INSPECTION CHART FOR DIAGNOSIS TROUBLE CODES (DTC)

[2.4 GSL]

No.CodeItemMILRemark
1P0707TRANSAXLE RANGE SWITCH CIRCUIT LOW INPUTON
2P0708TRANSAXLE RANGE SWITCH CIRCUIT HIGH INPUTON
3P0711TRANSAXLE FLUID TEMPERATURE SENSOR RATIONALITYON
4P0712TRANSAXLE FLUID TEMPERATURE SENSOR CIRCUIT LOW INPUTON
5P0713TRANSAXLE FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUTON
6P0717A/T INPUT SPEED SENSOR CIRCUIT - OPEN or SHORT(GND)ON
7P0721AT OUTPUT SPEED SENSOR FAILON
8P0722AT OUTPUT SPEED SENSOR CIRCUIT - OPEN or SHORT(GND)ON
9P0731GEAR 1 INCORRECT RATIOON
10P0732GEAR 2 INCORRECT RATIOON
11P0733GEAR 3 INCORRECT RATIOON
12P0734GEAR 4 INCORRECT RATIOON
13P0735GEAR 5 INCORRECT RATIOON
14P0741TORQUE CONVERTER CLUTCH STUCK OFFON
15P0743TORQUE CONVERTER CLUTCH CONTROL SOLENOID VALVE - OPEN or SHORT (GND)ON
16P0748VFS SOLENOIDOFF
17P0750LOW and REVERSE SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
18P0755UNDER DRIVE SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
19P0760SECOND SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
20P0765OVERDRIVE SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
21P0770RED SOLENOIDON
22P0885A/T CONTROL RELAY - OPEN or SHORT(GND)ON
23U0001CAN communication BUS OFFON
24U0100No ID from ECUON

INSPECTION CHART

[2.7 GSL]

No.CodeItemMILRemark
1P0707TRANSAXLE RANGE SWITCH CIRCUIT LOW INPUTON
2P0708TRANSAXLE RANGE SWITCH CIRCUIT HIGH INPUTON
3P0711TRANSAXLE FLUID TEMPERATURE SENSOR RATIONALITY1ON
4P0712TRANSAXLE FLUID TEMPERATURE SENSOR CIRCUIT LOW INPUTON
5P0713TRANSAXLE FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUTON
6P0717A/T INPUT SPEED SENSOR CIRCUIT - OPEN or SHORT(GND)ON
7P0722AT OUTPUT SPEED SENSOR CIRCUIT - OPEN or SHORT(GND)ON
8P0731GEAR 1 INCORRECT RATIOON
9P0732GEAR 2 INCORRECT RATIOON
10P0733GEAR 3 INCORRECT RATIOON
11P0734GEAR 4 INCORRECT RATIOON
12P0735GEAR 5 INCORRECT RATIOON
13P0741TORQUE CONVERTER CLUTCH STUCK OFFON
14P0742TORQUE CONVERTER CLUTCH STUCK ONON
15P0743TORQUE CONVERTER CLUTCH CONTROL SOLENOID VALVE - OPEN or SHORT (GND)ON
16P0748VFS SOLENOIDOFF
17P0750LOW and REVERSE SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
18P0755UNDER DRIVE SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
19P0760SECOND SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
20P0765OVERDRIVE SOLENOID VALVE CIRCUIT - OPEN or SHORT(GND)ON
21P0770RED SOLENOIDON
22P0885A/T CONTROL RELAY - OPEN or SHORT(GND)ON
23P0890TCM power Relay sense circuit lowON
24P0891TCM power Relay sense circuit HighON

