Blower: Overview Kia Optima II рестайлинг

Scheme 49

Scheme 50

Scheme 51

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad.(Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) )
3. Disconnect the connectors from the fresh and recirculation actuator, the blower motor and power mosfet.
4. Remove the cowl cross bar assembly.(Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) )
5. Remove the blower unit (B) from the heater unit after loosening a mounting bolt and 3 screws. NOTE: Make sure that there is no air leaking out of the blower and duct joints.
6. Installation is the reverse order of removal.

Scheme 52

Scheme 53

1. Connect the battery voltage and check the blower motor rotation.
2. If the blower motor voltage is not operating properly well, substitute with a known-good blower motor and check for proper operation.
3. If the problem is corrected, replace the blower motor.

Scheme 54

Scheme 55

1. Disconnect the negative (-) battery terminal.
2. Disconnect the connector (A) of the blower motor.
3. Remove the blower motor (A) after loosening the mounting screws.
4. Installation is the reverse order of removal.

Scheme 56

Scheme 57

1. Ignition "ON".
2. Manually operate the control switch and measure the voltage of blower motor between pin 1 and 2.
3. Select the control switch to raise voltage until high speed. Specification SPECIFICATION CHART Fan Motor Voltage Manual First speed 3.8 ± 0.5V Second speed 4.9 ± 0.5V Third speed 6.1 ± 0.5V Fourth speed 7.2 ± 0.5V Fifth speed 8.3 ± 0.5V Sixth speed 9.5 ± 0.5V Seventh speed 10.6 ± 0.5V eighth speed Battery(+) AUTO COOLING : Auto speed (4.5V~B+) AUTO HEATING : Auto speed (4.5V~10.5V)
4. If the measured voltage is not specification, substitute with a known-good power mosfet and check for proper operation.
5. If the problem is corrected, replace the power mosfet.

Scheme 58

1. Disconnect the negative (-) battery terminal.
2. Disconnect the power mosfet connector (A) at the connecting part between heater and blower unit.
3. Remove the power mosfet (B) after loosening the mounting screws.
4. Installation is the reverse order of removal.

DESCRIPTION

The A/C air filter is designed to reduce particulate and odor entry through the climate control system.

Scheme 59

Scheme 60

1. Remove the glove box(A) from the lift(B).
2. Open the glove box (B). Lower the glove box down completely by removing the glove box stopper (A) to the glove box.
3. Remove the filter cover (A) by pressing the clips inward. Take care not to damage the clips.
4. Replace the air filter (B). The installation direction is marked on the filter.

Scheme 61

Note. In case of driving in an air-polluted area or rugged terrain, check and replace the air filter as frequently as possible.

Replacement period : 15,000 km (9320 mile)

Scheme 62

1. The intake actuator is located at the blower unit.
2. It regulates the intake door by signal from control unit.
3. Pressing the intake selection switch will shift between recirculation and fresh air modes.

Scheme 63

1. Ignition "OFF".
2. Disconnect the intake actuator connector.
3. Verify that the intake actuator operates to the fresh position when connecting 12V to the terminal 3 and grounding terminal 4.
4. Verify that the intake actuator operates to the recirculation position when connecting in the reverse.
5. If the intake actuator is not operated well, substitute with a known-good intake actuator and check for proper operation.
6. If the problem is corrected, replace the intake actuator.

Scheme 64

1. Disconnect the negative (-) battery terminal.
2. Remove the glove box (Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) ).
3. Disconnect the intake actuator connector.
4. Loosen the mounting screw and then remove the intake actuator (A) from the blower unit.
5. Installation is the reverse order of removal.

Scheme 65
