Lamps/lighting - Interior - Service Information Jeep Grand Cherokee WK2

WARNING

DESCRIPTION

The interior lighting system for this vehicle includes both incandescent and Light Emitting Diode (LED) unit lighting on several separate circuits. The lamps in the interior lighting system include

1. Center Floor Console Cup Holder Lamp - The cup holders in the center floor console include a standard equipment light pipe around their inside perimeter illuminated by an LED lamp unit to assist visibility at night. This lamp is controlled by the panel lamps dimmer circuit and illuminates whenever the exterior lighting is turned ON.
2. Center Floor Console Forward Storage Bin Lamp - The forward storage bin in the center floor console on some models is illuminated by an LED lamp unit located in the overhead console to assist visibility at night. This lamp is controlled by the panel lamps dimmer circuit and illuminates whenever the exterior lighting is turned ON.
3. Center Floor Console Universal Serial Bus Connector Lamp - The Universal Serial Bus (USB) connector in the center floor console on some models includes an LED lamp unit to assist visibility at night. This lamp is controlled by the courtesy lamp circuit and illuminates whenever the interior courtesy lamps are turned ON.
4. Courtesy Lamps - Standard incandescent courtesy lamps are located under the right and left ends of the instrument panel, and are controlled by the courtesy lamp circuit.
5. Glove Box Lamp - A standard incandescent glove box lamp with an integral plunger-actuated switch is located on the upper outboard corner of the glove box housing of the instrument panel and illuminates whenever the glove box is opened.
6. Liftgate Lamp - Two standard incandescent liftgate lamps are located in the lower corners of the liftgate trim panel and are activated automatically whenever the liftgate is opened to illuminate the rear cargo area of the vehicle.
7. Front Dome Lamps - Front seat driver side and passenger side incandescent dome lamps are located behind a lens shared with the LED map/reading lamps in the overhead console. The dome lamps are controlled by the courtesy lamp circuit and by independent lens-actuated switches.
8. Front Door Inside Remote Latch Handle Lamps - Front door trim panel inside remote latch handles on some models include an LED lamp unit to assist visibility at night. These lamps are controlled by the panel lamps dimmer circuit and illuminate whenever the exterior lighting is turned ON.
9. Front Door Map Pocket Lamps - Front door trim panel map pockets on some models include an LED lamp unit to assist visibility at night. These lamps are controlled by the panel lamps dimmer circuit and illuminate whenever the exterior lighting is turned ON.
10. Front Map/Reading Lamps - Front seat driver side and passenger side LED map/reading lamps are located behind a lens shared with the incandescent dome lamps in the overhead console. The map/reading lamps are controlled by the courtesy lamp circuit and by independent push button switches in the overhead console.
11. Rear Dome/Reading Lamps - The standard incandescent rear dome/reading lamps are controlled by both the courtesy lamp circuit and independent lens-actuated switches. These lamps are integral to the grab handles located on the roof side rail adjacent to each outboard rear seating position.
12. Rechargeable Flashlight - A removable twin-LED flashlight powered by rechargeable lithium batteries is mounted in a bezel/charging station located in the left quarter trim panel near the D-pillar in the cargo area of the vehicle.
13. Vanity Lamps - An optional single intensity, incandescent vanity lamp is located on each side of a covered mirror on both the right and left sun visors, and is controlled by an integral vanity mirror cover-actuated switch.

Most controls on the instrument panel and elsewhere in the interior of the vehicle are illuminated by the panel lamps dimmer circuit for night visibility. All have miniature incandescent bulbs, Light-Emitting Diode (LED) units or a combination of the two lighting types that are soldered to internal circuit boards and are not serviceable.

