Sunroof: Overview Kia Optima I

Scheme 1

Scheme 2

1. Operate the switch and check for the continuity between the terminals.
2. If the continuity is not as specified, replace the switch. (Scheme 1): Identifying Sunroof Switch Connector Terminals (Scheme 2): Checking Sunroof Continuity

DESCRIPTION AND OPERATION

Headliner is a cloth cushion that serves as a buffer between passengers and top of vehicle. It also covers thermal and acoustic insulation in top of vehicle and wiring for room lamp. Both headliner and insulation are replaceable.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Unscrew two mounting screws from sun visors.
2. Remove sun visors and sun visors retaining clips. (Scheme 3): Removing Sun Visors
3. Remove assist handle covers, unscrew mounting screws.
4. Remove three assist handles.
5. Gently remove lens assembly on interior and map light.
6. Remove light bulb.
7. Remove two mounting screws.
8. Disconnect power connector and remove interior and map light. (Scheme 4): Removing Interior And Map Light
9. Remove A, B and C-pillar trims.
10. Remove seven fasteners.
11. Remove headliner. (Scheme 5): Removing Headliner
12. Remove glass panel. (Scheme 6): Removing Glass Panel
13. Disconnect the drain hose. (Scheme 7): Disconnecting The Drain Hose
14. Remove the sunroof mounting bolts and nuts, and remove the sunroof assembly. (Scheme 8): Removing The Sunroof Assembly NOTE: When removing the sunroof assembly, carefully pull out the sunroof assembly to avoid damage to the other parts.
