Wiper/washer System: Removal & Installation Kia Optima I

INSTALLATION

1. Install two bolts on wiper motor and link assembly.
2. Connect wiper motor harness connector.
3. Place cowl vent in position and install nuts and fasteners.
4. Install wiper arms and blades. see scheme 2
5. Check system movement. Wiper arms should stop 1.18 inch (30 mm) (Driver side) and 1.46 inch (37 mm) (Passenger side) from lower windshield edge.

1. Install in reverse order of removal.
2. Connect nozzle to neoprene hose.
3. Face nozzle exit toward windshield and push in place on hood.

Scheme 10

1. Spray should center on driver and passenger sides of front windshield. If off-line, adjust by slightly turning the nozzle. (Scheme 10): Adjusting Spray Area
2. If clogged or restricted, use a needle or wire to clear nozzle exit.
