DESCRIPTION
Chrysler LLC uses international symbols to identify various systems on the vehicle.
The graphic symbols illustrated are used to identify various instrument controls, vehicle controls and service information references. The symbols correspond to the controls and displays that are located on the instrument panel and throughout the vehicle.
Scheme 1
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|
| 1 | 115-Volt Power Inverter | 11 | Side Airbag |
| 2 | USB Connector | 12 | Seat Belt |
| 3 | Lighter | 13 | Airbag |
| 4 | Fuel Fill Side | 14 | Supplemental Restraint System |
| 5 | Spare Tire Winch | 15 | Power Steering Fluid |
| 6 | Fuse | 16 | See Owner's Manual |
| 7 | Key Activate (Power Outlet) | 17 | See Appropriate Service Information |
| 8 | Warning | 18 | Emergency Release Handle |
| 9 | Child Seat Tether Anchor | 19 | Jack/Jack Tools Location |
| 10 | Lower Anchors and Tether for Children (latch) |
INTERNATIONAL INFORMATION SYMBOL IDENTIFICATION
Scheme 2
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|
| 1 | Electronic Speed Control | 26 | Front Fog Light |
| 2 | Hill Descent Control | 27 | Rear Fog Light |
| 3 | Traction Control | 28 | Cargo Lamp |
| 4 | Electronic Stability Program/Brake System Assist System | 29 | Exterior Bulb Failure |
| 5 | Security Indicator | 30 | Door Ajar |
| 6 | Turn Signals | 31 | Liftgate Open |
| 7 | Water In Fuel | 32 | Brake System Warning Parking Brake |
| 8 | Low Fuel | 33 | All Wheel Drive |
| 9 | Side Airbag | 34 | Four Wheel Drive |
| 10 | Seat Belt Reminder | 35 | Four Wheel Drive Low |
| 11 | Airbag Warning Light | 36 | Tow/Haul |
| 12 | Passenger Airbag Off | 37 | Service Four Wheel Drive |
| 13 | Failure Of Anti-Lock Braking System | 38 | Service Four Wheel Drive |
| 14 | HEV Brake Regenerative Light | 39 | Cruise Indicator |
| 15 | Electronic Throttle Control | 40 | Brake System Warning Parking Brake |
| 16 | HEV Service Light | 41 | Tire Pressure Monitor |
| 17 | Engine Oil | 42 | Sway Bar Disconnect Indicator |
| 18 | Battery Charging | 43 | Front Axle Lock |
| 19 | Glow Plug/Intake Air Heated | 44 | Rear Axle Lock |
| 20 | Power Steering Fluid | 45 | Park Assist Indicator |
| 21 | Engine Coolant Temperature | 46 | Park Brake Indicator |
| 22 | Malfunction Indicator Light | 47 | Electronic Stability Control/Traction Control Off |
| 23 | Transmission Oil Temperature Light | 48 | Trailer Brake System Off |
| 24 | Diesel Exhaust Brake | 49 | |
| 25 | High Beam | 50 |
INTERNATIONAL INDICATOR SYMBOL IDENTIFICATION
Scheme 3
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|---|---|
| 1 | Rear Window Wiper | 26 | Passenger Air Bag Off | 51 | Door Ajar |
| 2 | Rear Window Intermittent Wiper | 27 | Electronic Speed Control | 52 | Liftgate Release |
| 3 | Rear Window Washer | 28 | Cruise Indicator | 53 | Sliding Door |
| 4 | Rear Window Defrost | 29 | Hill Descent Control | 54 | Sliding Door |
| 5 | Heated Mirror | 30 | Park Assist Off | 55 | Convertible Top Down |
| 6 | Turn Signals | 31 | Electronic Stability Program/Brake System Assist System | 56 | Convertible Top Up |
| 7 | Adjustable Pedals | 32 | Park Brake Release | 57 | Door Lock |
| 8 | Horn | 33 | Adjustable Headlights | 58 | Window Lift |
| 9 | Windshield Wiper Intermittent | 34 | Low Beam | 59 | Convertible 4 Window Down |
| 10 | Windshield Washer | 35 | Front Fog Light | 60 | Window Lock |
| 11 | Windshield Washer Fluid Level | 36 | Rear Fog Light | 61 | Power Rear Window |
| 12 | Windshield Electrically Heated | 37 | Cargo Lamp | 62 | Voice Recognition Button |
| 13 | Windshield Defrost | 38 | Hazard Lights | 63 | Uconnect™ Button |
| 14 | Windshield Wiper And Washer | 39 | 115-Volt Power Inverter | 64 | SwayBar Disconnect |
| 15 | Ventilating Fan | 40 | Key Activate (Power Outlet) | 65 | All Wheel Drive |
| 16 | Air Conditioning | 41 | Exterior Bulb Failure | 66 | Four Wheel Drive |
| 17 | Upper Air Outlet | 42 | Master Lighting Switch | 67 | Two Wheel Drive |
| 18 | Upper And Lower Air Outlet | 43 | Dome Light | 68 | Four Wheel Drive Low |
| 19 | Lower Air Outlet | 44 | Park Lights | 69 | Four Wheel Drive Lock |
| 20 | Defrost And Lower Air Outlet | 45 | Instrument Panel Illumination | 70 | Four Wheel Drive Auto |
| 21 | Heated Seat Low | 46 | Electronic Stability Program Off | 71 | Front Axle Lock |
| 22 | Heated Seat High | 47 | Diesel Exhaust Brake | 72 | Rear Axle Lock |
| 23 | Ventilated Seat | 48 | Overdrive Off | 73 | EVIC Menu |
| 24 | Recirculation | 49 | Hood Release | 74 | Navigation Button |
| 25 | Heated Steering Wheel | 50 | Trunk/Deck Release | 75 | Step |
| 76 | Reset | 77 | Axle Lock Button | 78 | Traction Control Off |
| 79 | Electronic Stability Control Off | 80 | Trailer Brakes |
INTERNATIONAL CONTROL SYMBOL IDENTIFICATION
Scheme 4
The graphic symbols illustrated are used to identify engine compartment lubricant and fluid inspection and fill locations. The symbols correspond to the caps located within the engine compartment.
