Module Configuration: Overview Jaguar XKR I

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover. (Scheme 23): Disconnecting Battery Ground Cable
3. Remove the trim pad from the door; refer to «DOOR TRIM PANEL»(ref-198049-S08318676492005101500000).
4. Remove the door speaker from the door. Remove the four bolts which secure the speaker. (Scheme 24): Removing Door Speaker
5. Disconnect and remove the speaker. Support the speaker, disconnect the multi-plug and remove the speaker. (Scheme 25): Disconnecting Speaker
6. Disconnect the door module. Remove the three screws which secure the module to the door. Reposition the module outwards through the speaker aperture. (Scheme 26): Removing Screws Which Secure Module To Door
7. Disconnect the harness from the module. Disconnect the two multi-plugs (1). Remove the module (2). (Scheme 27): Removing Module
8. If necessary remove the foam gasket from the module; note that a new gasket must be fitted when installing a new module.
