DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

B1A08-RKE FOB 1 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

WHEN MONITORED

Continuously.

SET CONDITION

Scrambled messages to the Wireless Ignition Node (WIN) from the FOBIK transmitter.

POSSIBLE CAUSES

Note. The most probable cause that sets this code is the RKE transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

DIAGNOSTIC TEST

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase DTCs. Turn the ignition off and operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace the FOBIK and program using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A09-RKE FOB 2 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the FOBIK transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A0A-RKE FOB 3 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the FOBIK transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK transmitter using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A0B-RKE FOB 4 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK transmitter using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A0C-RKE FOB 5 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK transmitter using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A0D-RKE FOB 6 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A0E-RKE FOB 7 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A0F-RKE FOB 8 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

Scrambled messages to the Wireless Ignition Node (WIN) from the transmitter.

Note. The most probable cause that sets this code is the FOBIK transmitter being pressed over 1024 times when it is out of range of the Wireless Ignition Node and it loses synchronization with the rolling code of the WIN. To correct, insert the FOBIK in the ignition and turn to the on position to synchronize the rolling code.

1. TEST FOR INTERMITTENT CONDITION Put the FOBIK in the ignition and turn the ignition on. With the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore causes the RKE system to be inoperative. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A10-RKE FOB 1 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the RKE transmitter in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A10-RKE FOB 1 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A11-RKE FOB 2 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK transmitter in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A11-RKE FOB 2 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) . No Test complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) .

B1A12-RKE FOB 3 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A12-RKE FOB 3 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the RF Detector (special tool #9001, Rf Detector). If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A13-RKE FOB 4 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK transmitter in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A13-RKE FOB 4 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A14-RKE FOB 5 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs Turn the ignition off and remove the FOBIK. Operate the RKE transmitter in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A14-RKE FOB 5 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A15-RKE FOB 6 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display; B1A15-RKE FOB 6 BATTERY LOW? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A16-RKE FOB 7 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the FOBIK in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A16-RKE FOB 7 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Testy complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A17-RKE FOB 8 BATTERY LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key interrogation and when a valid RKE transmission is read.

If the battery in the Fob-Integrated-Key (FOBIK) is low during key interrogation, with a valid key, this code will set. It may also set during a valid RKE button press.

1. TEST FOR INTERMITTENT CONDITION NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. Using the scan tool, record and erase the DTCs. Turn the ignition off and remove the FOBIK. Operate the RKE transmitter in all positions several times. Turn the ignition on. Using the scan tool, read the active DTCs. Does the scan tool display: B1A17-RKE FOB 8 BATTERY LOW as active? Yes Replace the FOBIK battery. Test the FOBIK using the Miller Special Tool "(special tool #9001, Rf Detector)" RF Detector". If the Strength Display does not display "Strong", replace and program the FOBIK using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete. The conditions that caused this code to set are not present at this time. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A24-KEY NOT PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

THEORY OF OPERATION

Whenever a Fob-Integrated-Key (FOBIK) is inserted in the Wireless Ignition Node (WIN) basestation, the WIN performs a self test and resynchronization routine. During the routine, the WIN interrogates the FOBIK, performing various validity and performance tests. The repair of this fault condition relies on the programmed status of the FOBIK.

During interrogation, the FOBIK sends a low frequency (LF) signal to the WIN that includes the FOBIK identification information.

This DTC sets if the WIN receives the default, secret key status from a FOBIK. Once set, this DTC will remain active until a valid, programmed FOBIK is inserted in the basestation and rotated through the ON position.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE .

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Make sure that the vehicle has the correct PCM and WIN installed by verifying the part numbers. With the scan tool, make sure that the PCM and WIN are programmed correctly. Compare the PCM VIN to the WIN VIN and ensure the two VINs match. With the scan tool, record and erase the DTCs. Perform two ignition cycles, leaving the ignition switch on for a minimum of one minute per cycle. With the scan tool, read the active DTCs. Does the scan tool display; B1A24-KEY NOT PROGRAMMED Yes Go To 2 . No Perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. ENGINE WILL NOT CRANK NOTE: When diagnosing any WIN system concern, all the FOBIKS should be present If this vehicle does not crank, use the table below to determine if the key is functional or not. With the scan tool under Data Display, Bussed Outputs, put the key in each position and check the "Ignition Status". Then with the key in the Run position, check "Valid Skim Key" and "SCREEM Status" reported by the WIN (or WCM). Compare all six readings with the "Good Key" column. If the engine does crank, answer "Yes" to the question below. BUSSED OUTPUTS Ignition Status Good Key Bad Key (Failed) Wrong Key New Key (Blank) Ignition Position = Lock -------------- or Lock -------------- -------------- -------------- or Lock Ignition Position = Acc. Off/Acc. -------------- -------------- Off/Acc. Ignition Position = Run Or ON Run Lock Lock Run Ignition Position = Start Engine Off - Trans. in Gear Start or Run Lock Lock Run SKREEM Status Normal Status Service SKREEM Invalid Key SNA (Signal Not Available) Valid Skim Key Yes/True No/False No/False No/False Trouble Code (DTC) B1A35 B1A6C, B1A25 B1A24 Does the key (FOBIK) pass All Six Comparisons that are in the "Good Key" column? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced along with the WIN in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 3 .
3. CHECK OPERATION OF THE FOBIK IN USE Using the scan tool, program the FOBIK to the WIN. Use the scan tool and erase all codes in the WIN. Turn the Ignition Off, and wait 15 seconds before turning the Ignition On. Wait one minute, and read active codes. Does the scan tool display: B1A24-KEY NOT PROGRAMMED? Yes Replace the key (FOBIK) and program using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A25-INVALID KEY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever a Fob-Integrated-Key (FOBIK) is inserted in the Wireless Ignition Node (WIN) basestation, the WIN performs a self test and resynchronization routine. During the routine, the WIN interrogates the FOBIK, performing various validity and performance tests. The repair of this fault condition relies on whether the ID of the FOBIK is recognized as valid in the WIN.

During interrogation, the FOBIK sends a low frequency (LF) signal to the WIN that includes the inserted FOBIK ID.

This DTC sets if the WIN receives an ID from the FOBIK that does not match any of the eight possible FOBIK IDs currently programmed in the WIN. This DTC will remain active until a valid, programmed FOBIK is inserted in the basestation and rotated through the ON position.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE .

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: An external Radio-Frequency Identification (RFID) key (and/or pass/radio key), such as one used to gain access to a 24 hour gym, can cause this DTC to set and create a no start condition. Inspect the customer's key chain for any type of RFID key. If one is not found, question the customer to see if a spare key chain has this RFID key on it or if it was removed from the original key chain before the vehicle was released for service. If a RFID key is present, remove the ignition key from the vehicle and remove the RFID key from the key chain. For GPEC equipped vehicles, disconnect the battery and wait a minimum of five minutes, reconnect and attempt to start the vehicle. For NGC equipped vehicles, turn the ignition on a minimum for one hour, and then attempt to start the vehicle. If the vehicle does not start, continue with the diagnostic test. NOTE: Verify that the FOBIK in use is the FOBIK causing this DTC to set. Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Make sure that the vehicle has the correct PCM and WIN installed by verifying the part numbers. With the scan tool, make sure that the PCM and WIN are programmed correctly. Compare the PCM VIN to the WIN VIN and make sure the two VINs match. With the scan tool, record and erase the DTCs. Perform two ignition cycles, leaving the ignition switch on for a minimum of one minute per cycle. With the scan tool, read the active DTCs. Does the scan tool display; B1A25-INVALID KEY as active? Yes If the engine does not crank, Go To 2 . If the engine does crank, Go To and answer "Yes" to the question in step 2. Refer to 2 . No Perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. ENGINE DOES NOT CRANK NOTE: When diagnosing any WIN system concern, all the FOBIKS should be present If this vehicle does not crank, use the table below to determine if the key is functional or not. With the scan tool under Data Display, Bussed Outputs, put the key in each position and check the "Ignition Status". Then with the key in the Run position, check "Valid Skim Key" and "SCREEM Status" reported by the WIN (or WCM). Compare all six readings with the "Good Key" column. BUSSED OUTPUTS Ignition Status Good Key Bad Key (Failed) Wrong Key New Key (Blank) Ignition Position = Lock -------------- or Lock -------------- -------------- -------------- or Lock Ignition Position = Acc. Off/Acc. -------------- -------------- Off/Acc. Ignition Position = Run Or ON Run Lock Lock Run Ignition Position = Start Engine Off - Trans. in Gear Start or Run Lock Lock Run SKREEM Status Normal Status Service SKREEM Invalid Key SNA (Signal Not Available) Valid Skim Key Yes/True No/False No/False No/False Trouble Code (DTC) B1A35 B1A6C, B1A25 B1A24 Does the key (FOBIK) pass All Six Comparisons that are in the "Good Key" column? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No If the customer affirms that the FOBIK being used in this test is the correct one for this vehicle, use the scan tool and perform the "Program Ignition Keys or Key FOBs" routine. If the key fails, replace the key (FOBIK) and program using the scan tool. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A26-MAXIMUM NUMBER OF KEYS PROGRAMMED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Wireless Ignition Node (WIN) is preprogrammed from the factory with 2 Fob-Integrated-Keys (FOBIKS), with the capability to have a maximum of 8 FOBIKS programmed in total. Additional programmed FOBIKS are automatically learned to the next available FOBIK position in the WIN software and do not overwrite any previous positions. The repair of this fault condition relies on the current number of FOBIKS programmed into the WIN and the number of available positions in the WIN software.

When the WIN is placed into FOBIK programming mode, the module references the number of unique FOBIK identifications stored in its memory.

