Specifications
| Item | Nm |
|---|---|
| Camshaft position sensor - bolt | 7 |
| Catalyst monitor sensor | 45 |
| Crankshaft position sensor - screw | 7 |
| Engine control module | 10 |
| Fuel rail pressure sensor | 5 |
| Fuel temperature sensor | 7 |
| Heated oxygen sensor | 45 |
| Knock sensor - nut | 20 |
| Knock sensor - stud | 10 |
| Oil pressure sensor | 15 |
| Oil temperature sensor | 15 |
| Variable camshaft timing, oil control solenoid - bolt | 10 |
Torque Specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Fuel rail pressure sensor |
| 2 | Injector |
| 3 | Fuel rail temperature sensor |
| 4 | Knock sensor |
| 5 | Camshaft Position (CMP) sensor |
| 6 | Electric throttle |
| 7 | Exhaust Gas Recirculation (EGR) valve |
| 8 | Manifold Absolute Pressure sensor |
| 9 | Purge valve |
| 10 | Camshaft Position (CMP) sensor |
| 11 | Engine Control Module (ECM) |
| 12 | Crankshaft Position (CKP) sensor |
| 13 | Downstream Heated Oxygen Sensor (HO2S) |
| 14 | Upstream Heated Oxygen Sensor (HO2S) |
| 15 | Mass Air Flow(MAF)/Intake Air Temperature (IAT) sensor |
| 16 | Secondary air injection valve |
| 17 | Oil temperature sensor |
| 18 | Oil pressure sensor |
| 19 | Secondary air injection pump |
| 20 | Mass Air Flow(MAF)/Intake Air Temperature (IAT) sensor |
| 21 | Variable valve timing solenoid |
| 22 | Ignition coil |
| 23 | Positive Crankcase Ventilation (PCV) valve |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | Power distribution box |
| 2 | Adaptive speed control sensor (where fitted) |
| 3 | Accelerator Pedal Position (APP) sensor |
| 4 | Adaptive speed control module (where fitted) |
| 5 | Fuel Pump Driver Module (FPDM) |
| 6 | Auxiliary junction box |
| 7 | Central Junction Box (CJB) |
| 8 | Engine Control Module (ECM) |
| 9 | Battery Junction Box (BJB) |
