Engine Emission Control (Without Supercharger): Specifications Jaguar XKR II

Engine Control Systems 1 illustration

Specifications

ItemNm
Exhaust gas recirculation (EGR) tube to EGR valve - bolt21
EGR tube to exhaust manifold - nut21
EGR valve to throttle body elbow - bolt10
Positive crankcase ventilation (PCV) valve - screw5
Secondary air injection, air pipe - union nut35
Secondary air injection, blanking plug35
Secondary air injection, control valve bracket to engine - bolt8
Secondary air injection, manifold absolute pressure sensor to bonnet hinge panel - bolt11
Secondary air injection, pump to bracket - nut8

Torque Specifications

Scheme 106

Scheme 106: COMPONENT LOCATION
Scheme 106: COMPONENT LOCATION
Item NumberDescription
1Valve
2Gas transfer pipe
3Part load valve
4Electric throttle
5Valve