In the event the WIN detects the user is attempting to program a 9th FOBIK, this DTC will be set as active.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC Is the DTC active or stored? WIN - ACTIVE DTC Go To 2 . WIN - STORED DTC Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. CLEAR FOBIKS PROGRAMMED INTO WIRELESS IGNITION NODE (WIN) AND REPROGRAM FOBIKS NOTE: The below procedure clears all FOBIKS currently programmed in the WIN software. It is important to obtain all the customer FOBIKS so they may be reprogrammed to the module. Any FOBIKS not present for the following procedure will be inoperable and require additional programming to function. Using the scan tool, use the Erase All Ignition Keys feature under Miscellaneous Functions. Using the scan tool, use the Program Ignition Keys or Key Fobs feature under Miscellaneous Functions. Program all the customer key(s) into the WIN (up to eight). Use the scan tool and erase all DTCs in the WIN. Turn the Ignition Off, and wait 15 seconds before turning the Ignition On. Wait one minute, and read active DTCs. Does the scan tool display: B1A26-MAXIMUM NUMBER OF KEYS PROGRAMMED? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A27-SKREEM PROGRAMMING PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Sentry Key Remote Entry Module (SKREEM) is one of the many functions that is a subset of the Wireless Ignition Node (WIN). SKREEM programming takes place during the Fob-Integrated-Key (FOBIK) programming procedure. The repair of this fault condition is dependent on the programmed status of the FOBIK attempting to be programmed. Once the WIN requests the FOBIK to send its identification information, the FOBIK will attempt to send the information up to three times for redundancy to ensure "Good" information has been received.

During FOBIK programming mode when the FOBIK and the WIN module are communicating over LF (low frequency) communication.

The WIN will set this DTC if one or more of the three FOBIK transmissions, during FOBIK programming, failed to be properly received by the WIN. The FOBIK may still get programmed because the transmission was successful on one of the other attempts.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE .

Note. All FOBIKs programmed to this vehicle should be present before continuing.

1. DELETE FOBIKS AND REPROGRAM With the scan tool, use the "Erase All Ignition Keys" feature under Miscellaneous Functions to delete all stored FOBIKs. With the scan tool, use the "Program Ignition Keys or Key FOBs" feature under Miscellaneous Functions to reprogram all applicable FOBIKs. With the scan tool, erase the WIN DTCs. Turn the ignition off, wait 15 seconds, turn the ignition on. Wait one minute, and read the active DTCs. Does the scan tool display; B1A27-SKREEM PROGRAMMING PERFORMANCE? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A28-ECM MISMATCH WITH SKIM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For the engine to start, the Sentry Key Immobilizer (SKIM) feature of the Wireless Ignition Node (WIN) and the Powertrain Control Module (PCM) must successfully communicate data over the data bus. Once the WIN sends the message that a valid Fob-Integrated-Key (FOBIK) is being used, the PCM and WIN perform a "handshake" routine, encrypted with the VIN, to validate this information, and a match allows the engine to run when the ignition state transitions to START. The repair of this fault is determined by the ability of the WIN and PCM/ECM to complete a successful handshake routine over the bus.

Whenever a valid FOBIK is inserted in the basestation and turned to the ON position, the WIN/PCM handshake takes place. The WIN validates that the message is sent to, and received by the PCM.

When a valid FOBIK is used and the WIN receives a mismatching cryptology code from the PCM as part of the routine, the WIN will send the command to flash the Security warning lamp and set this DTC as active. The engine will not start and the DTC will remain active until the WIN and PCM complete a successful handshake.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE .

1. DETERMINE ACTIVE OR STORED DIAGNOSTIC TROUBLE CODE (DTC) Is the DTC active or stored? WIN - ACTIVE DTC Go To 2 . WIN - STORED DTC Perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. VERIFY THE VEHICLE IDENTIFICATION NUMBER (VIN) STORED IN THE POWERTRAIN CONTROL MODULE (PCM). Using the scan tool, access the VIN number stored in the PCM. NOTE: Make sure that a VIN has been programmed into the PCM. If a VIN is not displayed, attempt to program the PCM with the correct VIN before continuing. Compare the VIN displayed, with the VIN of the vehicle. Does the VIN recorded in the PCM match the VIN of the vehicle? Yes Using the scan tool, verify the VIN in the WIN matches the VIN of the vehicle. If it DOES, Go To 3 If it does NOT match, replace the Wireless Ignition Node in accordance with the Service Information. Refer to 3 . Prior to replacing the WIN, the RUN circuits must be checked at the PCM. A missing run circuit at the PCM can cause this DTC to set. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed before the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Using the scan tool, perform the PCM Replaced Procedure to update the VIN in the PCM. Then, Go To 3 .
3. PCM STARTING DTCS Use the scan tool and erase all DTCs in the WIN and PCM. Turn the Ignition Off, and wait 15 seconds before turning the Ignition On. Try to start the engine. If the engine starts, leave it run for one minute and then turn the engine off (ignition on) Wait one minute, and read the active PCM DTCs. Does the scan tool display any Starting related DTCs? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No Go To 4 .
4. VERIFY PCM PROGRAMMING Use the scan tool and erase all DTCs in the WIN and PCM. Turn the Ignition Off, and wait 15 seconds before turning the Ignition On. Wait one minute, and read the active WIN DTCs. Does the scan tool display: B1A28-ECM MISMATCH WITH SKIM as active? Yes Replace and program the Powertrain Control Module in accordance with the Service Information. Refer to «MODULE, POWERTRAIN CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-intermittent-condition-pcmecm-reprogramming-gas-powertrain-verification-test-pre-diagnostic-troubleshooting-proc) or «PCM VERIFICATION TEST - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A29-SKIM BASESTATION MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

For the engine to start, the Sentry Key Immobilizer (SKIM) feature of the Wireless Ignition Node (WIN) and the Powertrain Control Module (PCM) must successfully communicate VIN data over the serial data bus. Once the WIN sends the message that a valid Fob-in-Key (FOBIK) is being used, the PCM and WIN perform a "handshake" routine to validate this VIN information, including a positive response from the PCM which allows the engine to run when the ignition state transitions to START. The repair of this fault is determined by the WIN recognition of a valid FOBIK and the ability of the WIN and PCM to complete a successful VIN handshake routine over the bus.

Whenever a FOBIK is inserted in the basestation, the WIN determines its validity status. If determined valid, the WIN allows rotation to the ON position and the WIN/PCM handshake takes place.

When an invalid FOBIK is used and the WIN receives a mismatching or no secret key data from the FOBIK, the WIN will send the command to illuminate the Security warning lamp, send an invalid key status in the handshake with the PCM, and set this DTC as active. The "B1A28 ECM/PCM Mismatch with SKIM" DTC will probably be accompanied along with this B1A29.

Always perform the WIN Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

Note. When diagnosing any WIN system DTCs, all FOBIK used on the vehicle should be present.

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. With the scan tool, read the active WIN DTCs. NOTE: This DTC identifies two fault conditions together, an unknown or non communicating FOBIK and a negative response from the PCM to start the engine. First, root cause why the FOBIK is unknown or not responsive. Once the FOBIK issue is corrected, the B1A29 DTC should go to a stored status. Once the B1A29 becomes stored, the B1A28 DTC can be corrected. Does the scan tool display: B1A29-SKIM BASESTATION MISMATCH as Active? Yes Go To 2 . No Verify the FOBIK in use is the FOBIK that caused this DTC to set. If it was, perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. VERIFY FOBIK COMMUNICATION NOTE: When diagnosing any WIN concern, all FOBIKs should be present With the scan tool, read the WIN active DTCs again. Does the scan tool display; B1A35-UNIDENTIFIED KEY COMMUNICATION ERROR as Active? Yes Go To 3 . No Go To 4 .
3. TEST LF COMMUNICATION With the scan tool, in the WIN menu, go to Data Display, Bussed Outputs and check the "SKREEM Status" for the current FOBIK that is being used. Record that status. Remove the FOBIK. Insert one of the other known good FOBIKs used with this vehicle. NOTE: If another FOBIK is not available, insert a new unprogrammed FOBIK to test the WIN module's LF communication (do not program the FOBIK). Check the "SKREEM Status" for the current FOBIK. Verify that the status changed from the first FOBIK that was in the ignition. Did the "SKREEM Status" change? Yes Replace and program the FOBIK in accordance with the Service Information. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. VERIFY THE STATE OF THE WIN MODULE Currently the secret key in the FOBIK does not match the secret key in the WIN module. Find out which component has the correct secret key for this vehicle. Has the WIN module just been replaced? Yes Go To 5 . No Replace and program the FOBIK in accordance with the Service Information. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
5. VERIFY THE WIN MODULE HAS BEEN INITIALIZED Using the scan tool, go to Miscellaneous Functions and run the "Reset WIN" routine. Enter the unique 4 digit PIN number assigned to this vehicle. Was the 4 digit PIN accepted? Yes Replace and program the FOBIK in accordance with the Service Information. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No NOTE: If the PCM was replaced at the same time the WIN was, install the old PCM before continuing or else the correct secret key value will not get transferred and replacing all FOBIKs will be necessary. Using the scan tool, go to Miscellaneous Functions and run the "WIN Replaced" routine. Using the scan tool, go to Miscellaneous Functions and run the "Program Ignition Keys or Key Fobs" routine. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

B1A35-UNIDENTIFIED KEY COMMUNICATION ERROR

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever a Fob-Integrated-Key (FOBIK) is inserted in the Wireless Ignition Node (WIN) basestation, the WIN performs a self test and resynchronization routine. During the routine, the WIN interrogates the FOBIK, performing various validity and performance tests. The repair of this fault condition relies on whether the FOBIK ID is received by the WIN.

During interrogation, the FOBIK sends an LF (Low frequency) signal to the WIN that includes the programmed FOBIK ID.

This Diagnostic Trouble Code (DTC) sets if a FOBIK is inserted in the WIN basestation but the WIN does not receive or is unable to read an ID from the FOBIK. This DTC will remain active until a valid programmed FOBIK is inserted in the WIN and its ID is received.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. CHECK FOR AN INTERMITTENT CONDITION NOTE: An external Radio-Frequency Identification (RFID) key (and/or pass/radio key), such as one used to gain access to a 24 hour gym, can cause this DTC to set and create a no start condition. Inspect the customer's key chain for any type of RFID key. If one is not found, question the customer to see if a spare key chain has this RFID key on it or if it was removed from the original key chain before the vehicle was released for service. If a RFID key is present, remove the ignition key from the vehicle and remove the RFID key from the key chain. For GPEC equipped vehicles, disconnect the battery and wait a minimum of five minutes, reconnect and attempt to start the vehicle. For NGC equipped vehicles, turn the ignition on a minimum for one hour, and then attempt to start the vehicle. If the vehicle does not start, continue with the diagnostic test. NOTE: Verify the FOBIK in use is the FOBIK causing this DTC to set. Turn the ignition on. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off, wait five seconds and then crank the engine. Turn the engine off, key on. With the scan tool, read the active WIN DTCs. Does the scan tool display: B1A35-UNIDENTIFIED KEY COMMUNICATION ERROR as Active? Yes Go To 2 . No Perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. TEST LF COMMUNICATION With the scan tool, in the WIN menu, go to Data Display, Bussed Outputs and check the "SKREEM Status" for the current FOBIK that is being used. Record that status. Turn the ignition off and remove the FOBIK. Insert one of the other known good FOBIKs used with this vehicle. NOTE: If another FOBIK is not available, insert a new FOBIK (Do not program) to test the WIN module's LF communication Check the "SKREEM Status" for the current FOBIK. Verify that the status changed from the first FOBIK that was in the ignition. Did the "SKREEM Status" change? Yes Replace and program the FOBIK in accordance with the Service Information. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . NOTE: If this vehicle is equipped with the Passive Entry System (PEM), with the scan tool, perform the "PEM Replace" routine in the PEM after the FOBIKS have been programmed. Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

Scheme 54

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Anytime the Key is placed in the ignition.

