Specifications
| Description | Nm |
|---|---|
| Air conditioning (A/C) compressor clutch retaining nut | 19 |
| Air conditioning (A/C) compressor mounting retaining bolts | 25 |
| Air conditioning (A/C) compressor manifold and tube retaining bolt | 20 |
| Air conditioning (A/C) condenser core retaining studs | 7 |
| Air conditioning (A/C) condenser core supply and return lines retaining nuts | 8 |
| Power steering oil cooler retaining nuts | 7 |
| Air conditioning (A/C) pressure cutoff switch | 8 |
Torque Specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Fascia panel with integral ducting |
| 2 | Heater / cooler assembly |
| 3 | A/CCM |
| 4 | Blower LH and RH |
| 5 | Plenum |
| 6 | Control panel |
| 7 | Solar sensor (LHD shown) |
| 8 | Assembly valve - water |
| 9 | Assembly pump - water |
| 10 | Temperature sensor - external |
| 11 | Compressor |
| 12 | Pressure switch - 4 level |
| 13 | Motorized in-car aspirator (LHD shown) |
| 14 | Receiver drier |
| 15 | Condenser |
The climate control system features fully automatic control of temperature, blower speed (airflow) and air distribution to maintain optimum comfort under most driving conditions.
Manual controls are provided to allow the operator to over-ride automatic operation.
