Module Communications Network: Other Jaguar XKR I

Fuse-boxes

FUSE BOX LOCATIONS Item Part Number Description 1 - Engine Compartment 2 - Engine Management - RHD Only 3 - Engine Management - LHD Only 4 - Fascia End - Right Hand Side 5 - Luggage Compartment 6 - High Power Protection module 7 - Fascia End - Left Hand Side

Scheme 17

There are six fusebox assemblies per vehicle, five of which have conventional, replaceable fuses. The High Power Protection Module does not have conventional fuses.

Two Engine Management fuse-boxes are shown. Only one is fitted (LHD or RHD) to any vehicle, on the opposite side to the pedal box.

The High Power Protection Module comprises three 250amp fusible links to protect the starting circuit (two connected in parallel) and the battery positive supply to the other fuse-boxes.

Driver Information Chart

Note. Use this table to identify DTCs associated with the message center display, then refer to the DIAGNOSTIC TROUBLE CODE (DTC) INDEX for possible sources and actions.

Note. For definitions of Default Modes, see the foot of this table.

DRIVER INFORMATION DTC DEFINITIONS

Default mode Definitions

LIMP-HOME MODE

1. Throttle motor off
2. Throttle motor relay off
3. Throttle motor circuit off
4. Fuel intervention
5. Cruise (speed) control inhibited

LIMP-HOME UNAVAILABLE

1. Power limitation
2. Vehicle speed limited to 74.5 mph (120 kph)
3. Reverse throttle progression enabled NOTE: The throttle operation uses the same map as for reverse gear.
4. Cruise (speed) control inhibited

REVERSE THROTTLE PROGRESSION

1. Throttle opening limited to maximum 30%

ENGINE SPEED LIMITED

1. Engine runs normally, up to 3000 RPM
2. Engine speed restricted to 3000 RPM maximum, by fuel cut-off

HIGH IDLE

1. Throttle valve kept in fixed position by motor
2. Cruise (speed) control inhibited

SAFETY REDUNDANCY

1. Power limitation
2. Vehicle speed limited to 74.5 mph (120 kph)
3. Reverse throttle progression enabled
4. Cruise (speed) control inhibited

