Air Bag Module (Driver Side): Overview Kia Optima II

Airbag 4 illustrations ~133 words

DESCRIPTION

Driver Airbag (DAB) is installed in steering wheel and electrically connected to SRSCM via clockspring. It protects the driver from danger by deploying a bag when frontal crash occurs. The SRSCM determines deployment of Driver Airbag (DAB).

CAUTIONNever attempt to measure the circuit resistance of the airbag module (squib) with an ohmmeter. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 4

Scheme 4: COMPONENTS
Scheme 4: COMPONENTS

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
  2. Remove the airbag module mounting bolts(2EA).
  3. Disconnect the horn connector(A).
  4. Release the connector locking pin, then disconnect the driver airbag module connector(B). CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover face up.
  5. Remove the steering wheel and steering wheel column cover. (Refer to «REMOVAL»(ref-266035-S17660488742007092700000) )
  6. Disconnect the clock spring and horn connector, then remove the clock spring.