Other components of the interior lighting system for this vehicle include

1. Door Ajar Switches - A door ajar switch is integral to the door latch mechanism of each front and rear door.
2. Flip-Up Glass Ajar Switch - A flip-up glass ajar switch is integral to the flip-up glass latch mechanism on the top of the lower flip-up glass opening in the liftgate inner panel.
3. Headlamp Switch - A headlamp switch is located on the left side of the instrument panel, below and outboard of the steering column. The headlamp switch includes a thumbwheel for selecting the panel lamps dimming level and for interior lighting control. A PARADE position of the thumbwheel illuminates all display units at full brightness for visibility when driving in daylight with the exterior lighting turned ON. There are also detent positions to turn ON all interior courtesy lighting, and a DEFEAT position that overrides door ajar switch control of interior lighting. Refer to «SWITCH, HEADLAMP , DESCRIPTION»(/jeep/grand-cherokee/wk2-2010-2013/remont/exterior-lights/#lampslighting-exterior-service-information) .
4. Instrument Cluster - The ElectroMechanical Instrument Cluster (EMIC) is also known as the Cab Compartment Node (CCN) in this vehicle. The EMIC/CCN is located in the instrument panel above the steering column opening, directly in front of the driver. Refer to «DESCRIPTION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#instrument-cluster-service-information__description) .
5. Liftgate Ajar Switch - A liftgate ajar switch is integral to the latch mechanism of the liftgate.
6. Totally Integrated Power Module - The Totally Integrated Power Module (TIPM) is located in the engine compartment. Refer to «DESCRIPTION»(/jeep/grand-cherokee/wk2-2010-2013/remont/body-electrical/#power-distribution__description) .

Hard wired circuitry connects the interior lighting system components to the electrical system of the vehicle. These hard wired circuits are integral to several wire harnesses, which are routed throughout the vehicle and retained by many different methods. These circuits may be connected to each other, to the vehicle electrical system and to the interior lighting components through the use of a combination of soldered splices, splice block connectors, and many different types of wire harness terminal connectors and insulators. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, further details on wire harness routing and retention, as well as pin-out and location views for the various wire harness connectors, splices and grounds.

OPERATION

The lamps of the interior lighting system can be divided into general classifications based upon the circuit that controls their operation: The courtesy lamp circuit, the reading lamps circuit and the panel lamps dimmer circuit. Following are paragraphs that briefly describe the operation of the courtesy lamps, reading lamps and panel lamps dimmer interior lighting circuits.

The lamps and the hard wired circuits between components related to the interior lighting system may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the interior lighting system or the electronic controls or communication between modules and other devices that provide some features of the interior lighting system. The most reliable, efficient, and accurate means to diagnose the interior lighting system or the electronic controls and communication related to interior lighting system operation requires the use of a diagnostic scan tool. Refer to the appropriate Diagnostic information.

COURTESY LAMP CIRCUIT

The courtesy lamp circuit includes the courtesy lamps located under each outboard end of the instrument panel and, depending upon the selected vehicle options may include either the dome or map and reading lamps located in the overhead console near the windshield and on the roof rails adjacent to the rear outboard seating positions, the liftgate lamps located near each lower corner of the liftgate trim panel, the glove box lamp in the top of the glove box opening in the instrument panel and the vanity lamps located in the sun visors.

The lamps in the courtesy lamp circuit are provided with a path to ground at all times. The ElectroMechanical Instrument Cluster (EMIC) (also known as the Cab Compartment Node/CCN) controls the output of battery voltage for the courtesy lamps in this circuit based upon hard wired inputs from the headlamp switch and electronic message inputs from the ignition switch (also known as the Wireless Ignition Node/WIN) and the Totally Integrated Power Module (TIPM).

After all of the ajar switch inputs to the TIPM transition to open and the EMIC receives the appropriate electronic ajar switch status messages from the TIPM over the Controller Area Network (CAN) data bus, the EMIC will keep the courtesy lamps illuminated for about 30 seconds, then fade the lamps to OFF (theater dimming) over about 3 seconds. The EMIC also provides courtesy lamp operation based upon a resistor multiplexed input from the interior lighting thumbwheel on the headlamp switch, and provides an Illuminated Entry feature in response to certain electronic ignition switch status message inputs received from the WIN and the Occupant Restraint Controller (ORC) over the CAN data bus. A resistor multiplexed courtesy lamp DEFEAT input from the interior lighting thumbwheel of the headlamp switch will cause the EMIC to override normal courtesy lamp operation.

The EMIC provides a battery saver (load shedding) feature for all courtesy lamps, which will automatically turn these lamps OFF if they are left ON for more than about 10 minutes after the electronic ignition switch status message transitions to OFF. If any courtesy lamp input is received subsequent to a 10 minute load shed and prior to a new ignition cycle, the courtesy lamps will turn OFF after 90 seconds.

