Automatic Transaxle System: Removal & Installation Kia Optima II рестайлинг

REPLACEMENT

If you have a fluid changer, use this changer to replace the fluid. If you do not, replace it using the following procedure.

Scheme 4

1. Disconnect the hose which connects the transmission and the oil cooler which is within the radiator only in 2.4L engine(3.3L-the oil cooler is separated).
2. Start the engine and let the fluid drain out. Running conditions : "N" range with engine idling. CAUTION: The engine should be stopped within one minute after it is started. If the fluid has all drained out before then, the engine should be stopped at that point.
3. Remove the drain plug(A) from the bottom of the transmission case to drain the fluid.
4. Install the drain plug using a new gasket, and tighten it to the specified torque. TORQUE : 40 ~ 50Nm (400 ~ 500 kgf.cm, 29 ~ 36 lb-ft)
5. Pour the new fluid in through the oil filler tube. CAUTION: Stop pouring if the full volume of fluid cannot be poured in.
6. Repeat the procedure in step (2). NOTE: Check the old fluid for contamination. If it has been contaminated, repeat steps 5 and 6 .
7. Pour the new fluid in through the oil filler tube.
8. Reconnect the hose which was disconnected in step (1) above and firmly replace the oil level gauge.(In case of this "replace", this means after wiping off any dirt around the oil level gauge, insert it into the filler tube.)
9. Start the engine and run it at idle for 1~2 minutes.
10. Move the select lever through all positions, and then move it to the "N" position.
11. Drive the vehicle until the fluid temperature rises to the normal temperature (70~80°C), and then check the fluid level again. The fluid level must be at the HOT mark.
12. Firmly insert the oil level gauge into the oil filler tube.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Drain automatic transaxle fluid.
2. Disconnect the negative terminal(B) from the battery(A).
3. Remove the engine cover(A).
4. After disconnecting the AFS connector(A) and removing the air cleaner upper body(B), take the air cleaner filter out of the air cleaner under body.
5. After disconnecting the PCM connectors(B), remove the air cleaner under body(A).
6. Remove the battery tray(A).
7. Remove the transaxle oil cooler hoses(A) releasing the clamps.
8. Disconnect the ground wire(A).
9. Disconnect the connectors related to the transaxle. Disconnect the solenoid valve connector(A). Disconnect the inhibitor switch connector(A). Disconnect the input speed sensor connector(A). Disconnect the output speed sensor connector(A). Disconnect the vehicle speed sensor connector(A).
10. Disconnect the control cable by removing the nut(A).
11. After removing the front wheels and tires and lifting up the vehicle, remove the under cover(A).
12. Drain power steering fluid. (Refer to «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
13. Remove the pressure tube from the power steering oil pump. (Refer to «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
14. After releasing the power steering hose clamp(A), disconnect the hose with the tube. CAUTION: Clamp or plug the power steering hose to avoid excessive fluid loss. When re-connecting, remove the clamp or hose plug and check power steering reservoir fluid level.
15. Remove the exhaust pipe. (See «INTAKE AND EXHAUST SYSTEM - 2.4L»(ref-357429) or «INTAKE AND EXHAUST SYSTEM - 2.7L»(ref-359924) )
16. Remove the lower arm assembly and tie rod mounting bolts. (See «FRONT SUSPENSION SYSTEM»(ref-357455) / «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
17. Supporting the sub frame with a jack, remove the sub frame mounting bolts. (See «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
18. After loosening the steering column bolt and lowering a jack, remove the sub frame. (See «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
19. Lowering the vehicle down, remove the transaxle upper mounting bolts(A).
20. Using the SST(09200-38001), support the engine and transaxle assembly safely.
21. Remove the transaxle insulator mounting bolt(A).
22. Remove the starter. (See «STARTING SYSTEM - 2.4L»(ref-357434) or «STARTING SYSTEM - 2.7L»(ref-359930) )
23. Remove the bolts(B-4EA) which connect the drive plate with the torque converter.
24. Remove the inner shaft mounting bolts and take the drive shafts off the transaxle assembly. (See «DRIVESHAFT ASSEMBLY»(ref-357451) )
25. After supporting the transaxle with a jack and removing the under mounting bolts(A).