G270316t1: CHECK THE PERMANENT SUPPLY (1) TO THE BPM

G270316t2: CHECK THE PERMANENT SUPPLY (2) TO THE BPM

G270316t4: CHECK THE SWITCHED GROUND TO THE BPM

G270316t5: CHECK THE IGNITION SWITCHED GROUND TO THE BPM

G270316t6: CHECK THE ACCESSORY SWITCHED GROUND TO THE BPM

G270316t7: CHECK THE PERMANENT SUPPLY (1) TO THE SLCM

G270316t8: CHECK THE PERMANENT SUPPLY (2) TO THE SLCM

G270316t9: CHECK THE LOGIC GROUND TO THE SLCM

G270316t10: CHECK THE PERMANENT SUPPLY TO THE PDCM

G270316t11: CHECK THE GROUND TO THE PDCM

G270316t12: CHECK THE PERMANENT SUPPLY TO THE DDCM

G270316t13: CHECK THE GROUND TO THE DDCM

G270316t14: CHECK THE PERMANENT SUPPLY TO THE PHRCM

G270316t15: CHECK THE LOGIC GROUND TO THE PHRCM

G270316t3: CHECK THE POWER GROUND TO THE PHRCM

G270316t16: CHECK THE PERMANENT SUPPLY TO THE PSCM

G270316t17: CHECK THE GROUND TO THE PSCM

G270316t18: CHECK THE PERMANENT SUPPLY TO THE DSCM

G270316t19: CHECK THE GROUND TO THE DSCM

G270316t20: CHECK THE PERMANENT SUPPLY TO THE DHRCM

G270316t21: CHECK THE LOGIC GROUND TO THE DHRCM

G270316t134: CHECK THE POWER GROUND TO THE DHRCM

G270316t135: CHECK THE DRIVER SEAT ID

G270316t22: CHECK THE PERMANENT SUPPLY TO THE IC

G270316t23: CHECK THE IGNITION SUPPLY TO THE IC

G270316t24: CHECK THE LOGIC GROUND TO THE IC

G270316t25: CHECK THE POWER GROUND TO THE IC

G270316t26: CHECK THE IGNITION SUPPLY TO THE RCM

G270316t27: CHECK THE GROUND TO THE RCM

G270316t31: CHECK THE PERMANENT SUPPLY TO THE ADCM

G270316t32: CHECK THE IGNITION SUPPLY TO THE ADCM

G270316t33: CHECK THE GROUND TO THE ADCM

G270316t34: CHECK THE PERMANENT SUPPLY TO THE KTM

G270316t35: CHECK THE LOGIC GROUND TO THE KTM

G270316t36: CHECK THE IGNITION SWITCHED GROUND TO THE KTM

G270316t37: CHECK THE ACCESSORY SWITCHED GROUND TO THE KTM

G270316t38: CHECK THE PERMANENT SUPPLY TO THE ASCCM

G270316t39: CHECK THE IGNITION SUPPLY TO THE ASCCM

G270316t40: CHECK THE GROUND TO THE ASCCM

G270316t41: CHECK THE PERMANENT SUPPLY TO THE ASCBCM

G270316t42: CHECK THE IGNITION SUPPLY TO THE ASCBCM

G270316t43: CHECK THE GROUND TO THE ASCBCM

G270316t44: CHECK THE PERMANENT SUPPLY TO THE A/CCM

G270316t45: CHECK THE ISOLATE RELAY SWITCHED SUPPLY TO THE A/CCM

G270316t28: CHECK THE COMPRESSOR CLUTCH RELAY SWITCHED SUPPLY TO THE A/CCM

G270316t46: CHECK THE IGNITION SWITCHED SUPPLY TO THE A/CCM

G270316t47: CHECK THE IGNITION SWITCHED GROUND TO THE A/CCM

G270316t48: CHECK THE GROUND TO THE A/CCM

G270316t53: CHECK THE PERMANENT SUPPLY TO THE ECM

G270316t54: CHECK THE IGNITION SWITCHED SUPPLY TO THE ECM

G270316t56: CHECK THE ENGINE MANAGEMENT SYSTEM (EMS) SWITCHED SUPPLY (1) TO THE ECM

G270316t55: CHECK THE EMS SWITCHED SUPPLY (2) TO THE ECM

G270316t57: CHECK THE GROUND TO THE ECM

G270316t59: CHECK THE IGNITION SUPPLY TO THE TCM

G270316t61: CHECK THE GROUND TO THE TCM

G270316t58: CHECK THE PERMANENT SUPPLY TO THE TCM

G270316t29: CHECK THE IGNITION SUPPLY (1) TO THE TCM

G270316t30: CHECK THE IGNITION SUPPLY (2) TO THE TCM

G270316t49: CHECK THE GROUND TO THE TCM

G270316t62: CHECK THE PERMANENT SUPPLY (1) TO THE ABS/TCCM

G270316t63: CHECK THE PERMANENT SUPPLY (2) TO THE ABS/TCCM

G270316t64: CHECK THE IGNITION SUPPLY TO THE ABS/TCCM

G270316t65: CHECK THE GROUND TO THE ABS/TCCM

G270316t66: CHECK THE IGNITION SUPPLY TO THE GSI MODULE

G270316t67: CHECK THE LOGIC GROUND TO THE GSI MODULE

G270316t69: CHECK THE PERMANENT SUPPLY TO THE DLC

G270316t70: CHECK THE IGNITION SUPPLY TO THE DLC

G270316t71: CHECK THE IGNITION SWITCHED GROUND TO THE DLC

G270316t72: CHECK THE ACCESSORY SWITCHED GROUND TO THE DLC

G270316t73: CHECK THE LOGIC GROUND TO THE DLC

G270316t68: CHECK THE CAN NETWORK FOR CONTINUITY

G270316t74: CHECK THE ASCBCM CAN + CIRCUIT FOR CONTINUITY

G270316t75: CHECK THE ASCBCM CAN - CIRCUIT FOR CONTINUITY

