Automatic Transmission/transaxle External Controls: Removal & Installation Jaguar XKR II

Removal

1. Remove the paddle gear selector lever. See «Upshift Paddle Switch»(ref-312593-S15332560772009041400000) .

Installation

1. To install, reverse the removal procedure.

Scheme 71

Scheme 72

Scheme 73

1. Remove the rear seat armrest. Refer to «Rear Seat Armrest»(ref-312549-S32221670662009041400000) article.
2. Remove the floor console veneer trim panel. Refer to «Floor Console Finish Panel»(ref-312550-S23819977062009041400000) article.
3. Remove the floor console rear panel. Carefully release the 2 clips.
4. Remove the floor console side panel trim. Remove the 2 Torx bolts. Carefully release 11 clips. Repeat the procedure and remove the opposite hand.
5. Release the LH side floor console electrical harness connector blocks. Carefully release the 4 clips.
6. Disconnect the gear selector assembly electrical connector.
7. Remove the gear selector assembly. Carefully disconnect the selector cable ball joint. Remove the 4 Torx bolts. Release the electrical harness.

1. Install the gear selector assembly. Position the electrical harness. Install the Torx bolts and tighten to 6 Nm (4 lb.ft). Connect the selector cable ball joint.
2. Connect the gear selector assembly electrical connector.
3. Install the LH side floor console electrical harness connector blocks. Carefully align and secure the clips.
4. Install the floor console side panel trim. Carefully align and secure the clips. Tighten the Torx screws to 6 Nm (4 lb.ft). Install the opposite hand.
5. Install the floor console rear panel. Align the lugs and secure the clips.
6. Install the floor console veneer trim panel. Refer to «Floor Console Finish Panel»(ref-312550-S23819977062009041400000) article.
7. Install the rear seat armrest. Refer to «Rear Seat Armrest»(ref-312549-S32221670662009041400000) article.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Remove the floor console. Refer to «Floor Console»(ref-312550-S37039950832009041400000) article.
2. Release the transmission selector lever cable. Release the gaiter. Pass the gear selector cable through the vehicle floor. Tie the recovery line to the floor console ground nut.
3. Raise and support the vehicle.
4. Release the exhaust heat shield for access. Remove the 4 bolts.
5. Position the LH side transmission casing heat shield aside. Remove the 2 bolts.
6. Remove the selector cable and bracket. Carefully disconnect the selector cable ball joint. Remove the 2 bolts. Withdraw the cable. Disconnect the recovery line.

1. Install the selector cable and bracket. Connect the recovery line to the transmission selector cable. Install the bolts and tighten to 10 Nm (7 lb.ft). Connect the selector cable ball joint.
2. Install the LH side transmission casing heat shield. Install the bolts and tighten to 10 Nm (7 lb.ft).
3. Install the exhaust heat shield. Install the bolts and tighten to 10 Nm (7 lb.ft).
4. Install the transmission selector cable gaiter. Disconnect the recovery line.
5. Install the floor console. Refer to «Floor Console»(ref-312550-S37039950832009041400000) article.

Scheme 78

Scheme 79

1. Remove the selector lever knob. Carefully loosen the locking collar. Unscrew the knob. Remove the spacer. Remove the locking collar.
2. Remove the selector lever knob.

1. Install the selector lever knob. Clean the components. Apply threadlock if the selector lever knob is to be reused.
2. Install the selector lever knob. Install the locking collar. Install the spacer. Align the knob and tighten the locking collar.

1. Remove the paddle gear selector lever. Remove the Torx bolt. Release the assembly. Disconnect the electrical connector.

1. Install the paddle gear selector lever. Connect and secure the electrical connector. Tighten the Torx bolt to 3 Nm (2 lb.ft).