This code is set immediately when the Wireless Ignition Node detects the (F892) Ignition Switch Output circuit shorted to ground when the ignition key is removed.

Scheme 55

Scheme 56

1. VERIFY THAT DTC B1A68-STEERING COLUMN LOCK MODULE BOLT CONTROL LOW (WIN) With the scan tool, record and erase WIN DTCs. Insert and remove the key from the ignition switch several times. With the scan tool, read the active DTCs. Does the scan tool display: B1A68-STEERING COLUMN LOCK MODULE BOLT CONTROL LOW as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
2. STEERING COLUMN LOCK MODULE Turn the ignition off. Disconnect the Steering Column Lock Module connector. NOTE: Check connectors - Clean and repair as necessary. Turn the ignition on. With the scan tool, erase the DTCs. Cycle the ignition switch from On to Off three times. Remove and insert the key in the ignition switch several times. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display: B1A68-STEERING COLUMN LOCK MODULE BOLT CONTROL LOW (WIN) as active? Yes Go To 3 . No Replace the Steering Column Lock Module in accordance with the service information. The Wireless Ignition Node (WIN) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WIN and the Steering Column Lock Module (ELV), the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
3. CHECK THE (F892) IGNITION SWITCH OUTPUT (KEY-IN) CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Wireless Ignition Node harness connector. Measure the resistance between ground and the (F892) Ignition Switch Output (Key-In) circuit in the WIN harness connector. Is the resistance below 10K Ohms? Yes Repair the (F892) Ignition Switch Output (Key-In) circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. The Steering Column Lock Module must also be replaced along with the WIN Module in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

The Wireless Ignition Node detects that the Steering Column Lock Module has not initialized.

1. STEERING COLUMN LOCK MODULE With the scan tool, record and erase WIN DTCs. Remove and insert the key from the ignition switch several times then leave the key in the run position. With the scan tool, read the active DTCs. Does the scan tool display: B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED? Yes Go To 2 . No Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. INITIALIZE STEERING COLUMN LOCK MODULE With the scan tool, erase the DTCs in the WIN. With the scan tool, perform the Steering Wheel Lock Module (ELV) Replaced routine. Turn the Ignition off, wait 15 seconds then turn the ignition back on. Remove and insert the key from the ignition switch several times then leave the key in the run position. With the scan tool, read the DTCs. Does the scan tool display: B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED? Yes Replace the Steering Column Lock Module in accordance with the service information. The Wireless Ignition Node (WIN) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WIN and the Steering Column Lock Module (ELV), the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Test complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A6C-SECRET KEY MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever a Fob-Integrated-Key (FOBIK) is inserted in the Wireless Ignition Node (WIN) basestation, the WIN performs a self test and resynchronization routine. During the routine, the WIN interrogates the FOBIK for the secret key information and start the vehicle. The repair of this fault condition relies on whether the current secret key in the FOBIK is recognized by the WIN.

During interrogation, the FOBIK sends a low frequency (LF) signal to the WIN that includes the current secret key.

This Diagnostic Trouble Code (DTC) sets if the WIN receives a secret key ID from the FOBIK that is not the correct secret key value stored in the WIN. This DTC will remain active until a valid, programmed FOBIK, with the correct secret key is inserted in the basestation and rotated through the ON position.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: When diagnosing any WIN system concern, all the FOBIKS should be present. NOTE: Verify that the FOBIK in use is the FOBIK causing the DTC to set. Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Make sure that the vehicle has the correct PCM and WIN installed by verifying the part numbers. With the scan tool, ensure that the PCM and WIN are programmed correctly. Compare the PCM VIN to the WIN VIN and ensure the two VINs match. With the scan tool, record and erase the DTCs. Perform five ignition cycles, leaving the ignition switch on for a minimum of one minute per cycle. With the scan tool, read the active DTCs. Does the scan tool display; B1A6C-SECRET KEY MISMATCH as active? Yes If the engine does not crank, Go To 2 . If the engine does crank, Go To 3 . No Perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. ENGINE DOES NOT CRANK If this vehicle does not crank, use the table below to determine if the key is functional or not. With the scan tool under Data Display, Bussed Outputs, put the key in each position and check the "Ignition Status". Then with the key in the Run position, check "Valid Skim Key" and "SKREEM Status" reported by the WIN (or WCM). Compare all six readings with the "Good Key" column. BUSSED OUTPUTS Ignition Status Good Key Bad Key (Failed) Wrong Key New Key (Blank) Ignition Position = Lock -------------- or Lock -------------- -------------- -------------- or Lock Ignition Position = Acc. Off/Acc. -------------- -------------- Off/Acc. Ignition Position = Run Or ON Run Lock Lock Run Ignition Position = Start Engine Off - Trans. in Gear Start or Run Lock Lock Run SKREEM Status Normal Status Service SKREEM Invalid Key "SNA" Signal Not Available Valid Skim Key Yes/True No/False No/False No/False Trouble Code (DTC) B1A35 B1A6C, B1A25 B1A24 Does the key (FOBIK) pass All Six Comparisons that are in the "Good Key" column? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced along with the WIN in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 3 .
3. VERIFY THE WIN HAS BEEN PROPERLY INITIALIZED Using the scan tool, read the Number of Key/Fobs Programmed under Data Display. Does the scan tool show any Key/Fobs Programmed? Yes Go To 4 . No Using the scan tool, program the FOBIKS. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. CHECK OPERATION OF THE FOBIK IN USE NOTE: Verify the FOBIK in use is the FOBIK causing the DTC to set. Replace the FOBIK currently in use, unless the FOBIK was identified as a new key in Step 2. Using the scan tool, program the new FOBIK to the WIN. Use the scan tool and erase all codes in the WIN. Turn the Ignition Off, and wait 15 seconds before turning the Ignition On. Wait one minute, and read active codes. Does the scan tool display this DTC as active? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced along with the WIN in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1A77- REMOTE START ANTENNA CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Remote start present and configured.

Short to ground detected on the Remote Start Antenna.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. With the scan tool, read the active WIN DTCs. Does the scan tool display: B1A77- REMOTE START ANTENNA CIRCUIT LOW as Active? Yes Go To 2 . No Perform the WIN INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. CHECK WIN Unplug the Remote Start Antenna from the WIN module. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on, wait five seconds. With the scan tool, read the active WIN DTCs. NOTE: The "B1A79-Remote Start Antenna Circuit Open or Not Connected" will probably display as active. Does the scan tool display; B1A77- REMOTE START ANTENNA CIRCUIT LOW as Active? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Remote Start Antenna in accordance with the Service Information. Refer to «ANTENNA, REMOTE START , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/starter/#starting-service-information__removal) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

B1A79- REMOTE START ANTENNA CIRCUIT OPEN OR NOT CONNECTED

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on. Remote start present and configured.

No Remote Start Antenna detected by the Wireless Ignition Node (WIN).

1. REMOTE START ANTENNA NOT CONNECTED Verify that the Remote Start Antenna is connected to the WIN. Disconnect the Remote Start Antenna and reconnect it to ensure that it is seated correctly. Turn the ignition on. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on, wait five seconds. With the scan tool, read the active WIN DTCs. Does the scan tool display: B1A79- REMOTE START ANTENNA CIRCUIT OPEN OR NOT CONNECTED as Active? Yes Go To 2 . No Test complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
2. CHECK REMOTE START ANTENNA Turn the ignition off. Secure a new Remote Start Antenna and connect the connector to the WIN. Turn the ignition on. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. With the scan tool, read the active WIN DTCs. Does the scan tool display: B1A79- REMOTE START ANTENNA CIRCUIT OPEN OR NOT CONNECTED as Active? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Finish the installation of the Remote Start Antenna in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B210A-SYSTEM VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

At all times.

This is a CAN message that the battery voltage was below 10.0 volts for over 15 seconds.

1. CHECK POWERTRAIN CONTROL MODULE DTCs With the scan tool, read Powertrain DTCs Are there any Powertrain Charging or Battery DTCs present? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) . No This code is for information only. At some time there was a low battery system voltage. Check the battery and charging system in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B210B-SYSTEM VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

At all times.

This is a CAN message that the system voltage was above 16.0 volts for over 15 seconds.

1. CHECK ENGINE DTCs With the scan tool, read Powertrain DTCs. Are there any Powertrain Charging or Battery DTCs present? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No This code is a CAN system message for information only. Check the charging system in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B210D-BATTERY VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition switch on.

The Wireless Ignition Node (WIN) has detected the Fused (B+) input voltage was below 10.5 volts for over 15 seconds except during cranking or when the FOBIK removal inhibit feature is engaged.

Scheme 57

1. CHECK PCM FOR CHARGING SYSTEM DTCs NOTE: Be sure the battery is fully charged before proceeding. With a scan tool, read the Powertrain Control Module (PCM) DTCs. Are there any Charging or Starting System DTCs set in the PCM? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No Go To 2 .
2. VERIFY THAT DTC B210D-BATTERY VOLTAGE LOW IS ACTIVE With the scan tool, record and erase the DTCs. Cycle the ignition switch to the OFF position then start the engine and let run for one minute. With the scan tool, read the WIN active DTCs. Does the scan tool display: B210D-BATTERY VOLTAGE LOW active? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. (A106) FUSED (B+) CIRCUIT OR (Z912) GROUND CIRCUIT HAS HIGH RESISTANCE NOTE: Check the related fuses to the Fused (B+) circuit. If the fuse is found to be open, repair the circuit for a shorted condition. Turn the ignition off. Disconnect the WIN harness connector. Turn the ignition on. Using a 12-volt test light, connect it between the (A106) Fused (B+) circuit and the (Z912) Ground circuit in the WIN harness connector. The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Is the test light as bright at the module as it is at the battery? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it MUST also be replaced along with the WIN in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Test the (A106) Fused B(+) circuit and the Ground circuit to determine which one has the high resistance. Repair the Fused B(+) circuit or the Ground circuit for high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B210E-BATTERY VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition switch on.