INSPECTION CHART

Scheme 3

Scheme 3: INPUT/OUTPUT SIGNAL VOLTAGE CHECK SHEET
PIN No.Check itemConditionInput/Output valueMeasurement ValueRemarks
TypeLevel
A012nd CAN_HI
A022nd CAN_LO
A03P Range SelectionP Position OtherwiseDC VoltageV_BAT Max. 1.0V12.9V 0V
A04R Range SelectionR Position OtherwiseDC VoltageV_BAT Max. 1.0V12.3V 0V
A05N Range SelectionN Position OtherwiseDC VoltageV_BAT Max. 1.0V13.2V 0V
A06D Range SelectionD Position OtherwiseDC VoltageV_BAT Max. 1.0V13.2V 0V
A07Select PositionDC VoltageV_BAT Max. 1.0V13.2V 0V
A08Up PositionDC VoltageV_BAT Max. 1.0V13.2V 0V
A09Down PositionDC VoltageV_BAT Max. 1.0V13.2V 0V
A12N.A
A14N.A
A19N.A
A20A/T Control RelayRelay On Relay OffDC VoltageV_BAT Max. 1.0V Vpeak : Max. 70V Resistance : 680ohms13.8V 0V -0.7V Resistance : 680ohms
W/H OpenDTC Spec : P0890DTC : P0890
A27Diagnosis "K"Communicated with GSTPulseAt transmitting HI : V_BAT* 80%↑ LO : V_BAT* 20%↓ AT receiving HI : V_BAT* 70%↑ LO : V_BAT*30%↓11.3V 0.14/0.32VV_BAT : 13.2V
A31N.A
A32A/C Pressure Analog
A34N.A
A36N.A
A37N.A
A41CAN_HIRecessive DominantPulse2.0 ~ 3.0 V 2.75 ~ 4.5 V3.85V 2.5V
A42CAN_LORecessive DominantPulse2.0 ~ 3.0 V 0.5 ~ 2.25 V2.55V 1.34V
A60A/T PWR SourceIG Off IG On IG. Key On IG. Key Off Idle Key Off from Idle Fuse 1/2/3 Removal ConditionDC VoltageMax. 0.5 V V_BAT MAX. +/- 75V (ECU GND) MAX. +/- 75V (ECU GND) MAX. +/- 75V (ECU GND) MAX. +/- 75V (ECU GND) MAX. +/- 75V (ECU GND)0V 11.9V +30V/-10V or less ↑
W/H OpenDTC Spec : P0888DTC : P0888
A73Shift Position Signal(To Cluster)Running 1 gear 2 gear 3 gear 4 gear 5 gearPulse Duty ↑ ↑ ↑ ↑HI : V_BAT LO : Max. 1.0V Freq.: 50±2Hz (Reference) 12.5±2% 27.5±2% 42.5±2% 57.5±2% 72.5±2%N.ASports mode
B03UD SolenoidShiftingPulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V14.4V 0.35V 56.3V
W/H OpenDTC Spec : P0755DTC : P0755
B05N.A
B06Oil temperature sensor_ATMIdleAnalog0.5V ~ 4.5V4.4V 3.1V16Hz
B09Output speed sensor30kphPulseHI : Min. 4.0V LO : Max. 1.0V5.08V 0.34V
W/H OpenDTC Spec : P0722DTC : P0722
B10Input speed sensorIdlePulseHI : Min. 4.0V LO : Max. 1.0V5.06V 0.35V630Hz
W/H OpenDTC Spec : P0717DTC : P0717
B20N.A
B22LR SolenoidShiftingPulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V13.9V 0.38V 56.1V
W/H OpenDTC Spec : P0750DTC : P0750
B26N.A
B27N.A
B33GND_SensorIdleDC VoltageMax. 50 mV13mVWTS & OTS_ATM
W/H OpenDTC Spec : P0118/1115DTC : P0118/P1115
B42OD SolenoidShiftingPulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V15.4V 0.45V 56.3V
W/H OpenDTC Spec : P0765DTC : P0765
B43DCC solenoidLock_Up onPulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V15.4V 0.45V 56.3V
W/H OpenDTC Spec : P0743DTC : P0743
B44RED SolenoidShiftingPulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V15.4V 0.45V 56.3V
W/H OpenDTC Spec : P0770DTC : P0770
B452ND SolenoidShiftingPulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V15.4V 0.45V 56.3V
W/H OpenDTC Spec : P0760DTC : P0760
B46N.A
B47N.A
B59Variable Solenoid (-)IdlePulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V1.8/1.2V - N range 0.03V(DC) - D range600Hz
W/H OpenDTC Spec : P0748DTC : P0748
B65N.A
B66N.A
B75Variable Solenoid (+)IdlePulseHI : V_BAT LO : Max. 1.0V Vpeak : Max. 70V13.1V -0.07V
W/H OpenDTC Spec : P0748DTC : P0748
B80N.A

CONNECTOR REFERENCE

INSPECTION

  1. Drive the vehicle until the fluid reaches normal operating temperature [70~80°C].
  2. Place the vehicle on a level surface.
  3. Move the selector lever through all gear positions. This will fill the torque converter and the hydraulic system with fluid and move the selector lever to the "N" (Neutral) or "P"(Park) position.
  4. Before removing the oil level gauge, wipe all contaminants from around the oil level gauge. Then take out the oil level gauge and check the condition of the fluid. NOTE: If the fluid smells as if it is burning, it means that the fluid has been contaminated by fine particles from the bushes and friction materials, a transaxle overhaul may be necessary.
  5. Check that the fluid level is at the HOT mark on the oil level gauge. If the fluid level is low, add automatic transaxle fluid until the level reaches the "HOT" mark. Auto transaxle fluid: DIAMOND ATF SP-III, SK ATF SP-III Quantity : 9.5 l NOTE: Low fluid level can cause a variety of a abnormal conditions because it allows the pump to take in air along with fluid. Air trapped in the hydraulic system forms bubbles, which are compressable. Therefore, pressures will be erratic, causing delayed shifting, slipping clutches and brakes, etc. Improper filling can also raise fluid level too high. When the transaxle has too much fluid, gears churn up foam and cause the same conditions which occur with low fluid level, resulting in accelerated deterioration of automatic transaxle fluid. In either case, air bubbles can cause overheating, and fluid oxidation, which can interfere with normal valve, clutch, and brake operation. Foaming can also result in fluid escaping from the transaxle vent where it may be mistaken for a leak.
  6. Insert the oil level gauge securely.

Note. When new, automatic transmission fluid should be red. The red dye is added so the assembly plant can identify it as transmission fluid and distinguish it from engine oil or antifreeze. The red dye, which is not an indicator of fluid quality, is not permanent. As the vehicle is driven the transmission fluid will begin to look darker. The color may eventually appear light brown.
