VALVE" parameter on the scan tool.
  4. Shift gear position.
  5. Does "2nd SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S40449428312010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S36291206922010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms(68°F or 20°C)
  5. Surge voltage: 56 V

Scheme 126

Scheme 126: Diagnostic Circuit Diagram

Scheme 127

Scheme 127

Scheme 128

Scheme 128: Signal Waveform & Data

Scheme 129

Scheme 129

Scheme 130

Scheme 130: Monitor Scan Tool Data

Scheme 131

Scheme 131

Scheme 132

Scheme 132

Scheme 133

Scheme 133

Scheme 134

Scheme 134

Scheme 135

Scheme 135
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "OD SOL. VALVE" parameter on the scan tool.
  4. Shift gear position.
  5. Does "OD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S01572835262010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S30163862392010042200000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type: Normal open 3-way
  2. Operating temperature: -22°F to 266°F (-30°C to 130°C)
  3. Frequency: LR, 2ND, UD, OD, RED: 61.27Hz (at the ATF temp. -20°C above) DCC: 30.64Hz KM series: 35Hz
  4. Internal resistance: 2.7-3.4ohms (68°F or 20°C)
  5. Surge voltage: 56 V

Scheme 136

Scheme 136: Diagnostic Circuit Diagram

Scheme 137

Scheme 137

Scheme 138

Scheme 138: Signal Waveform & Data

Scheme 139

Scheme 139: Monitor Scan Tool Data

Scheme 140

Scheme 140

Scheme 141

Scheme 141

Scheme 142

Scheme 142

Scheme 143

Scheme 143

Scheme 144

Scheme 144

Scheme 145

Scheme 145
  1. Connect scan tool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "RED SOL. VALVE" parameter on the scan tool
  4. Shift gear position
  5. Is "RED SOLENOID DUTY" within specifications? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM) connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-359938-S42359734242010042200000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-359938-S33716434192010042200000) " procedure.