The Wireless Ignition Node (WIN) has detected the Fused (B+) input voltage to be above 15.5 volts for over 15 seconds.

1. CHECK FOR CHARGING SYSTEM RELATED DTCs IN THE POWERTRAIN CONTROL MODULE (PCM) NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. Turn the ignition on. With the scan tool in ECU View, select PCM and check for any Battery or Charging System related DTCs. Does the scan tool display any Battery or Charging System related DTCs? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No Go To 2 .
2. INTERMITTENT CONDITION NOTE: Be sure the battery is fully charged before proceeding. With the scan tool, record and erase the WIN DTCs. Perform five ignition cycles, leaving the ignition switch on for a minimum of one minute per cycle. Start the engine and run for two minutes. With the scan tool, read the active WIN DTCs. Does the scan tool display: B210E-BATTERY VOLTAGE HIGH? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. CHECK THE GROUND CIRCUIT AT THE WIN NOTE: A dirty (partial) ground can cause abnormal conditions within a system. Turn the ignition off. Disconnect the WIN connector. Using a 12-volt test light, connect it between the (A106) Fused (B+) circuit and the (Z912) Ground circuit in the WIN harness connector. The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Is the test light as bright at the module connector as it is at the battery? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair the (Z912) Ground circuit for high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B2204-ECU CONFIGURATION MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Wireless Ignition Node (WIN) must be configured for various parameters such as model year and vehicle line, after a service replacement. The WIN checks for the proper configuration by comparing the values stored to those sent out on the serial data bus. The repair of this fault does not involve any external circuitry and centers on verifying the module is configured correctly.

The WIN checks the feature configuration at power up during the initialization process, and continuously through the ignition cycle.

This DTC sets when the WIN detects a mismatch of Model Year, vehicle line, body style or market country between the current vehicle configuration of the module and the information sent out on the CAN bus. Once set, this DTC is latched for the entire ignition cycle.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DTC Is the DTC active or stored? WIN - ACTIVE DTC Go To 2 . WIN - STORED DTC Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. RESET/RECONFIGURE THE TOTALLY INTEGRATED POWER MODULE (TIPM) Turn the ignition on. Using the scan tool, select ECU View. This will list the modules on the vehicle. Read and record the listed modules. NOTE: A Scan Report will list all the modules on the vehicle. Using the scan tool, select the Totally Integrated Power Module (TIPM) and then press Miscellaneous Functions. Press Reset ECU. Cycle the ignition from on to off three times and read the active WIN DTCs. Does the scan tool display: B2204-ECU CONFIGURATION MISMATCH active? Yes Go To 3 . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. RESET/RECONFIGURE THE WIN Using the scan tool, select the WIN and then press Miscellaneous Functions. Press Reset ECU. Cycle the ignition from on to off three times and read the active WIN DTCs. Does the scan tool display: B2204-ECU CONFIGURATION MISMATCH active? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed before the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B2205-ORIGINAL VIN MISSING/MISMATCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When a valid Fob-Integrated-Key (FOBIK) is used and the ignition is rotated to the RUN position, the Wireless Ignition Node (WIN) "listens" to the CAN C bus for the broadcast of the Vehicle Identification Number (VIN) by the Powertrain Control Module (PCM).

The WIN monitors the VIN broadcast on the CAN C bus three times, when the ignition is turned to the RUN position. When the full VIN has been received by the WIN, all further broadcasts of the VIN are ignored for that ignition cycle.

When the VIN received from the CAN C bus does not match the VIN stored in the memory of the Wireless Ignition Node, the WIN will send the command to flash the Security warning lamp and set this DTC as active and the vehicle will immobilize. The DTC will remain active until a VIN matching the one stored in WIN memory is received by the module from the bus.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

1. DETERMINE ACTIVE OR STORED DIAGNOSTIC TROUBLE CODE (DTC) Is the DTC active or stored? WIN - ACTIVE DTC Go To 2 . WIN - STORED DTC Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. CHECK THE VIN STORED IN THE PCM Using the scan tool, compare the VIN that is stored in the PCM to the VIN of the vehicle's VIN plate. Does the VIN stored in the PCM match the vehicle's VIN? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Powertrain Control Module in accordance with the Service Information. Refer to «MODULE, POWERTRAIN CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-intermittent-condition-pcmecm-reprogramming-gas-powertrain-verification-test-pre-diagnostic-troubleshooting-proc) or «PCM VERIFICATION TEST - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) .

Scheme 58

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

This DTC is set when the internal initialization state machine is set to FAIL or the (D508) LIN Bus circuit is shorted.

Scheme 59

Scheme 60

1. CHECK FOR DELAMINATION ON THE WINDSHIELD Check the contact surface of the Rain Sensing Module to the windshield for delamination (this will resemble air bubbles in the contact area). Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/wiperwasher-systems/#wiper-system-washer-system-service-information) . Is delamination present on the windshield? Yes Replace the windshield in accordance with the Service Information Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 2 .
2. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, erase the DTCs. Cycle the ignition from on to off three times. Turn the ignition on and wait 30 seconds. With the scan tool, read the DTCs. NOTE: If the D508 LIN Bus circuit is shorted to Ground or Battery voltage, this code may appear as Stored and when erased may return as Stored. Does the scan tool display: B2211-RAIN SENSOR MODULE INITIALIZATION PERFORMANCE either Active or Stored? Yes Go To 3 . No Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
3. (D508) LIN BUS CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Rain Sensor harness connector. Measure the resistance between ground and the (D508) LIN Bus circuit in the rain sensor connector. Is the resistance below 20, 000 Ohms? Yes Go To 5 . No Go To 4 .
4. (D508) LIN BUS CIRCUIT SHORTED TO BATTERY Turn the ignition on. Measure the voltage between the (D508) LIN Bus circuit and ground. NOTE: The voltage should fluctuate between approximately 7.0 and 9.8 volts. Is the voltage above 10.0 volts? Yes Go To 6 . No Replace the Rain Sensor in accordance with the Service Information. Replace and program the Rain Sensor. Refer to «MODULE, LIGHT RAIN SENSOR (LRSM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wiperwasher-systems/#wiper-system-washer-system-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
5. (D508) LIN BUS WIRE SHORTED TO GROUND Disconnect the Wireless Ignition Node (WIN) harness connector. Measure the resistance between ground and the (D508) LIN Bus circuit in the rain sensor connector. Is the resistance below 20, 000 Ohms? Yes Repair the (D508) LIN Bus circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Rain Sensor in accordance with the Service Information. Replace and program the Rain Sensor. Refer to «MODULE, LIGHT RAIN SENSOR (LRSM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wiperwasher-systems/#wiper-system-washer-system-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
6. (D508) LIN BUS WIRE SHORTED TO BATTERY Turn the ignition off. Disconnect the Wireless Ignition Node (WIN) harness connector. Turn the ignition on. Measure the voltage between the (D508) LIN Bus circuit and ground. Is there any voltage present? Yes Repair the LIN Bus wire for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed before the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

B221D-RAIN SENSOR MODULE INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The Rain Sensing Module detects an internal failure.

1. REPLACE THE RAIN SENSING MODULE With the scan tool, read the WIN DTCs. Does the scan tool display: B221D-RAIN SENSOR MODULE (RSM) INTERNAL active? Yes Replace the Rain Sensor in accordance with the Service Information. With the scan tool select: Misc. Functions, LRSM Re-Adaption and run that program. Refer to «MODULE, LIGHT RAIN SENSOR (LRSM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wiperwasher-systems/#wiper-system-washer-system-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

B2224-SKREEM INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During key insertion and removal and at module power up.

When the internal memory is corrupted. This DTC can also set if the vehicle is equipped with a Steering Column Lock module (BUX). If after any three consecutive unsuccessful Steering Column Lock and/or Unlock (ELV) attempts, which could be caused by an encoded data mismatch or the bolt did not reach the intended position when requested.

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Make sure that the vehicle has the correct PCM and WIN installed by verifying the part numbers. With the scan tool, ensure that the PCM and WIN are programmed correctly. Compare the PCM VIN to the WIN VIN and ensure the two VINs match. With the scan tool, erase the DTCs. Perform three ignition cycles, leaving the ignition switch on for a minimum of one minute per cycle. With the scan tool, read the active DTCs. Does the scan tool display: B2224-SKREEM INTERNAL as active? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced along with the WIN in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

B2254-COLUMN LOCK MODULE INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

If the Wireless Ignition Node (WIN) does not receive the correct response message back from the Steering Column Lock Module (ELV).

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. INTERMITTENT DTC Using the scan tool, record and erase the WIN DTCs. Turn the ignition off and remove the FOBIK. Arm the Vehicle Theft and Security System (VTSS) and wait one minute. Disarm the VTSS by inserting the FOBIK. Turn the ignition on. Wait one minute. Using the scan tool, read the WIN DTCs. Does the scan tool display active; B2254-COLUMN LOCK MODULE INTERNAL? Yes Go To 2 . No Perform the WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
2. (A106) FUSED B(+) CIRCUIT OPEN Turn the ignition off. Gain access to the Steering Column Lock Module. Disconnect the Steering Column Lock Module connector. Using a 12-volt test light connected to ground, check the (A106) Fused B(+) circuit in the Steering Column Lock Module connector. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (A106) Fused B(+) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. (F892) IGNITION SWITCH OUTPUT (KEY-IN) CIRCUIT OPEN Disconnect the WIN harness connector. Measure the resistance of the (F982) Ignition Switch Output (Key-In) circuit between in the WIN module and the Steering Column Lock Module. Is the resistance below 2.0 Ohms? Yes Go To 4 . No Repair the (F892) Ignition Switch Output (Key-In) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
4. (Z912) GROUND CIRCUIT OPEN Using a 12-volt test light, connect one end to the (A106) Fused B(+) circuit and the other end to the (Z912) Ground circuit in the Steering Column Lock Module connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (Z912) Ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
5. (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN Measure the resistance of the (D508) COM-LIN Tire Pressure Monitor LAN circuit between (Cavity 2) in the WIN module and (Cavity 4) in the Steering Column Lock Module. Is the resistance below 1.0 Ohms? Yes Replace the Steering Column Lock Module in accordance with the service information. The Wireless Ignition Node (WIN) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WIN and the Steering Column Lock Module (ELV), the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair the (D508) COM-LIN Tire Pressure Monitor LAN circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C0077-LOW TIRE PRESSURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

A low pressure condition will exist when the tire pressure falls below or is equal to the low pressure threshold value as specified for the vehicle.