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Lifting up the transaxle slowly with a jack, tighten the under mounting bolts(A) TORQUE : Ø 2.4L 43~55 Nm(430~550 kgf.cm, 31.3~39.8 lb-ft) - A [2EA] 43~49 Nm(430~490 kgf.cm, 31.3~35.6 lb-ft) - C [4EA] μ 2.7L 80~100 Nm(800~1000 kgf.cm, 57.9~72.3 lb-ft) - A [2EA] 40~47 Nm(400~470 kgf.cm, 29.0~34.1 lb-ft) - C [4EA] CAUTION: Take care not to damage the power steering hoses.
2. Insert the drive shafts into the transaxle. (See «DRIVESHAFT ASSEMBLY»(ref-357451) )
3. Install the inner shaft mounting bolts(2EA). (See «DRIVESHAFT ASSEMBLY»(ref-357451) ) TORQUE: 50~65 Nm(500~650 kgf.cm, 36.2~47.0 lb-ft)
4. Apply grease on the threaded part of the bolts(B-4EA) which connect the drive plate with the torque converter and tighten them. TORQUE: 46~53 Nm(460~530 kgf.cm, 33.3~38.3 lb-ft) - B
5. Install the starter. (See «STARTING SYSTEM - 2.4L»(ref-357434) or «STARTING SYSTEM - 2.7L»(ref-359930) )
6. Tighten the transaxle insulator mounting bolt(A). TORQUE: 65~85 Nm(650~850 kgf.cm, 47.0~61.5 lb-ft)
7. Tighten the transaxle upper mounting bolts(A). TORQUE : Ø 2.4L 43~55 Nm(430~550 kgf.cm, 31.3~39.8 lb-ft) - A [4EA] μ 2.7L 65~85 Nm(650~850 kgf.cm, 47.0~61.5 lb-ft) - A [4EA]
8. Lifting up the sub frame with a jack, tighten the steering column bolt. (See «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
9. Tighten the sub frame mounting bolts. (See «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
10. Install the lower arm assembly and the steering bar tie rod mounting bolts. (See «FRONT SUSPENSION SYSTEM»(ref-357455) / «HYDRAULIC POWER STEERING SYSTEM»(ref-357462) )
11. Install the front exhaust pipe. (See «INTAKE AND EXHAUST SYSTEM - 2.4L»(ref-357429) or «INTAKE AND EXHAUST SYSTEM - 2.7L»(ref-359924) )
12. Clamp the power steering hose(A).
13. Install the under cover(A).
14. Connect the transaxle wire harness connectors. Connect the solenoid valve connector(A). Connect the inhibitor switch connector(A). Connect the input speed sensor connector(A). Connect the output speed sensor connector(A). Connect the vehicle speed sensor connector(A).
15. Connect the ground wire(A).
16. Connect the control cable(A) by installing the nut.
17. Clamp the transaxle oil cooler hoses(A).
18. Install the battery tray(A).
19. Install the air cleaner under body(A) and connect the PCM connectors(B).
20. Reassemble the air cleaner filter, install the air cleaner upper body(B) and connect the air flow sensor connector(A).
21. After installing the battery(A), connect the positive terminal(B) to the battery.
22. Install the engine cover(A).

Scheme 44

Note. Refill power steering fluid and bleed the power steering system. (Refer to ) Refill automatic transaxle fluid. (Refer to ' SERVICE ADJUSTMENT PROCEDURE ')

Note. When replacing the automatic transaxle, reset the automatic transaxle's values by using the High-Scan Pro.

Scheme 45

Scheme 46

1. Connect the Hi-Scan Pro connector to the data link connector under the crash pad and power cable to the cigar jack under the center facia.
2. Turn the ignition switch on and power on the Hi-Scan Pro.
3. Select the vehicle's name.
4. Select 'AUTOMATIC TRANSAXLE'.
5. Select 'RESETTING AUTO T/A VALUES' and perform the procedure.
6. Perform the procedure by pressing F1 (REST).

Scheme 47