READING LAMP CIRCUIT

For those lamps on the courtesy lamp circuit with independent switching such as the reading lamps, the optional vanity lamps and the glove box lamp, the EMIC also provides a battery voltage output to those switches through a separate reading lamp circuit. The EMIC provides a battery saver (load shedding) feature for the reading lamp circuit as well as the courtesy lamp circuit, which will automatically turn these lamps OFF if they are left ON for more than about 10 minutes after the electronic ignition switch status message transitions to OFF. If any reading lamp input is received subsequent to a 10 minute load shed and prior to a new ignition cycle, the reading lamps will turn OFF after 90 seconds.

PANEL LAMPS DIMMER CIRCUIT

The panel lamps dimmer circuit actually includes several circuits. These circuits control the back lighting illumination and dimming level of the headlamp switch, the heater-air conditioner controls, the instrument panel switch pod, the four-wheel drive selector switch, the automatic transmission gear selector bezel lamp, the front door map pocket and remote inside handle lamps, as well as the center floor console cup holder and forward storage compartment lamps. All lamps in the panel lamps dimmer circuits are provided a path to ground at all times through a hard wired ground circuit. These lamps are illuminated by a 12-volt Pulse Width Modulated (PWM) output of the EMIC through several panel lamps dimmer circuits.

This shared PWM output synchronizes the selected illumination intensity level of all the lamps in the panel lamps dimmer circuits. The EMIC uses hard wired inputs from the rotary exterior lighting control knob and interior lighting thumbwheel of the headlamp switch to determine when the exterior lighting is turned ON and the dimming level selection. Then the EMIC provides the appropriate PWM outputs through the panel lamps dimmer circuits as well as electronic dimming level messages over the CAN data bus to other electronic modules in the vehicle.

The EMIC, the instrument panel switch pod and the radio use the electronic dimming level messages to control the illumination intensity of their own back lighting, controls and display units. In addition, when the interior lighting thumbwheel of the headlamp switch is moved to the PARADE (or funeral) mode detent position, all of the electronic display units are illuminated at their full intensity levels for increased visibility when the vehicle is driven during daylight hours with the exterior lighting turned ON. The PARADE mode has no effect on the illumination intensity of incandescent panel lamps.

DIAGNOSIS AND TESTING

Note. When diagnosing the interior lighting circuits, remember that high generator output can burn out bulbs rapidly and repeatedly; and, that dim or flickering bulbs can be caused by low generator output or poor battery condition. If one of these symptoms is a problem on the vehicle, be certain to diagnose the battery and charging system, then repair as necessary.

Note. A good ground is necessary for proper lighting operation. If a lighting problem is being diagnosed that involves multiple symptoms, systems, or components, the problem can often be traced to a loose, corroded, or open ground.

The hard wired circuits between components related to the operation of the interior lighting system may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the interior lighting system or the electronic controls or communication between modules and other devices that provide some features of the interior lighting system. The most reliable, efficient, and accurate means to diagnose the interior lighting system or the electronic controls and communication related to interior lighting system operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

COURTESY AND READING LAMP CIRCUITS

Note. As part of the exterior lighting fail-safe feature, upon ignition ON all of the panel lamps dimmer circuit lamps will illuminate at full intensity and the exterior park lamps and headlamp low beams will illuminate regardless of the headlamp switch position if the instrument cluster cannot detect an input from the headlamp switch, or if there is a loss of data bus communication.

COURTESY LAMPS

BULB APPLICATION TABLE

TORQUE SPECIFICATIONS

PANEL LAMPS

Note. All illuminated controls on the instrument panel and elsewhere in the interior of the vehicle have either miniature incandescent bulbs or Light-Emitting Diode (LED) units that are soldered to internal circuit boards and are not serviceable.

Scheme 1

A removable and rechargeable flashlight (3) is encased within a molded plastic housing, which is secured within a bezel/charging station (2) at the back of the left quarter inner trim panel (1) by two tabs on the end opposite the clear flashlight lens and a push-push type latch mechanism. The flashlight is powered by a rechargeable and replaceable lithium battery. A momentary switch on the flashlight electronic circuit board is actuated by a plastic push button located on the side of the flashlight housing. When the flashlight is turned ON it illuminates two clear Light Emitting Diode (LED) units to create a wide and bright light beam. A red LED unit on the side of the flashlight housing behind the push button illuminates as the battery becomes discharged to indicate that the unit requires recharging.