1. DTC STATUS NOTE: If the incorrect Placard Values were programmed into the WIN, a DTC could be set. Before continuing with any TPM diagnostic test, using the scan tool, check that the correct Placard Values have been programmed in to the module. NOTE: If any the following conditions are present repair them first before continuing with this test. Individual Low Tire Pressure Sensor DTCs Tire Pressure Monitoring (TPM) Sensor Internal fault Spare Tire is not equipped with a TPM Sensor and is currently on the vehicle NOTE: Seasonal temperature changes will affect tire pressure, and may have caused the tire pressure to fall below the low pressure warning threshold. Tire pressure should always be set based on cold inflation tire pressure (placard). This is defined as the tire pressure after a vehicle has not been driven for more then three hours, and in outside ambient temperatures. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. Ignition on engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at speeds greater than 15 mph (24 km/h) for minimum of 10 minutes. With the scan tool, read DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 8 .
2. LOW TIRE PRESSURE NOTE: This DTC can be caused by many different factors and might not be a TPM Sensor or a WIN fault. Interference from other elements can over power the sensor/transmitter RF frequency to the WIN making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. With the scan tool, erase DTCs. With the scan tool, read DTCs. Does the DTC reset or is the status Active for this DTC? Yes Go To 3 . No Go To 8 .
3. TIRE PRESSURE MONITORING (TPM) SENSOR NOTE: The following tests are used to locate the Tire Pressure Sensor/Transmitter that is setting the low pressure fault. If the tires have been rotated, the Tire Pressure Sensor/Transmitter is no longer in sequence from the factory. Faults are linked to the sensor/transmitter IDs. You MUST locate the correct Tire Pressure Sensor/Transmitter that set the fault before. NOTE: Before continuing with any TPM diagnostic test, using the scan tool and read first set of the Tire Placard Pressure Front and Tire Placard Pressure Rear under Data Display in the WIN. (under the Left Rear Transponder Status) Confirm that the values match the Tire Inflation Pressure (Placard) label located on the Drivers Side B-Pillar. If the incorrect Placard Values have been programmed in the WIN, go to Update Pressure Thresholds under Miscellaneous Functions for the WIN and follow the procedure. If the vehicle is equipped with a WIN Module, go into the Totally Integrated Power Module (TIPM), select Data Display and read "Tire Placard Pressure - Front" and "Tire Placard Pressure - Rear" to confirm the values were programmed correctly. If the Placard values are incorrect in the TIPM, select the Totally Integrated Power Module (TIPM) then under "Miscellaneous" select "Update Pressure Threshold" and enter the placard pressure value as seen on the Tire Inflation Pressure (Placard) label. Repeat step #2 for Diagnostics. With the scan tool, select View Data Display in the WIN and find the compensated tire pressure values located under each of the Sensor Identification locations. Are any of the compensated tire pressure values are below the Placard Value? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 4 .
4. TPM/RKE ANALYZER CH9936 Is their a TPM/RKE Analyzer CH9936 available? Yes Go To 5 . No Go To 7 .
5. TIRE PRESSURE MONITORING (TPM) SENSOR NON-RESPONSIVE With the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE), check to see if the any of the TPM Sensors do not respond after repeated attempts or display the following: "Damaged Accel" "Damaged Temp" "Damaged Temp" "Damaged Press" Are any of the TPM Sensors not responding or displaying the information listed above? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 6 .
6. TPM SENSOR INTERNAL FAULT SET USING TPM/RKE ANALYZER CH9936 NOTE: The following procedure is used to locate the TPM Sensor that is setting the sensor internal fault. If the tires have been rotated, the Tire Pressure Sensor is no longer in sequence from the factory. Faults are linked to the sensor/transmitter IDs. You MUST locate the correct Tire Pressure Sensor that set the fault before continuing. Use the following method below at every tire location. NOTE: If the sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM sensors and repeat this step. With the scan tool, select Data Display for the WIN. Check to see if the Sensor IDs match what is programmed into the WIN. Has the Tire Pressure Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
7. TIRE PRESSURE SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 15 mph (24 km/h) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values Look for a tire location whose sensor ID that is not responding. Repeat this test on each wheel on the vehicle until the sensor in question has been identified Has the Tire Pressure Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
8. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions necessary to set this DTC are not present at this time. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, erase DTCs. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). With the scan tool, read DTCs. Does the DTC reset or is the status Active for this DTC? Yes Repair as necessary. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.

C1501-TIRE PRESSURE SENSOR 1 INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tire pressure sensor actively monitors the air pressure and air temperature inside the tire, the sensor internal battery status, and the radial acceleration of the wheel. Each sensor has a unique ID code.

With vehicle speed greater than 24 km/h (15 mph).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

1. DTC STATUS IS ACTIVE NOTE: Seasonal temperature changes will affect tire pressure, and may have caused the tire pressure to fall below the low pressure warning threshold. Tire pressure should always be set based on cold inflation tire pressure (placard). This is defined as the tire pressure after a vehicle has not been driven for more then three hours, and in outside ambient temperatures. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. Ignition on engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. With the scan tool, read the DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 9 .
2. TPM-RKE ANALYZER CH9936 Is there a TPM-RKE Analyzer CH9936 available? Yes Go To 3 . No Go To 8 .
3. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with a TPM Sensor. With the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) verify the correct TPM Sensor is on the vehicle. Is the correct TPM Sensor installed on the vehicle? Yes Go To 4 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET USING TPM-RKE ANALYZER NOTE: The following procedure is used to locate the TPM Sensor that is setting the internal fault. If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the TPM Sensor that set the fault before continuing. Use the following method below at every tire location. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to scan each TPM Sensor for a response, and store in the proper location in the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE). If you receive no response from any of the TPM Sensors, check to make sure that the TPM-RKE Analyzer is set correctly and repeat the process on each non-responsive wheel. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 5 .
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to verify the TPM Sensor IDs match what is programmed into the WIN. The TPM Sensor Identifications are located under "Data Display" for the WIN. Do the TPM Sensor IDs match what is stored in the WIN? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT Using the data taken by the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE), program the current sensor ID's into the WIN module in the corresponding locations. With the scan tool, erase the DTCs. Drive the vehicle for a minimum of 20 minutes with the vehicle speed greater than 24 km/h (15 mph) to verify that the DTC does not return in an active state. With the scan tool, read the active DTCs. Does the scan tool display: C1501-TIRE PRESSURE SENSOR 1 INTERNAL Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID With the TPM-RKE Analyzer, read the sensor ID's. Do the sensor ID's match the ID's just learned in the previous step? Yes Test complete. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive the TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values. Look for a tire location with a non-responsive TPM Sensor ID. Repeat this test on each wheel on the vehicle until the TPM Sensor in question has been identified. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
9. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions necessary to set this DTC are not present at this time. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, clear DTCs in the Wireless Ignition Node (WIN) Module. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). With the scan tool, select View DTCs in the Wireless Ignition Node (WIN) Module. Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the diagnostic procedure as necessary. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.

C1502-TIRE PRESSURE SENSOR 2 INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tire pressure sensor actively monitors the air pressure and air temperature inside the tire, the sensor internal battery status, and the radial acceleration of the wheel. Each sensor has a unique ID code. The sensor transmits the data at regular intervals via an encoded signal to a receiver circuit located in the Wireless Ignition Node (WIN).

With vehicle speed greater than 24 km/h (15 mph).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

1. DTC STATUS IS ACTIVE NOTE: Seasonal temperature changes will affect tire pressure, and may have caused the tire pressure to fall below the low pressure warning threshold. Tire pressure should always be set based on cold inflation tire pressure (placard). This is defined as the tire pressure after a vehicle has not been driven for more then three hours, and in outside ambient temperatures. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. Ignition on engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. With the scan tool, read DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 9 .
2. TPM-RKE ANALYZER CH9936 Is there a TPM-RKE Analyzer CH9936 available? Yes Go To 3 . No Go To 8 .
3. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with a TPM Sensor. With the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) verify the correct TPM Sensor is on the vehicle. Is the correct TPM Sensor installed on the vehicle? Yes Go To 4 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET USING TPM-RKE ANALYZER NOTE: The following procedure is used to locate the TPM Sensor that is setting the internal fault. If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the TPM Sensor that set the fault before continuing. Use the following method below at every tire location. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to scan each TPM Sensor for a response, and store in the proper location in the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE). If you receive no response from any of the TPM Sensors, check to make sure that the TPM-RKE Analyzer is set correctly and repeat the process on each non-responsive wheel. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 5 .
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to verify the TPM Sensor IDs match what is programmed into the WIN. The TPM Sensor Identifications are located under "Data Display" for the WIN. Do the TPM Sensor IDs match what is stored in the WIN? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT Using the data taken by the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE), program the current sensor ID's into the WIN module in the corresponding locations. With the scan tool, erase the DTCs. Drive the vehicle for a minimum of 20 minutes with the vehicle speed greater than 24 km/h (15 mph) to verify that the DTC does not return in an active state. With the scan tool, read the active DTCs. Does the scan tool display: C1502-TIRE PRESSURE SENSOR 2 INTERNAL Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID With the TPM-RKE Analyzer, read the sensor ID's. Do the sensor ID's match the ID's just learned in the previous step? Yes Test complete. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive the TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values. Look for a tire location with a non-responsive TPM Sensor ID. Repeat this test on each wheel on the vehicle until the TPM Sensor in question has been identified. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the WIN module in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
9. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions necessary to set this DTC are not present at this time. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, clear DTCs in the Wireless Ignition Node (WIN) Module. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). With the scan tool, select View DTCs in the Wireless Ignition Node (WIN) Module. Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the diagnostic procedure as necessary. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.

C1503-TIRE PRESSURE SENSOR 3 INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tire pressure sensor actively monitors the air pressure and air temperature inside the tire, the sensor internal battery status, and the radial acceleration of the wheel. Each sensor has a unique ID code. The sensor transmits the data at regular intervals via an encoded signal to a receiver circuit located in the Wireless Ignition Node (WIN).