Scheme 5
| 1 - VECI LABEL (CANADIAN) |
|---|
| 2 - VECI LABEL |
| 3 - HOOD |
Note. The Vehicle Emission Control Information (VECI) label(s) must be in place for the life of the vehicle. When replacing the component in which the VECI label is adhered, a new VECI label must also be adhered to the new component.
All vehicles are equipped with a combined VECI label(s). The label is located in the engine compartment on the vehicle hood. Two labels are used for vehicles built for sale in the country of Canada.
The VECI label(s) contain the following
- Engine family and displacement
- Evaporative family
- Certification application
- Spark plug and gap
Scheme 6
A vehicle certification label is attached to every Chrysler LLC vehicle. The label certifies that the vehicle conforms to all applicable Federal Motor Vehicle Standards. The label also lists
- Month and year of vehicle manufacture.
- Gross Vehicle Weight Rating (GVWR). The gross front and rear axle weight ratings (GAWR's) are based on a minimum rim size and maximum cold tire inflation pressure.
- Vehicle Identification Number (VIN).
- Type of vehicle.
- Type of rear wheels.
- Bar code.
- Month, Day and Hour (MDH) of final assembly.
- Paint and Trim codes.
- Country of origin.
The label is located on the driver-side door shut-face.
Scheme 7
The Vehicle Identification Number (VIN) label (1) is attached to the top left side of the instrument panel. The VIN contains 17 characters that provide data concerning the vehicle. Refer to the decoding chart below to determine the identification of a vehicle.
To protect the consumer from theft and possible fraud the manufacturer is required to include a Check Digit at the ninth position of the Vehicle Identification Number. The check digit is used by the manufacturer and government agencies to verify the authenticity of the vehicle and official documentation. The formula to use the check digit is not released to the general public.
| POSITION | INTERPRETATION | CODE = DESCRIPTION |
|---|---|---|
| 1, 2, 3 | WMI (World Manufacturer Identifier) | 1J4 = Chrysler LLC |
| 4 | Gross Vehicle Weight Rating | Active Belts (ASP) Front Air Bags (OSP) Without Side Inflatable Restraints |
| C = 2722 - 3175 kg (6001 - 7000 lbs) | ||
| Active Belts (ASP) Front Air Bags (OSP) With Side Inflatable Restraints All Rows | ||
| J = 2722 - 3175 kg (6001 - 7000 lbs) | ||
| R = 2722 - 3175 kg (6001 - 7000 lbs) | ||
| 5 | Vehicle Line (WK) | S = Grand Cherokee Left Hand Drive (4x2) |
| R = Grand Cherokee Left Hand Drive (4x4) | ||
| 2 = Grand Cherokee Right Hand Drive (4x4) | ||
| 6 | Series | 4 = Grand Cherokee Laredo |
| 5 = Grand Cherokee Limited | ||
| 6 = Grand Cherokee Overland | ||
| 7 | Body Style | G = Sport Utility 4 Door |
| 8 | Engine | G = 3.6L 6 CYL Gasoline Non -Turbo (EZH) |
| T = 5.7L 8 CYL Gasoline Non - Turbo (ERB) | ||
| 9 | Check Digit | 0 through 9 or X |
| 10 | Model Year | B = 2011 |
| 11 | Assembly Plant | C = Jefferson North Assembly |
| 12 thru 17 | Vehicle Build Sequence | 6 Digit Number Assigned by Assembly Plant |
VEHICLE IDENTIFICATION NUMBER DECODING CHART