The bezel/charging station unit, the flashlight battery and the flashlight unit are each available for separate service replacement. If any other component of the flashlight or bezel/charging station are damaged or ineffective, the complete flashlight unit or bezel/charging station unit must be replaced.

The rechargeable lithium battery within the flashlight automatically recharges while the flashlight is nested in its receptacle within the bezel charging station and the engine is running. The flashlight has a pair of electrical contacts that mate with contacts within the charging station that provide a source of recharging current. The red Light Emitting Diode (LED) unit on the side of the flashlight behind the ON-OFF push button illuminates when the charge of the flashlight battery is becoming depleted.

The flashlight is removed from the bezel/charging station by pushing it momentarily at the depression marked PUSH on the flashlight housing, then releasing it and swinging it downward far enough to disengage two slots on the lower end of the flashlight from two tabs within the charging station. When the flashlight is removed from its receptacle in the bezel/charging station, it can be used as an auxiliary light source in emergencies or other situations where a portable light source is required. The flashlight is turned ON or OFF by momentarily depressing and releasing the ON-OFF push button on the side of the flashlight housing. Reverse the removal procedure to restore the flashlight to the bezel/charging station and to recharge the flashlight battery.

Scheme 2

Scheme 3

1. Insert a small screwdriver or another suitable tool into each of the two notches (2) between the upper (1) and lower (3) case halves of the flashlight and use a twisting action to separate the case.
2. Remove the lower case (4) from the upper case (3) and set it aside.
3. Lightly lift the latch tab (2) at the back of the upper case and slide the battery (1) rearward far enough to remove it from the case.
4. Install the new battery by sliding it between the latch tab and the case until it is engaged by the latch tab. The battery must be installed with the positive ( + ) terminal oriented toward the upper case (3).

Scheme 4

1. Disconnect and isolate the battery negative cable.
2. Pull the rear of the left quarter trim panel (2) away from the D-pillar far enough to access the back of the bezel/charging station (1). Refer to «PANEL, QUARTER TRIM , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
3. Disconnect the body wire harness connector (4) from the connector receptacle on the back of the bezel/charging station.
4. Compress the spring clip retainers (3) far enough to allow the bezel/charging station to be pushed out of the mounting hole through the face of the quarter trim panel. Six spring clip retainers are used, three on the forward side and three on the rearward side of the unit.
5. Remove the bezel/charging station from the vehicle.

BEZEL/CHARGING STATION

1. Align the bezel/charging station (1) with the mounting hole near the rear of the left quarter trim panel (2).
2. Using hand pressure, push the bezel/charging station into the mounting hole firmly and evenly until all 6 of the spring clip retainers (3) snap into place on the back side of the trim panel.
3. Reconnect the body wire harness connector (4) to the connector receptacle on the back of the bezel/charging station.
4. Reinstall the left quarter trim panel. Refer to «PANEL, QUARTER TRIM , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
5. Reconnect the battery negative cable.

BULB

Scheme 5

Scheme 6

1. Disconnect and isolate the battery negative cable.
2. Support the courtesy lamp housing (1) with one hand while grasping the flange on the outer circumference of the lens (3) with the other hand, then pull the lens straight down to unsnap it from the housing.
3. Pull the base of the bulb (2) straight out of the socket in the courtesy lamp housing (1).

1. Disconnect and isolate the battery negative cable.
2. Remove the screw that secures the integral mounting bracket of the courtesy lamp (1) to the lower instrument panel (2).
3. Pull the courtesy lamp unit down from the lower instrument panel far enough to access and disconnect the instrument panel wire harness from the connector receptacle on the top of the lamp housing.
4. Remove the courtesy lamp from under the instrument panel.

1. Align the base of the bulb (2) with the socket in the courtesy lamp housing (1).
2. Push the bulb straight into the socket until the base is firmly seated.
3. Align the courtesy lamp lens (3) with the lamp housing (1).
4. Support the courtesy lamp housing with one hand while firmly and evenly pushing the lens into the housing with the other hand, until the lens snaps into place.
5. Reconnect the battery negative cable.

1. Position the courtesy lamp (1) under the instrument panel (2).
2. Reconnect the instrument panel wire harness to the connector receptacle on the top of the courtesy lamp housing.
3. Position the integral mounting bracket of the lamp to the lower instrument panel.
4. Install and tighten the screw that secures the lamp to the instrument panel. Tighten the screw to 2 N.m (17 in. lbs.).
5. Reconnect the battery negative cable.