With vehicle speed greater than 24 km/h (15 mph).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

1. DTC STATUS IS ACTIVE NOTE: Seasonal temperature changes will affect tire pressure, and may have caused the tire pressure to fall below the low pressure warning threshold. Tire pressure should always be set based on cold inflation tire pressure (placard). This is defined as the tire pressure after a vehicle has not been driven for more then three hours, and in outside ambient temperatures. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. Ignition on engine not running. Using the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. Using the scan tool, read DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 9 .
2. TPM-RKE ANALYZER CH9936 Is there a TPM-RKE Analyzer CH9936 available? Yes Go To 3 . No Go To 8 .
3. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with a TPM Sensor. With the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) verify the correct TPM Sensor is on the vehicle. Is the correct TPM Sensor installed on the vehicle? Yes Go To 4 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET USING TPM-RKE ANALYZER NOTE: The following procedure is used to locate the TPM Sensor that is setting the internal fault. If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the TPM Sensor that set the fault before continuing. Use the following method below at every tire location. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to scan each TPM Sensor for a response, and store in the proper location in the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE). If you receive no response from any of the TPM Sensors, check to make sure that the TPM-RKE Analyzer is set correctly and repeat the process on each non-responsive wheel. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 5 .
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to verify the TPM Sensor IDs match what is programmed into the WIN. The TPM Sensor Identifications are located under "Data Display" for the WIN. Do the TPM Sensor IDs match what is stored in the WIN? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT Using the data taken by the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE), program the current sensor ID's into the WIN module in the corresponding locations. With the scan tool, erase the DTCs. Drive the vehicle for a minimum of 20 minutes with the vehicle speed greater than 24 km/h (15 mph) to verify that the DTC does not return in an active state. With the scan tool, read the active DTCs. Does the scan tool display: C1503-TIRE PRESSURE SENSOR 3 INTERNAL Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID With the TPM-RKE Analyzer, read the sensor ID's. Do the sensor ID's match the ID's just learned in the previous step? Yes Test complete. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive the TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values. Look for a tire location with a non-responsive TPM Sensor ID. Repeat this test on each wheel on the vehicle until the TPM Sensor in question has been identified. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
9. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions necessary to set this DTC are not present at this time. Perform any Technical Service Bulletins that may apply to this condition. Using the scan tool, clear DTCs in the Wireless Ignition Node (WIN) Module. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). Using the scan tool, select View DTCs in the Wireless Ignition Node (WIN) Module. Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the diagnostic procedure as necessary. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.

C1504-TIRE PRESSURE SENSOR 4 INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The tire pressure sensor actively monitors the air pressure and air temperature inside the tire, the sensor internal battery status, and the radial acceleration of the wheel. Each sensor has a unique ID code. The sensor transmits the data at regular intervals via an encoded signal to a receiver circuit located in the Wireless Ignition Node (WIN).

With vehicle speed greater than 15 m.p.h. (24 km/h).

The Wireless Ignition Node (WIN) will monitor the signals from the four active road tire sensors. A loss of signal error is detected when eight consecutive blocks of data are not received or cannot be accurately decoded. An internal sensor hardware error condition will be set when an error in the accelerometer, pressure sensor, or temperature sensor is detected.

1. DTC STATUS IS ACTIVE NOTE: Seasonal temperature changes will affect tire pressure, and may have caused the tire pressure to fall below the low pressure warning threshold. Tire pressure should always be set based on cold inflation tire pressure (placard). This is defined as the tire pressure after a vehicle has not been driven for more then three hours, and in outside ambient temperatures. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. Ignition on engine not running. Using the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. Using the scan tool, read DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 9 .
2. TPM-RKE ANALYZER CH9936 Is there a TPM-RKE Analyzer CH9936 available? Yes Go To 3 . No Go To 8 .
3. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with a TPM Sensor. With the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) verify the correct TPM Sensor is on the vehicle. Is the correct TPM Sensor installed on the vehicle? Yes Go To 4 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET USING TPM-RKE ANALYZER NOTE: The following procedure is used to locate the TPM Sensor that is setting the internal fault. If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the TPM Sensor that set the fault before continuing. Use the following method below at every tire location. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to scan each TPM Sensor for a response, and store in the proper location in the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE). If you receive no response from any of the TPM Sensors, check to make sure that the TPM-RKE Analyzer is set correctly and repeat the process on each non-responsive wheel. Has the faulty TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 5 .
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to verify the TPM Sensor IDs match what is programmed into the WIN. The TPM Sensor Identifications are located under "Data Display" for the WIN. Do the TPM Sensor IDs match what is stored in the WIN? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT Using the data taken by the TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE), program the current sensor ID's into the WIN module in the corresponding locations. With the scan tool, erase the DTCs. Drive the vehicle for a minimum of 20 minutes with the vehicle speed greater than 24 km/h (15 mph) to verify that the DTC does not return in an active state. With the scan tool, read the active DTCs. Does the scan tool display: C1504-TIRE PRESSURE SENSOR 4 INTERNAL Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID With the TPM-RKE Analyzer, read the sensor ID's. Do the sensor ID's match the ID's just learned in the previous step? Yes Test complete. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive the TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values. Look for a tire location with a non-responsive TPM Sensor ID. Repeat this test on each wheel on the vehicle until the TPM Sensor in question has been identified. Has the TPM Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the service information. Refer to «SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
9. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions necessary to set this DTC are not present at this time. Perform any Technical Service Bulletins that may apply to this condition. Using the scan tool, clear DTCs in the Wireless Ignition Node (WIN) Module. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). Using the scan tool, select View DTCs in the Wireless Ignition Node (WIN) Module. Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the diagnostic procedure as necessary. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.

C151C-TIRE PRESSURE MONITORING (TPM) SENSORS MISSING

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When installing a new Wireless Ignition Node (WIN), the module is programed with universal IDs for the Tire Pressure Monitoring (TPM) Sensors. The WIN must be programmed with the correct TPM Sensor IDs.

During vehicle TPM Sensor ID locate process.

When installing a new Wireless Ignition Node (WIN).

1. VERIFY DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: The DTC can be caused by many different factors and might not be a sensor/transmitter or a WIN fault. Interference from other elements will over power the sensor/transmitter RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Correct all tire pressures to the recommended cold inflation tire pressure specifications and wait two minutes for the system to update. Ignition on, engine not running. Using the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM data and allow for the system to update. Using the scan tool, read DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 5 .
2. TPM-RKE ANALYZER CH9936 Is there a TPM-RKE Analyzer CH9936 available? Yes Go To 3 . No Go To 4 .
3. WITH TPM-RKE TOOL CHECK TIRE PRESSURE MONITORING (TPM) SENSOR ID(S) NOTE: Always be certain to select the proper vehicle line and model year when using this tool, as the tool will automatically use the correct protocol to attempt to read the Sensor. If the incorrect vehicle line and/or model year is selected, the Sensor will not respond to the tool. NOTE: If you receive no response from any of the tire pressure sensors, check to make sure that the TPM-RKE Analyzer is set correctly, and repeat the process on each of the non-responsive wheel(s) Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to scan each TPM Sensor for an ID, store in the proper location in the TPM-RKE Analyzer. Use a TPM-RKE Analyzer (special tool #CH9936, Analyzer, TPM/RKE) to upload the correct IDs and proper locations in the scan tool. Using the scan tool, select the TIPM Module under "Miscellaneous Functions", follow the procedure for uploading TPM Sensor IDs. Using the scan tool, erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM data and allow for the system to update. Using the scan tool, check to see if the TPM Module IDs match what is programmed into the WIN. Do the TPM IDs match? Yes Test complete. Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. WITHOUT TPM-RKE ANALYZER CHECK TIRE PRESSURE MONITORING (TPM) SENSOR ID(S) Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values. Repeat the above step on each wheel of the vehicle. Using the scan tool, erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM data and allow for the system to update. Using the scan tool, check to see if the TPM IDs are programmed into the WIN. Are the TPM Sensor IDs in the WIN? Yes Test complete. Perform the VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the TPM VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
5. INTERMITTENT TIRE PRESSURE SENSOR DTC NOTE: The DTC can be caused by many different factors and might not be a sensor/transmitter or a WIN fault. Interference from other elements will over power the sensor/transmitter RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Perform any Technical Service Bulletins that may apply to this condition. Using the scan tool, erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM data and allow for the system to update. Using the scan tool, read DTCs. Does the DTC reset or is the status Active for this DTC? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.

Scheme 65

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The brake switch signal must be active before the shift lever can be moved out of the park position. The Shifter Lever Assembly (SLA) Electronic Shift Module (ESM) receives two brake switch signals. The first signal is a CAN C Bus message sent to the shifter lever assembly. The second signal is a hard wired Brake Transmission Switch Interlock (BTSI) Control signal to the shifter lever assembly from the Wireless Ignition Node (WIN). The CAN C Bus message is the primary brake switch signal and the hard wired signal serves as the backup brake switch signal. These two brake switch signals are compared against each other to verify proper brake switch operation.

Continuously with the ignition on.

The Diagnostic Trouble Code (DTC) will set if the WIN detects a short to ground, open or disconnected (K321) BTSI Control circuit, for more than 10 seconds.

Always perform the NAG1 Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. ENGINE DTCS PRESENT With the scan tool, read the PCM DTCs. Are there any Powertrain Control Module (PCM) brake related DTCs present? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK THE (K321) BTSI CONTROL CIRCUIT Turn the ignition off to the lock position. Disconnect the Shifter Lever Assembly harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on, engine not running. Using a 12-volt test light connected to ground, check the (K321) BTSI Control circuit in the Shifter Lever Assembly connector. With the scan tool under WIN, actuate the BTSI. Does the test light illuminate brightly on and off while cycling the (K321) BTSI Control circuit? Yes Replace the Shifter Lever Assembly in accordance with the Service Information. Refer to «SHIFTER, TRANSMISSION , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/automatic-trans/#nag1-automatic-transmission-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 3 .
3. (K321) BTSI CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off to the lock position. Disconnect the WIN harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance between ground and the (K321) BTSI Control circuit in the Shifter Lever harness connector. Measure the resistance between ground and the (K321) BTSI Control circuit in the WIN harness connector. Is the resistance below 10K Ohms in either connector? Yes Repair the (K321) BTSI Control circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 4 .
4. (K321) BTSI CONTROL CIRCUIT OPEN Measure the resistance of the (K321) BTSI Control circuit between the Shifter Lever Assembly harness connector and the WIN harness connector. Is the resistance above 2.0 Ohms? Yes Repair the (K321) BTSI Control circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 5 .
5. (K321) BTSI CONTROL CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage between ground and the (K321) BTSI Control circuit. Is there any voltage present? Yes Repair the (K321) BTSI Control circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

U0001-CAN C BUS

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

Whenever the CAN C Bus (+) or CAN C Bus (-) circuit is open, shorted to voltage or shorted to ground.

