INSTALLATION
Installation is the reverse of removal.
Tighten glass mounting nuts to 4~6 N.m (40~60 kg.cm, 35~52 lb. in).
Tighten sunroof mounting bolts to 7~11 N.m (70~110 kg.cm, 61~95 lb. in).
Tighten sunroof mounting nuts to 4~6 N.m (40~60 kg.cm, 35~52 lb. in).
Note. Check that the limit switches (LS1 and LS2) of the motor are at the fully closed position. Align the guide roller center and slider mating mark at the fully closed position.
Illustrating Limit Switches. Scheme 12
Illustrating Guide Roller. Scheme 13
Scheme 14
Scheme 15
- If the glass panel movement is difficult, check and adjust. Make sure the battery voltage is normal. Make sure that the sunroof sliding unit is free of foreign material. Make sure that, when the glass panel opens, the rear position of panel dose not interfere with the roof panel. NOTE: If the stopper is moved forward too far, it may cause malfunction or leaks. Make sure the gap between the glass panel and roof panel is not more than 0.3 mm. Measure the driving force of the motor, and adjust it to 15~25 kg (33.1~55.7 lb) with the torque adjustment nut on the motor. To measure, use the deep hole in the center of the lid lower panel. After adjustment, be sure to lock the nut with the pawl washer. (Scheme 14): Measuring The Driving Force Of The Motor (Scheme 15): Locking Nut With Pawl Washer
Scheme 16
Scheme 17
Scheme 18
- Adjust the difference between the height of the glass panel and the roof panel. Front side: -1~0 mm Rear side: 0~1 mm (Scheme 16): Illustrating Glass Height
- If the difference is not as specific, adjust using the following procedure. Loosen the front screw and rear screw and adjust the height between the glass panel and roof panel. Loosen the glass panel mounting nuts and adjust the gap between the glass panel and roof panel. (Scheme 17): Illustrating Glass Panel Height (Scheme 18): Adjusting Glass Height