Scheme 7

1. Disconnect and isolate the battery negative cable.
2. Remove the lamp (3) from the liftgate trim panel. Refer to «LAMP, COURTESY , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/interiorillumination-lights/#lampslighting-interior-service-information) «LAMP, COURTESY, LIFTGATE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/interiorillumination-lights/#lampslighting-interior-service-information) .
3. Using a small thin-bladed screwdriver, gently pry the latch features of the lamp lens (5) away from the lamp housing and remove the lens from the housing.
4. Pull the base of the bulb (4) straight out of the bulb holder within the lamp housing.

Scheme 8

1. Disconnect and isolate the battery negative cable.
2. Remove the trim (1) from the liftgate inner panel. Refer to «PANEL, TRIM , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
3. Pull the trim away from the liftgate inner panel far enough to access and disconnect the wire harness connector (3) from the back of the liftgate lamp housing (2).
4. From the back of the trim panel, compress the latch features on the outside of the lamp housing and push the lamp out through the mounting hole toward the face of the panel.
5. Remove the liftgate lamp from the vehicle.

1. Align the base of the bulb (4) with the bulb holder within the liftgate lamp housing (3).
2. Push the bulb into the holder until the base is fully seated.
3. Align the lens (5) to the lamp housing.
4. Using hand pressure, press firmly and evenly on the lens until it snaps into place over the lamp housing.
5. Reinstall the lamp into the liftgate trim panel (1). Refer to «LAMP, COURTESY , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/interiorillumination-lights/#lampslighting-interior-service-information) «LAMP, COURTESY, LIFTGATE , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/interiorillumination-lights/#lampslighting-interior-service-information) .
6. Reconnect the battery negative cable.

1. Align the liftgate lamp (2) to the mounting hole in the face of the liftgate trim panel (1).
2. Using hand pressure, press the lamp firmly and evenly into the mounting hole until the lamp latch features snap into place.
3. Reconnect the wire harness connector (3) to the back of the lamp housing.
4. Reinstall the trim onto the liftgate inner panel. Refer to «PANEL, TRIM , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
5. Reconnect the battery negative cable.

Scheme 9

Note. The front dome and the front map/reading lamps are integral to the overhead console (1) in the headliner near the windshield. Both the incandescent dome lamps and the Light Emitting Diode (LED) map/reading lamps share the same two lenses (2) in the overhead console. Both the dome lamps and the map/reading lamps are turned ON and OFF by the door ajar switches or by the interior lighting thumbwheel of the headlamp switch. The front dome lamps can be turned ON independently by depressing the lamp lenses, while the front map/reading lamps are turned ON or OFF independently by the two map/reading lamp push button switches (3). The incandescent dome lamp bulbs are serviceable; however, the LED map/reading lamps as well as all of the switches, lamp housings, lenses and wiring are serviced only as a unit with the overhead console assembly.

Scheme 10

1. Disconnect and isolate the battery negative cable.
2. Remove the overhead console from the headliner, but do not disconnect it. Refer to «CONSOLE, OVERHEAD, FRONT , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
3. Reach above the top of the over head console (1) to access and rotate the bulb and bulb holder unit (2) counterclockwise about 30 degrees to unlock it from the keyed opening in the lamp housing.
4. Pull the bulb holder and bulb straight out of the housing.

Scheme 11

Note. The rear dome/reading lamps are integral to the grab handle (1) in the headliner on the inner roof side rail over each outboard rear seating position. The lamp housing, switch and wiring are serviced only as a unit with the grab handle assembly.

Scheme 12

1. Disconnect and isolate the battery negative cable.
2. Using a small thin-bladed screwdriver, gently pry the forward end of the reading lamp lens (2) away from the grab handle far enough to unsnap it from the lamp housing.
3. Pull the front end of the lens outward far enough to disengage the larger rear lens tab from the lamp housing.
4. Pull the base of the bulb (1) straight forward out of the bulb holders (2) within the lamp housing.

