Air Bag Module (Passenger Side): Overview Kia Optima II

Airbag 2 illustrations ~148 words

DESCRIPTION

The passenger Airbag (PAB) is installed inside the crash pad and protects the front passenger in the event of a frontal crash. The SRSCM determines if and when to deploy the PAB.

CAUTIONNever attempt to measure the circuit resistance of the airbag module (squib) with an ohmmeter. If the circuit resistance is measured with a tester, accidental airbag deployment will result in serious personal injury.

Scheme 11

Scheme 11: COMPONENTS
Scheme 11: COMPONENTS

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL
  1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
  2. Remove the glove box. (Refer to «INTERIOR - OPTIMA & MAGENTIS (CANADIAN)»(ref-266048) )
  3. Disconnect the PAB connector and remove the PAB mounting bolts (2EA).
  4. Remove the crash pad. (Refer to «INTERIOR - OPTIMA & MAGENTIS (CANADIAN)»(ref-266048) ) NOTE: Replace the damaged crash pad with PAB when the PAB is deployed.
  5. Remove the heater duct from the crash pad.
  6. Remove the mounting nuts(6EA) from the crash pad. Then remove the passenger airbag. CAUTION: The removed airbag module should be stored in a clean and dry place with the cushion side up.