1. CHECK FOR ACTIVE DTCS With the scan tool, read the active WIN DTCs. Cycle the ignition switch from off to on at least 3 times, leaving the ignition on for a minimum of one minute per cycle. With the scan tool, read the active WIN DTCs. Does the scan tool display: U0001-CAN C BUS as active? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) , and perform the U0001-CAN C Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) , and perform the Stored Lost Communication DTCs diagnostic procedure.

U0037-LIN BUS

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

The module detects a short to ground, voltage or an open circuit on the Com-LIN Tire Pressure Monitor Lan (LIN Bus) circuit.

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

1. VERIFY DTC IS ACTIVE Turn the ignition on. With the scan tool, record and erase the Wireless Ignition Node (WIN) DTCs. Cycle the ignition from on to off to on three times. Wait 30 seconds. With the scan tool, read the active Wireless Ignition Node (WIN) DTCs. Does the scan tool display: U0037-LIN BUS as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
2. CHECK THE RAIN SENSOR Turn the ignition off. Disconnect the Rain Sensor harness connector. NOTE: If this vehicle is not equipped with a Rain Sensor, go to the next step. Turn the ignition on. With the scan tool, erase the Wireless Ignition Node (WIN) DTCs. Cycle the ignition from on to off to on three times. Wait 30 seconds. With the scan tool, read the active Wireless Ignition Node (WIN) DTCs. Does the scan tool display active: U0037-LIN BUS? yes Go To 3 . No Replace the Rain Sensor in accordance with the Service Information. Refer to «MODULE, LIGHT RAIN SENSOR (LRSM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wiperwasher-systems/#wiper-system-washer-system-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. STEERING COLUMN LOCK MODULE Turn the ignition off. Disconnect the Steering Column Lock Module (ELV) connector. NOTE: If this vehicle is not equipped with a Steering Wheel Lock Module (BUX), go to the next step. Turn the ignition on. With the scan tool, erase the Wireless Ignition Node (WIN) DTCs. Cycle the ignition from on to off to on three times. Wait 30 seconds. With the scan tool, read the active Wireless Ignition Node (WIN) DTCs. Does the scan tool display active: U0037-LIN BUS? Yes Go To 4 . No Replace the Steering Column Lock Module in accordance with the service information. The Wireless Ignition Node (WIN) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WIN and the Steering Column Lock Module (ELV), the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. (D508) LIN BUS CIRCUIT SHORTED TO THE (Z912) GROUND CIRCUIT Turn the ignition off. Disconnect the Wireless Ignition Node harness connector. Measure the resistance between the (D508) LIN Bus circuit and the (Z912) Ground circuit in the WIN connector. Is the resistance below 10K Ohms? Yes Repair the (D508) LIN Bus circuit for a short to the (Z912) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 5 .
5. (D508) LIN BUS CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage between ground and the (D508) LIN Bus circuit in the WIN connector. Is there any voltage present? Yes Repair the short to voltage in the (D508) LIN Bus circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 6 .
6. (D508) LIN BUS CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (D508) LIN Bus circuit between the WIN connector and the Rain Sensor or the Steering Column Lock Module (ELV) (BUX) (if equipped) connector. Is the resistance below 5.0 Ohms? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module (ELV), the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the open in the (D508) LIN Bus circuit. Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .

U0100-LOST COMMUNICATION WITH THE ECM/PCM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Powertrain Control Module (PCM/ECM) for approximately two to five seconds.

1. ACTIVE DTC Ignition on, engine not running. With the scan tool, select view DTCs. Does the scan tool display as active: U0100-LOST COMMUNICATION WITH THE ECM/PCM? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) , and perform the U0100-Lost Communication with PCM diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) , and perform the Stored Lost Communication DTCs diagnostic procedure.

U0121-LOST COMMUNICATION WITH ABS

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Anti Lock Brake Module (ABS) for approximately two to five seconds.

1. ACTIVE DTC Ignition on, engine not running. With the scan tool, select view DTCs. Is the DTC Active at this time? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) , and perform the U0121-Lost Communication with Anti-Lock Brake Module diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) , and perform the Stored Lost Communication DTCs diagnostic procedure.

U0146-LOST COMMUNICATION WITH CENTRAL GATEWAY (TIPM)

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

The battery voltage between 10.0 and 16.0 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display active: U0146-LOST COMMUNICATION WITH CENTRAL GATEWAY? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) , and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) , and perform the Stored Lost Communication DTCs diagnostic procedure.

U0231-LOST COMMUNICATION WITH LIGHT RAIN SENSING MODULE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

Ignition Off Draw (IOD) fused installed.

Bus messages not received from the Rain Sensing Module for approximately two to five seconds.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. With the scan tool, record and erase the WIN DTCs. Cycle the ignition switch from on to off three times then back to on. Start the engine and run for two minutes. With the scan tool, read the active WIN DTCs. Does the scan tool display: U0231-LOST COMMUNICATION WITH LIGHT RAIN SENSING MODULE? Yes Go To 2 . No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) , and perform the Stored Lost Communication DTCs diagnostic procedure.
2. (F981) FUSED IGNITION SWITCH OUTPUT OPEN NOTE: Be sure the battery is fully charged before proceeding. Turn the ignition off. Disconnect the Rain Sensor harness connector. Turn the ignition on. Measure the voltage between ground and the (F981) Fused Ignition Switch Output circuit in the Rain Sensor harness connector. Is the voltage above 12.0 volts? Yes Go To 3 . No Repair the (F981) Fused Ignition Switch Output circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. (Z919) GROUND CIRCUIT OPEN Using the a 12 volt test light connected to 12 volts, check the (Z919) Ground circuit. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (Z919) Ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
4. CHECK THE VOLTAGE OF THE (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT Measure the voltage between the (D508) COM-Lin Tire Pressure Monitor LAN circuit and ground in the Rain Sensor connector. Is the voltage below 7.0 volts? Yes Go To 5 . No Replace the Rain Sensor in accordance with the Service Information. Refer to «MODULE, LIGHT RAIN SENSOR (LRSM) , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/wiperwasher-systems/#wiper-system-washer-system-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
5. (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN Turn the ignition off. Disconnect the WIN Module harness connector. Measure the resistance of the (D508) COM-Lin Tire Pressure Monitor LAN circuit between the WIN Module harness connector and the Rain Sensor harness connector. Is the resistance below 2.0 Ohms? Yes Replace the Wireless Ignition Node (WIN) in accordance with the Service Information. If this vehicle is equipped with a Steering Column Lock Module (BUX), it must also be replaced in accordance with the Service Information. When replacing the WIN and the Steering Column Lock Module, the Win MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair the (D508) COM-Lin Tire Pressure Monitor LAN circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

U0236-LOST COMMUNICATION WITH COLUMN LOCK MODULE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

If the Wireless Ignition Node (WIN) does not receive the correct response message back from the Steering Column Lock Module.

1. INTERMITTENT DIAGNOSTIC TROUBLE CODE (DTC) Using the scan tool, erase the current WIN DTCs. Turn the ignition off. Arm the Vehicle Theft and Security System (VTSS) and wait one minute. Disarm the VTSS and turn the ignition on. Using the scan tool, read the WIN DTCs. Does the scan tool display active; U0236-LOST COMMUNICATION WITH COLUMN LOCK MODULE? Yes Go To 2 . No Perform the STORED LOST COMMUNICATION DTCS TEST. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) .
2. (A106) FUSED B(+) CIRCUIT OPEN Gain access to the Steering Column Lock Module. Disconnect the Steering Column Lock Module connector. Using a 12-volt test light connected to ground, check the (A106) Fused B(+) circuit (Cavity 1) in the Steering Column Lock Module connector. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (A106) Fused B(+) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. (F892) IGNITION SWITCH OUTPUT (KEY-IN) CIRCUIT OPEN Disconnect the WIN harness connector. Measure the resistance of the (F982) Ignition Switch Output (Key-In) circuit between (Cavity 9) in the WIN module and (Cavity 3) in the Steering Column Lock Module. Is the resistance below 2.0 Ohms? Yes Go To 4 . No Repair the (F892) Ignition Switch Output (Key-In) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
4. (Z912) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check the (Z912) Ground circuit (Cavity 2) in the Steering Column Lock Module connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (Z912) Ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
5. (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN Measure the resistance of the (D508) COM-LIN Tire Pressure Monitor LAN circuit between (Cavity 2) in the WIN module and (Cavity 4) in the Steering Column Lock Module. Is the resistance below 2.0 Ohms? Yes Replace the Steering Column Lock Module in accordance with the service information. The Wireless Ignition Node (WIN) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WIN and the Steering Column Lock Module (ELV), the WIN MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Ignition Node (WIN). Refer to «RECEIVER, WIRELESS IGNITION NODE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#vehicle-theft-security-service-information) . Perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Repair the (D508) COM-LIN Tire Pressure Monitor LAN circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

U1197-SECURITY SEED RESPONSE NOT RECEIVED FROM ECM/PCM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Whenever a Fob Integrated Key (FOBIK) is inserted in the Wireless Ignition Node (WIN), the WIN performs a self test and resynchronization routine. During the routine, the WIN interrogates the FOBIK for the secret key information and performs a CAN Bus message handshake with the Powertrain Control Module (PCM). The PCM must reply to the WIN that the secret key information matches to initiate the start sequence or this code will set on the third attempt.

Whenever a FOBIK is rotated to the Run position.

This DTC sets if the WIN does not receive a CAN Bus message from the ECM/PCM. This code will set on the 20th start attempt.