BULB - FRONT

Note. The front dome and the front map/reading lamps are integral to the overhead console (1) in the headliner near the windshield. Both the incandescent dome lamps and the Light Emitting Diode (LED) map/reading lamps share the same two lenses (2) in the overhead console. Both the dome lamps and the map/reading lamps are turned ON and OFF by the door ajar switches or by the interior lighting thumbwheel of the headlamp switch. The front dome lamps can be turned ON independently by depressing the lamp lenses, while the front map/reading lamps are turned ON or OFF independently by the two map/reading lamp push button switches (3). The incandescent dome lamp bulbs are serviceable; however, the LED map/reading lamps as well as all of the switches, lamp housings, lenses and wiring are serviced only as a unit with the overhead console assembly.

1. Reach above the top of the overhead console (1) to align and insert the bulb and bulb holder unit (2) into the keyed opening of the overhead console lamp housing until the bulb holder is firmly seated.
2. Rotate the bulb and bulb holder unit clockwise about 30 degrees to lock it into place.
3. Reinstall the overhead console onto the headliner. Refer to «CONSOLE, OVERHEAD, FRONT , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
4. Reconnect the battery negative cable.

BULB - REAR

Note. The rear dome/reading lamps are integral to the grab handle in the headliner on the inner roof side rail over each outboard rear seating position. The lamp housing, switch and wiring are serviced only as a unit with the grab handle assembly.

1. Align the base of the bulb (1) with the bulb holders (2) within the rear reading lamp housing.
2. Push the bulb straight rearward into the bulb holders until the base is fully seated.
3. Insert the large tab on the rearward end of the lamp lens (2) into the rear end of the lamp housing.
4. Using hand pressure, push the small tab at the front of the lens rearward and inward towards the lamp housing until it snaps into place.
5. Reconnect the battery negative cable.

Scheme 13

Note. Vehicles equipped with optional vanity lamps have a single lamp at each side of the covered mirror that is integral to each sun visor. Each lamp is independently controlled by an integral switch that is automatically actuated by the mirror cover. The lamp housings, the switch, the mirror and the mirror cover are serviced only as a unit with the sun visor. The bulb types and service procedures are identical for each of these lamp bulbs.

Scheme 14

1. Disconnect and isolate the battery negative cable.
2. Insert a small flat-bladed screwdriver on either side near the top or the bottom between the vanity lamp lens (2) and the lamp housing of the sun visor (1).
3. Carefully pry the lens outward until it unsnaps from the lamp housing.
4. Using small needle-nose pliers, carefully grasp the bulb (2) and pull the base out of the lamp socket.

INSTALLATION

Note. Vehicles equipped with optional vanity lamps have a single lamp at each side of the covered mirror that is integral to each sun visor. Each lamp is independently controlled by an integral switch that is automatically actuated by the mirror cover. The lamp housings, the switch, the mirror and the mirror cover are serviced only as a unit with the sun visor. The bulb types and service procedures are identical for each of these lamp bulbs.

1. Using small needle-nose pliers, carefully grasp the vanity lamp bulb (2) and align the base of the bulb with the socket in the lamp housing of the sun visor (1).
2. Push the bulb straight into the socket until the base is fully seated.
3. Insert one tab on the top or the bottom of the lens (2) into the appropriate slot at the top or bottom of the lamp housing.
4. Flex the lens far enough to engage the loose tab into its slot in the lamp housing.
5. Reconnect the battery negative cable.

Scheme 15

1. Disconnect and isolate the battery negative cable.
2. Open the glove box.
3. Reach through the window (3) in the instrument panel glove box housing (1) to access the bulb (4) on the lower side of the glove box lamp and switch unit (2).
4. Pull the base of the bulb straight out of the bulb holder and out through the window.

LAMP/SWITCH

1. Disconnect and isolate the battery negative cable.
2. Open the glove box.
3. Reach through the window (3) in the instrument panel glove box housing (1) to access and depress the latch feature on either side of the glove box lamp and switch unit (2).
4. While holding the retaining latch depressed, push the glove box lamp and switch unit out through the mounting hole in the face of the instrument panel glove box housing.
5. Disconnect the wire harness connector from the glove box lamp and switch.
6. Remove the lamp and switch unit from the instrument panel.

1. Reach through the window (3) in the instrument panel glove box housing (1) to align the base of the bulb (4) with the bulb holder on the lower side of the glove box lamp and switch unit (2).
2. Push the bulb straight into the bulb holder until the base is firmly seated.
3. Close the glove box.
4. Reconnect the battery negative cable.