G270316t76: CHECK THE TCM CAN + CIRCUIT FOR CONTINUITY

G270316t77: CHECK THE TCM CAN - CIRCUIT FOR CONTINUITY

G270316t136: CHECK THE CAN NETWORK FOR SHORT CIRCUIT

G270316t137: CHECK THE CAN NETWORK FOR OPEN CIRCUIT

G270316t78: CHECK THE CAN + CIRCUIT BETWEEN THE DLC AND THE INSTRUMENT CLUSTER FOR CONTINUITY

G270316t79: CHECK THE CAN - CIRCUIT BETWEEN THE DLC AND THE INSTRUMENT CLUSTER FOR CONTINUITY

G270316t80: CHECK THE CAN + CIRCUIT BETWEEN THE INSTRUMENT CLUSTER AND THE GSI MODULE FOR CONTINUITY

G270316t81: CHECK THE CAN - CIRCUIT BETWEEN THE INSTRUMENT CLUSTER AND THE GSI MODULE FOR CONTINUITY

G270316t82: CHECK THE CAN + CIRCUIT BETWEEN THE GSI MODULE AND THE ECM FOR CONTINUITY

G270316t83: CHECK THE CAN - CIRCUIT BETWEEN THE GSI MODULE AND THE ECM FOR CONTINUITY

G270316t84: CHECK THE CAN + CIRCUIT BETWEEN THE ECM AND THE ASCCM FOR CONTINUITY

G270316t85: CHECK THE CAN - CIRCUIT BETWEEN THE ECM AND THE ASCCM FOR CONTINUITY

G270316t86: CHECK THE CAN + CIRCUIT BETWEEN THE ASCCM AND THE ABS/TCCM FOR CONTINUITY

G270316t87: CHECK THE CAN - CIRCUIT BETWEEN THE ASCCM AND THE ABS/TCCM FOR CONTINUITY

G270316t138: CHECK THE CAN + AND - CIRCUITS BETWEEN THE DLC AND THE INSTRUMENT CLUSTER FOR SHORT CIRCUIT TO EACH OTHER

G270316t139: CHECK THE CAN + AND - CIRCUITS BETWEEN THE INSTRUMENT CLUSTER AND THE GSI MODULE FOR SHORT CIRCUIT TO EACH OTHER

G270316t140: CHECK THE CAN + AND - CIRCUITS BETWEEN THE GSI MODULE AND THE ECM FOR SHORT CIRCUIT TO EACH OTHER

G270316t141: CHECK THE CAN + AND - CIRCUITS BETWEEN THE ECM AND THE ASCCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t143: CHECK THE CAN + AND - CIRCUITS BETWEEN THE ASCCM AND THE ABS/TCCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t142: CHECK THE CAN + AND - CIRCUITS BETWEEN THE ECM AND THE TCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t144: CHECK THE CAN + AND - CIRCUITS BETWEEN THE GSI MODULE AND THE ASCBCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t98: CHECK THE CAN NETWORK FOR CONTINUITY

G270316t99: CHECK THE ASCBCM CAN + CIRCUIT FOR CONTINUITY

G270316t100: CHECK THE ASCBCM CAN - CIRCUIT FOR CONTINUITY

G270316t145: CHECK THE CAN NETWORK FOR SHORT CIRCUIT

G270316t146: CHECK THE CAN NETWORK FOR OPEN CIRCUIT

G270316t103: CHECK THE CAN + CIRCUIT BETWEEN THE DLC AND THE INSTRUMENT CLUSTER FOR CONTINUITY

G270316t104: CHECK THE CAN - CIRCUIT BETWEEN THE DLC AND THE INSTRUMENT CLUSTER FOR CONTINUITY

G270316t105: CHECK THE CAN + CIRCUIT BETWEEN THE INSTRUMENT CLUSTER AND THE GSI MODULE FOR CONTINUITY

G270316t106: CHECK THE CAN - CIRCUIT BETWEEN THE INSTRUMENT CLUSTER AND THE GSI MODULE FOR CONTINUITY

G270316t107: CHECK THE CAN + CIRCUIT BETWEEN THE GSI MODULE AND THE ECM FOR CONTINUITY

G270316t108: CHECK THE CAN - CIRCUIT BETWEEN THE GSI MODULE AND THE ECM FOR CONTINUITY

G270316t109: CHECK THE CAN + CIRCUIT BETWEEN THE ECM AND THE TCM FOR CONTINUITY

G270316t110: CHECK THE CAN - CIRCUIT BETWEEN THE ECM AND THE TCM FOR CONTINUITY

G270316t111: CHECK THE CAN + CIRCUIT BETWEEN THE TCM AND THE ASCCM FOR CONTINUITY

G270316t112: CHECK THE CAN - CIRCUIT BETWEEN THE TCM AND THE ASCCM FOR CONTINUITY

G270316t101: CHECK THE CAN + CIRCUIT BETWEEN THE ASCCM AND THE ABS/TCCM FOR CONTINUITY

G270316t102: CHECK THE CAN - CIRCUIT BETWEEN THE ASCCM AND THE ABS/TCCM FOR CONTINUITY

G270316t147: CHECK THE CAN + AND - CIRCUITS BETWEEN THE DLC AND THE INSTRUMENT CLUSTER FOR SHORT CIRCUIT TO EACH OTHER

G270316t148: CHECK THE CAN + AND - CIRCUITS BETWEEN THE INSTRUMENT CLUSTER AND THE GSI MODULE FOR SHORT CIRCUIT TO EACH OTHER

G270316t150: CHECK THE CAN + AND - CIRCUITS BETWEEN THE GSI MODULE AND THE ASCBCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t149: CHECK THE CAN + AND - CIRCUITS BETWEEN THE GSI MODULE AND THE ECM FOR SHORT CIRCUIT TO EACH OTHER

