Automatic Transmission/transaxle: Maintenance Jaguar XKR II

Automatic Trans 5 illustrations ~1119 words

FLUID PUMP

The fluid pump is an integral part of the transmission. The fluid pump is used to supply hydraulic pressure for the operation of the control valves and clutches, to pass the fluid through the transmission cooler and to lubricate the gears and shafts.

The 6HP26 fluid pump is a crescent type pump and is located between the intermediate plate and the torque converter. The pump has a delivery rate of 16 cm 3 per revolution.

Scheme 22

Scheme 22: FLUID PUMP
Item NumberDescription
1Securing ring
2Shaft oil seal
3O-ring seal
4Pump housing
5Ring gear
6Crescent spacer
7Roller bearing
8Impeller
9Centering pin
10Spring washer
11Outlet port (high pressure)
12Inlet port (low pressure)

The pump comprises a housing, a crescent spacer, an impeller and a ring gear. The housing has inlet and outlet ports to direct flow and is located in the intermediate plate by a centering pin. The pump action is achieved by the impeller, ring gear and crescent spacer.

The crescent spacer is fixed in its position by a pin and is located between the ring gear and the impeller. The impeller is driven by drive from the torque converter hub which is located on a needle roller bearing in the pump housing. The impeller teeth mesh with those of the ring gear. When the impeller is rotated, the motion is transferred to the ring gear which rotates in the same direction.

The rotational motion of the ring gear and the impeller collects fluid from the intake port in the spaces between the teeth. When the teeth reach the crescent spacer, the oil is trapped in the spaces between the teeth and is carried with the rotation of the gears. The spacer tapers near the outlet port. This reduces the space between the gear teeth causing a build up of fluid pressure as the oil reaches the outlet port. When the teeth pass the end of the spacer the pressurized fluid is released into the outlet port.

The fluid emerging from the outlet port is passed through the fluid pressure control valve. At high operating speeds the pressure control valve maintains the output pressure to the gearbox at a predetermined maximum level. Excess fluid is relieved from the pressure control valve and is directed, via the main pressure valve in the valve block, back to the pump inlet port. This provides a pressurized feed to the pump inlet which prevents cavitation and reduces pump noise.

Fluid Level and Condition Check

CAUTIONThe vehicle should not be driven if the fluid level is low as internal failure can result.

Note. The transmission fluid temperature must not be allowed to exceed 50°C (122°F) whilst checking level. Should the temperature rise above this figure, abort the check and allow the transmission fluid to cool to below 30°C (86°F).

This vehicle is not equipped with a fluid level indicator. An incorrect level may affect the transmission operation and could result in transmission damage. To correctly check and add fluid to the transmission. See Transmission Fluid Level Check .

High Fluid Level

A fluid level that is too high may cause the fluid to become aerated due to the churning action of the rotating internal parts. This will cause erratic control pressure, foaming, loss of fluid from the vent tube and possible transmission damage. If an overfill condition is identified, with the engine at idle ensure the fluid temperature is within the specified range and allow the excess fluid to drain until a small thread of fluid runs from the filler/level plug hole.

Low Fluid Level

A low fluid level could result in poor transmission engagement, slipping, or damage. This could also indicate a leak in one of the transmission seals or gaskets. See Transmission Fluid Level Check .

Adding Fluid

CAUTIONThe use of any other type of transmission fluid other than that specified can result in transmission damage.

If fluid needs to be added, add fluid in 0.50 liter increments through the fill hole opening. Do not overfill the fluid. For fluid type, refer to Specifications .

Fluid Condition Check

  1. Check the fluid level. See «Transmission Fluid Level Check»(ref-312552-S13288918512009041400000) .
  2. Observe the color and the odor of the fluid. The color under normal circumstances should be like honey, not brown or black.
  3. Allow the fluid to drip onto a facial tissue and examine the stain.
  4. If evidence of solid material is found, the transmission fluid pan should be removed for further inspection.

NOTE: In the event of a transmission unit replacement for internal failure, the oil cooler and pipes must also be replaced.

Transmission Fluid Drain and Refill - General Procedures

Special Tools Tool Illustration Tool Name Tool Number Adaptor 307-452

WARNINGObserve due care when draining, as the fluid can be very hot.
WARNINGObserve due care when working near a hot exhaust system.

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26
  1. Raise and support the vehicle.
  2. Remove the RH transmission heat shield. Remove the 2 bolts.
  3. Clean the area around the transmission fluid drain and filler plugs.
  4. Place a container under the transmission.
  5. Using the special tool, remove the transmission fluid filler/level plug. Remove and discard the sealing washer.
  6. Remove the transmission fluid drain plug. Remove and discard the sealing washer. Allow the fluid to drain.
  7. Install the transmission fluid drain plug and tighten to 8 Nm (6 lb.ft). Install a new sealing washer.
  8. Add the correct transmission fluid, until a small thread of fluid runs from the filler/level hole.
  9. Start and run the engine.
  10. Add the correct transmission fluid, until a small thread of fluid runs from the filler/level hole.
  11. Check and top-up the transmission fluid level. See «Transmission Fluid Level Check»(ref-312552-S13288918512009041400000) .

Transmission Fluid Level Check - General Procedures

Special Tools Tool Illustration Tool Name Tool Number Adaptor 307-452

WARNINGObserve due care when draining, as the fluid can be very hot.
WARNINGObserve due care when working near a hot exhaust system.
CAUTIONThe gearbox fluid level must only be checked when the temperature of the fluid is between 30 degrees and 50 degrees. The fluid level obtained will be incorrect if the reading is outside this temperature range.
  1. The following steps must be observed before starting the transmission fluid level check and top-up. The vehicle must be on a horizontal ramp. The parking brake must be applied. The wheels must be chocked.
  2. Connect WDS to the on-board diagnostic connector, to monitor the transmission fluid temperature.
  3. Start the engine. Move the selector lever from 'P' through all gear positions, pausing in each gear position for 2-3 seconds and return to the 'P' position.
  4. Raise and support the vehicle.
  5. Remove the RH transmission heat shield. Remove the 2 bolts.
  6. Place a container under the transmission.
  7. Using the special tool, remove the transmission fluid filler/level plug. Clean the area around the filler/level plug. Remove and discard the sealing washer.
  8. If no fluid loss is apparent when the filler/level plug is removed, with the engine at idle, continue to fill the transmission until a small thread of oil runs from oil filler/level hole.
  9. Install the transmission fluid filler/level plug and tighten to 35 Nm (26 lb.ft). Install a new sealing washer. Step 1. Multiply 35 Nm by the effective length of the torque wrench (1). Step 2. Add the effective length of the special tool (2) to the effective length of the torque wrench (2). Step 3. Divide the total of step 1 by the total of step 2. Step 4. Set the torque wrench to the figure arrived at in step 3.
  10. Install the transmission heat shield. Tighten the bolts to 10 Nm (7 lb.ft).
  11. Disconnect WDS from the vehicle.
