Sunroof: Diagnosis Kia Optima I

INSPECTION OF COMPONENTS

Check for continuity between the terminals. If the continuity is not as specified, replace the relay.

Scheme 9

Scheme 10

1. Remove the overhead console lamp. (Scheme 9): Removing Overhead Console Lamp
2. Disconnect the motor connector from sun roof harness.
3. Apply 12V to the terminal 2 and ground the terminal 6. (Scheme 10): Checking Sunroof Motor Operation
4. Check that the motor turns.
5. Reverse the connections and check that the motor turns in the opposite direction.

Illustrating Roof Trim Components. Scheme 11