1. Position the glove box lamp and switch unit (2) to the instrument panel glove box housing (1).
2. Reconnect the wire harness connector to the lamp and switch unit.
3. Feed the wire harness back through the switch mounting hole.
4. Align the lamp and switch unit with the mounting hole in the instrument panel glove box housing.
5. Using hand pressure, push the lamp and switch unit firmly and evenly into the mounting hole until it is fully seated.
6. Close the glove box.
7. Reconnect the battery negative cable.

DOOR

This vehicle has four door ajar switches, one for each door. Each switch is concealed within and integral to its respective door latch unit. The switches are momentary leaf contact-type micro switch units that are actuated by the mechanisms internal to the door latch. An integral connector receptacle on each door latch connects the door ajar switch and the power lock motor to the vehicle electrical system through its respective door wire harness.

The door ajar switches cannot be adjusted or repaired and, if ineffective or damaged, the door latch unit must be replaced.

FLIP-UP GLASS

A liftgate flip-up glass ajar switch is standard equipment on this vehicle. The switch is concealed within and integral to the liftgate flip-up glass release latch unit. The switch is a momentary leaf contact-type micro switch unit that is actuated by the flip-up glass latch mechanism. An integral connector receptacle on the flip-up glass latch connects the ajar switch to the vehicle electrical system through the liftgate wire harness.

The flip-up glass ajar switch cannot be adjusted or repaired and, if ineffective or damaged, the flip-up glass release latch unit must be replaced. Refer to LATCH, FLIP-UP GLASS , REMOVAL .

LIFTGATE

A liftgate ajar switch is standard equipment on this vehicle. The switch is concealed within and integral to the liftgate latch unit. The switch is a momentary leaf contact-type micro switch unit that is actuated by the liftgate latch mechanism. An integral connector receptacle on the liftgate latch connects the liftgate ajar switch to the vehicle electrical system through the liftgate wire harness.

The liftgate ajar switch cannot be adjusted or repaired and, if ineffective or damaged, the liftgate latch unit must be replaced. Refer to LATCH , REMOVAL or LATCH, FLIP-UP GLASS , REMOVAL .

The door ajar switches are actuated by the mechanisms internal to the door latch. When a door is closed and properly latched, its door ajar switch is an open circuit. When a door is open or only partially latched, the door ajar switch is a closed circuit. The door ajar switches are hard wired in series between a body ground and the Totally Integrated Power Module (TIPM). The TIPM reads the hard wired door ajar switch inputs through internal pull-ups, then uses these inputs to control many electronic functions and features of the vehicle. The TIPM also sends electronic door ajar switch status messages to other electronic modules in the vehicle over the Controller Area Network (CAN) data bus.

The door ajar switches as well as the hard wired inputs and outputs of the switches may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information.

The liftgate flip-up glass ajar switch is actuated by the flip-up glass release latch mechanism. When the flip-up glass is closed and properly latched, the ajar switch is an open circuit. When the glass is open or only partially latched, the ajar switch is a closed circuit. The flip-up glass ajar switch is hard wired in series between a body ground and the Totally Integrated Power Module (TIPM). The TIPM reads the hard wired flip-up glass ajar switch input through an internal pull-up, then uses this input to control many electronic functions and features of the vehicle. The TIPM also sends electronic flip-up glass ajar switch status messages to other electronic modules in the vehicle over the Controller Area Network (CAN) data bus.

The flip-up glass ajar switch as well as the hard wired inputs and outputs of the switch may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information.

The liftgate ajar switch is actuated by the liftgate latch mechanism. When the liftgate is closed and properly latched, the liftgate ajar switch is an open circuit. When the liftgate is open or only partially latched, the liftgate ajar switch is a closed circuit. The liftgate ajar switch is hard wired in series between a body ground and the Totally Integrated Power Module (TIPM) on vehicles without the power liftgate option, or the Power LiftGate Module (PLGM) on vehicles with the power liftgate option. The TIPM or the PLGM reads the hard wired liftgate ajar switch input through an internal pull-up, then uses this input to control many electronic functions and features of the vehicle. The TIPM or the PLGM also sends electronic liftgate ajar switch status messages to other electronic modules in the vehicle over the Controller Area Network (CAN) data bus.

The liftgate ajar switch as well as the hard wired inputs and outputs of the switch may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information.
