SRS Control System: Removal & Installation Kia Optima II

Airbag 3 illustrations ~293 words

REMOVAL

CAUTIONRemoval of the airbag must be performed according to the precautions/procedures described previously. Before disconnecting the front impact sensor connector, disconnect the front airbag connector(s). Do not turn the ignition switch ON and do not connect the battery cable while replacing the front impact sensor.

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the front bumper. (Refer to «FRONT BUMPER»(ref-266056-S09773572352007092700000) ).
  3. Disconnect the Front Impact Sensor connector.
  4. Remove the Front Impact Sensor mounting bolt and sensor bracket cover.
  5. Remove the Front Impact Sensor.

INSTALLATION

CAUTIONDo not turn the ignition switch ON and do not contact the battery cable while replacing the front impact sensor.
  1. Install the new Front Impact Sensor and sensor bracket cover.
  2. Tighten the Front Impact Sensor mounting bolt. Tightening torque : 1.0-1.4 kgf.m (10.2-13.8 Nm, 7.5-10.2 lb.ft)
  3. Install the front bumper. (Refer to «FRONT BUMPER»(ref-266056-S09773572352007092700000) ).
  4. Reconnect the battery negative cable.
  5. After installing the Front Impact Sensor, confirm proper system operation: Turn the ignition switch ON the SRS indicator light should be turned on for about six seconds and then go off.
CAUTIONEnsure that the harness is installed and routed properly to prevent damage to the wiring.
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the ignition key from the vehicle.
  3. Install the seat belt buckle switch. Tightening Torque: 4.0-5.5 kgf.m (28.9-39.8 lb.ft)
  4. Install the seat recliner cover with two screws.
  5. Install the front seat assembly. (Refer to «SEAT»(ref-266054) article ).
  6. Reconnect the battery negative cable.
  7. After installing the Seat Belt Buckle Switch, confirm proper system operation: Turn the ignition switch ON, the SRS indicator should be turned on for about six seconds and then go off.
CAUTIONEnsure that the harness is installed and routed properly to prevent damage to the wiring.

Scheme 28

Scheme 28
Scheme 28
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the ignition key from the vehicle.
  3. Install the STPS with two screws.
  4. Install the front seat assembly. (Refer to «SEAT»(ref-266054) article ).
  5. Reconnect the battery negative cable.
  6. After installing the Seat Track Position Sensor, confirm proper system operation: Turn the ignition switch ON, the SRS indicator should be turned on for about six seconds and then go off.
