Specifications
| Item | Nm |
|---|---|
| Camshaft position sensor - bolt | 7 |
| Catalyst monitor sensor | 45 |
| Crankshaft position sensor - screw | 7 |
| Engine control module | 10 |
| Fuel rail pressure sensor | 5 |
| Fuel temperature sensor | 7 |
| Heated oxygen sensor | 45 |
| Knock sensor - nut | 20 |
| Knock sensor - stud | 10 |
| Oil pressure sensor | 15 |
| Oil temperature sensor | 15 |
| Variable camshaft timing, oil control solenoid - bolt | 10 |
Torque Specifications
Scheme 48
| Item Number | Description |
|---|---|
| 1 | Fuel rail pressure sensor |
| 2 | Fuel rail temperature sensor |
| 3 | Sensor |
| 4 | Injector |
| 5 | Purge valve |
| 6 | Sensor |
| 7 | Sensor |
| 8 | |
| 9 | Sensor |
| 10 | / sensor |
| 11 | Downstream |
| 12 | Upstream |
| 13 | Electric throttle |
| 14 | Oil temperature sensor |
| 15 | Oil pressure sensor |
| 16 | Valve |
| 17 | Secondary air injection pump |
| 18 | Secondary air injection valve |
| 19 | Variable Vale timing solenoid |
| 20 | Ignition coil |
| 21 | Knock sensor |
| 22 | Valve |
Scheme 49
| Item Number | Description |
|---|---|
| 1 | Power distribution box |
| 2 | Adaptive speed control sensor (where fitted) |
| 3 | Sensor |
| 4 | Adaptive speed control module (where fitted) |
| 5 | |
| 6 | Auxiliary junction box |
| 7 | |
| 8 | |
| 9 |
