TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Balance Shaft Module | Refer to PUMP, ENGINE OIL, INSTALLATION | ||
| Bell Housing-Bolts | 48 | 35 | |
| Camshaft Bearing Cap-Bolts | |||
| M6 Bolts | 12 | 106 | |
| M8 Bolts | 30 | 22 | |
| Coils | 8 | 71 | |
| Connecting Rod Cap-Bolts | 20 + 90° | 15 + 90° | |
| Coolant Temperature Sender | 18 | 13 | |
| Crankshaft Main Bearing Cap-Bolts | Refer to INSTALLATION | ||
| Crankshaft Damper-Bolt | 210 | 155 | |
| Cylinder Head-Bolts | Refer to INSTALLATION | ||
| Cylinder Head Cover-Bolts | Refer to INSTALLATION | ||
| Engine Support Bracket-Bolts | 48 | 36 | |
| Exhaust Manifold-Bolts | 34 | 25 | |
| Exhaust Manifold Heat Shield-Bolts | |||
| M6x25mm Bolts | 7 | 62 | |
| M6x70mm Bolts | 9 | 80 | |
| Flex Plate to Crankshaft-Bolts | 29 + 51° | 22 + 51° | |
| Intake Manifold-Bolts | 24 | 18 | |
| Ladder Frame | 22 | 16 | |
| Oil Cooler Connector Bolt | 49 | 36 | |
| Oil Filter | 14 | 10 | |
| Oil Filter Nipple | 49 | 36 | |
| Oil Jet Fastener | 12 | 106 | |
| Oil Pan-Bolts | |||
| M6 Bolts | 9 | 80 | |
| M8 Bolts | 24 | 18 | |
| Oil Pan Drain-Plug | 27 | 20 | |
| Oil Pressure Switch | 8 | 71 | |
| PCV Valve | 5 | 44 | |
| Phaser to Camshaft-Bolt | 75 | 55 | |
| Spark Plugs | 27 | 20 | 239 |
| Timing Chain Cover | |||
| M6 Bolts | 9 | 80 | |
| M8 Bolts | 26 | 19 | |
| Timing Chain Tensioner Assembly-Bolts | 10 | 89 | |
| Timing Chain Guides | 12 | 106 | |
Scheme 1
- Remove engine cover (1) by pulling upwards.
OIL FILTER SPECIFICATION
All engines are equipped with a high quality full-flow, disposable type oil filter. Replace oil filter with a Mopar® or the equivalent.