1. VERIFY PCM PROGRAMMING Using the scan tool, record and erase all DTCs in the PCM. Turn the Ignition Off, and wait fifteen seconds before turning the Ignition On. Wait one minute, and read the active PCM DTCs. Does the scan tool display: U1197-SECURITY SEED RESPONSE NOT RECEIVED FROM ECM/PCM as active? Yes Perform the PCM/ECM REPROGRAMMING procedure. Refer to «PCM REPROGRAMMING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information__pcm-reprogramming) . Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-intermittent-condition-pcmecm-reprogramming-gas-powertrain-verification-test-pre-diagnostic-troubleshooting-proc) or «PCM VERIFICATION TEST - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) . No Repair is complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

WIRELESS IGNITION NODE (WIN) INTERMITTENT TEST

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. RECORD AND ERASE ALL WIN DIAGNOSTIC TROUBLE CODES (DTCS) Using the scan tool, record and erase all DTCs from the WIN. Monitor for any active codes as you work through the following steps. Review the code monitor and set conditions for any DTCs that are stored and attempt to reproduce the conditions listed. Wiggle the wiring harness and connectors of the related circuit, sensor or component. Turn the ignition off. Perform any Technical Service Bulletins (TSBs) that may apply. Was the source of the customer complaint found or did any DTCs appear and stay active? Yes Make the appropriate repairs and perform the WIN VERIFICATION TEST, or, refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) , and perform the appropriate diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No Go To 2 .
2. ATTEMPT TO REPRODUCE THE CONDITION In the event the customer complaint cannot be duplicated due to an intermittent condition in the theft/security system, the following may aid in attempting to reproduce the condition. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors related to the stored code or component in question. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. If the customer concern was related to a specific Fob-Integrated-Key (FOBIK), ensure the FOBIK in question is used while attempting reproduce the condition. Reconnect any disconnected components and harness connectors and ensure they are properly seated. If numerous trouble codes were set, use a schematic and inspect any common ground or supply circuits. Was the source of the intermittent condition located? Yes Make the appropriate repairs and perform the WIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) . No The problem cannot be found at this time. If repeated intermittent failures are encountered that cannot be reproduced and the condition has prompted multiple customer visits to the dealership, document any findings on the repair order.

WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE

Before attempting to repair any WIN system, technicians should be familiar with and fully understand the system operation. for complete details. Refer to OPERATION . The following should be used as a checklist to be completed in its entirety prior to referencing specific WIN diagnostic procedures.

1. FOLLOW THE BASIC OUTLINE SET FORTH IN THE SIX-STEP TROUBLESHOOTING PROCEDURE Verification of complaint. Verification of any related symptoms. Symptom analysis. Problem isolation. Repair of isolated problem. Verification of proper operation.
2. TAKE INTO ACCOUNT CURRENT VEHICLE CONDITION, REPAIR HISTORY, AND TECHNICAL SERVICE BULLETINS (TSBs) Verify there are no outward signs of vehicle damage that could impact the proper operation of the theft or security system. Check for aftermarket vehicle accessories that may have been installed improperly or could interfere with the system Check the vehicle repair history for repairs that may relate to the current condition. Perform a check of current Technical Service Bulletins (TSB) for the WIN system related to the customer concern. If a TSB applies, follow the procedure outlined in the TSB.
3. DIAGNOSE ONLY THOSE FAILURES THAT ARE ACTIVE AND CAN BE REPRODUCED Check the control module that is central to the subsystem which is exhibiting the condition for the active DTCs. For an intermittent failure that is not current at the time of vehicle inspection, and perform the WIN INTERMITTENT TEST and document the event on the repair order. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/door-locks-anti-theft-systems/#wireless-ignition-node-win-electrical-diagnostics) .
4. ADDRESS ACTIVE DIAGNOSTIC TROUBLE CODES (DTCS) IN THE CORRECT ORDER As a general rule, for any WIN module that exhibits more than one active DTC, address the codes in the order indicated: Low/High Voltage and Serial Data Loss of Communication Codes Module Internal Failure and Configuration Mismatch Codes Circuit specific DTC failures Should the malfunction still be present after conducting this Pre-diagnostic Procedure, technicians should continue to the appropriate DTC procedure or symptom diagnostic.

WIN VERIFICATION

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Perform the following after completion of a diagnostic repair

Note. When entering the Personal Identification Number (PIN), care should be taken because the WIN will only allow three consecutive attempts to enter the correct PIN. If three consecutive incorrect PINs are entered the WIN will Lock Out the scan tool. To exit Lock Mode, the ignition key must remain in the Run position for one hour. All accessories must be off. A battery charger connected to the battery during this time period is recommended.

Note. On vehicles equipped with a Base Tire Pressure Monitoring (TPM) system, when the WIN and/or the spare tire pressure sensor is replaced with a new unit, a diagnostic scan tool MUST be used to run a routine that allows the WIN to be programmed with the ID number and location of the spare tire pressure sensor mounted in the wheel of the spare tire. Follow the programming steps outlined in the diagnostic scan tool for "Learn Spare Tire Sensor ID" under "Miscellaneous Functions" for the "WIN" menu item as appropriate. In addition, if the WIN is replaced, the spare tire must be dismounted from its wheel to access and note the ID number on the spare tire pressure sensor so that the ID code for that sensor can be programmed into the new WIN.

1. Reconnect the previously disconnected components and connectors.
2. Obtain the vehicle's unique Personal Identification Number (PIN) assigned to it's original WIN. This number can be obtained from the original vehicle invoice or from your Service Manager or Parts Manager.

PCM & WIN REPLACEMENT

Note. If the Powertrain Control Module (PCM) and the WIN are replaced at the same time, program the PCM VIN into the PCM first.

Note. The PCM stores the secret key information. If the WIN ever needs to be replaced, the secret key information can be retrieved from the PCM and then transferred to the WIN for security use.

During PCM/ECM replacement, use the following steps to verify the transfer of the secret key information from the WIN to the new PCM

1. If the PCM is to be replaced, first, replace the PCM/ECM with the original WIN still connected to the vehicle. If the PCM is not being replaced, go to step 3.
2. Using the appropriate Service Information to program the new PCM/ECM. (This will verify the Secret Key Transfer from the original WIN into the new PCM/ECM).
3. Now replace and program (WIN Replaced) the WIN (if necessary). This will cause the WIN to receive the Secret Key from the PCM/ECM back into the new WIN. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WIN. Whenever a WIN is replaced the Steering Wheel Lock Module MUST also be replaced.
4. Using the scan tool, select Miscellaneous Functions, WIN. Then select the desired procedure and follow the display on the scan tool.
5. If the vehicle is equipped with the Base Tire Pressure Monitoring System, program the Placard Pressure Values into the WIN.
6. Make sure all the customer's keys have been programmed into the new module if necessary. NOTE: If the WIN module was replaced and the vehicle is equipped with the Passive Entry System (PEM), with the scan tool, perform the "PEM Replace" routine in the PEM after the FOBIKS have been programmed.
7. Using the scan tool, erase all DTCs. Perform five ignition key cycles, leaving the key on for at least 90 seconds per cycle.
8. Using the scan tool, read WIN DTCs.

1. Are there any WIN DTCs present? Yes Repair not complete, go to the appropriate diagnostic information and perform the appropriate diagnostic procedure. No Repair is complete.

TPM VERIFICATION

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. TIRE PRESSURE MONITORING (TPM) Was the Wireless Ignition Node (WIN) replaced during the test procedure? Yes Go To 2 . No Go To 3 .
2. WIRELESS IGNITION NODE (WIN) NOTE: When entering the PIN, care should be taken because the WIN will only allow three consecutive attempts to enter the correct PIN. If three consecutive incorrect PIN's are entered the WIN will Lock Out the scan tool. To exit Lock Mode, the ignition key must remain in the Run position for one hour. All accessories must be off. A battery charger connected to the battery during this time period is recommended. Reconnect the previously removed and/or disconnected components and connectors. Obtain the vehicle's unique Personal Identification Number (PIN) assigned to its original WIN. This number can be obtained from the vehicle invoice or from the Chrysler Customer Center (Phone 1-800-992-1997). With the scan tool, select Miscellaneous Functions, Wireless Ignition Node (WIN). Then select the desired procedure and follow the display on the scan tool. If the WIN was replaced, all the customer's keys must be programmed to the new module. Use the scan tool and the Program Key procedure With the scan tool, erase all DTCs. Perform five ignition key cycles, leaving the key on for at least 90 seconds per cycle. Drive the vehicle for a minimum of 10 minutes while maintaining a continuous speed above 15 mph (24 km/h). During this time the system will learn the new sensor ID code and will clear any DTC(s) automatically. With the scan tool, read DTCs. Are there any DTCs present? Yes Repair not complete, perform the appropriate diagnostic procedure. No Repair is complete.
3. TIRE PRESSURE SENSOR REPLACE Reconnect the previously removed and/or disconnected components and harness connectors. If available, use a TPM-RKE Analyzer tool with the scan tool to program the WIN with the tire pressure sensors ID's on the vehicle. Drive the vehicle for a minimum of 10 minutes while maintaining a continuous speed above 15 mph (24 km/h). During this time the system will learn the new sensor IDs. With the scan tool, read DTCs. Are there any DTCs present? Yes Repair not complete, perform the appropriate diagnostic procedure. No Repair is complete.

See also:
• STANDARD PROCEDURE
• DIAGNOSIS AND TESTING
• RECEIVER, WIRELESS IGNITION NODE , REMOVAL
• MODULE, SHAFT LOCK , REMOVAL
• DIAGNOSTIC CODE INDEX - 3.0L DIESEL
• DIAGNOSTIC CODE INDEX - NGC
• POWERTRAIN VERIFICATION TEST - NGC
• PCM VERIFICATION TEST - 3.0L DIESEL
• ANTENNA, REMOTE START , REMOVAL
• DIAGNOSIS AND TESTING
• SENSOR, TIRE PRESSURE MONITORING (TPM) , REMOVAL
• STANDARD PROCEDURE
• SHIFTER, TRANSMISSION , REMOVAL
• DIAGNOSIS AND TESTING
• PCM REPROGRAMMING
• OPERATION
• B1A08
• B1A09
• B1A0A
• B1A0B
• B1A0C
• B1A0D
• B1A0E
• B1A0F
• B1A10
• B1A11
• B1A12
• B1A13
• B1A14
• B1A15
• B1A16
• B1A17
• B1A24
• B1A25
• B1A26
• B1A27
• B1A28
• B1A29
• B1A35
• B1A68
• B1A6B
• B1A6C
• B1A77
• B1A79
• B210A
• B210B
• B210D
• B210E
• B2204
• B2205
• B221D
• B2224
• B2254
• C0077
• C1501
• C1502
• C1503
• C1504
• C151C
• U0001
• U0037
• U0100
• U0121
• U0146
• U0231
• U0236
• U1197
• WIRELESS IGNITION NODE (WIN) PRE-DIAGNOSTIC PROCEDURE