G270316t151: CHECK THE CAN + AND - CIRCUITS BETWEEN THE ECM AND THE TCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t152: CHECK THE CAN + AND - CIRCUITS BETWEEN THE TCM AND THE ASCCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t153: CHECK THE CAN + AND - CIRCUITS BETWEEN THE ASCCM AND THE ABS/TCM FOR SHORT CIRCUIT TO EACH OTHER

G270316t88: CHECK THE CAN + FOR SHORT CIRCUIT TO BATTERY

G270316t89: CHECK THE CAN + FOR SHORT CIRCUIT TO IGNITION POSITIVE

G270316t90: CHECK THE CAN + FOR SHORT CIRCUIT TO GROUND

G270316t91: CHECK THE CAN + FOR SHORT CIRCUIT TO ACCESSORY SWITCHED GROUND

G270316t92: CHECK THE CAN + FOR SHORT CIRCUIT TO IGNITION SWITCHED GROUND

G270316t93: CHECK THE CAN - FOR SHORT CIRCUIT TO BATTERY

G270316t94: CHECK THE CAN - FOR SHORT CIRCUIT TO IGNITION POSITIVE

G270316t95: CHECK THE CAN - FOR SHORT CIRCUIT TO GROUND

G270316t96: CHECK THE CAN - FOR SHORT CIRCUIT TO ACCESSORY SWITCHED GROUND

G270316t97: CHECK THE CAN - FOR SHORT CIRCUIT TO IGNITION SWITCHED GROUND

G270316t113: CHECK FOR CORRECT BUS TERMINATION IN THE SCP + NETWORK

G270316t50: CHECK THE SCP NETWORK + AND - FOR SHORT CIRCUIT TO EACH OTHER

G270316t114: CHECK THE SCP + FOR SHORT CIRCUIT TO BATTERY

G270316t115: CHECK THE SCP + FOR SHORT CIRCUIT TO IGNITION POSITIVE

G270316t116: CHECK THE SCP + FOR SHORT CIRCUIT TO GROUND

G270316t117: CHECK THE SCP + FOR SHORT CIRCUIT TO ACCESSORY SWITCHED GROUND

G270316t118: CHECK THE SCP + FOR SHORT CIRCUIT TO IGNITION SWITCHED GROUND

G270316t119: CHECK THE SCP - FOR SHORT CIRCUIT TO BATTERY

G270316t120: CHECK THE SCP - FOR SHORT CIRCUIT TO IGNITION POSITIVE

G270316t121: CHECK THE SCP - FOR SHORT CIRCUIT TO GROUND

G270316t122: CHECK THE SCP - FOR SHORT CIRCUIT TO ACCESSORY SWITCHED GROUND

G270316t123: CHECK THE SCP - FOR SHORT CIRCUIT TO IGNITION SWITCHED GROUND

G270316t124: CHECK THE BIDIRECTIONAL CIRCUIT FOR SHORT CIRCUIT TO BATTERY

G270316t125: CHECK THE BIDIRECTIONAL CIRCUIT FOR SHORT CIRCUIT TO IGNITION POSITIVE

G270316t126: CHECK THE BIDIRECTIONAL CIRCUIT FOR SHORT CIRCUIT TO GROUND

G270316t127: CHECK THE BIDIRECTIONAL CIRCUIT FOR SHORT CIRCUIT TO ACCESSORY SWITCHED GROUND

G270316t128: CHECK THE BIDIRECTIONAL CIRCUIT FOR SHORT CIRCUIT TO IGNITION SWITCHED GROUND

G270316t129: CHECK THE SERIAL INPUT CIRCUIT FOR SHORT CIRCUIT TO BATTERY

G270316t130: CHECK THE SERIAL INPUT CIRCUIT FOR SHORT CIRCUIT TO IGNITION POSITIVE

G270316t131: CHECK THE SERIAL INPUT CIRCUIT FOR SHORT CIRCUIT TO GROUND

G270316t132: CHECK THE SERIAL INPUT CIRCUIT FOR SHORT CIRCUIT TO ACCESSORY SWITCHED GROUND

G270316t133: CHECK THE BIDIRECTIONAL CIRCUIT FOR SHORT CIRCUIT TO IGNITION SWITCHED GROUND

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover. (Scheme 17): Disconnecting Battery Ground Cable
3. Open the bonnet and fit body paintwork protection sheets.
4. Remove the positive supply power cable. Remove the fuse-box from the mounting panel. Reposition the cover from the positive cable (1). Remove the nut which secures the positive cable to the fuse-box (2). Disconnect the positive power cable (3). (Scheme 18): Disconnecting Positive Power Cable
5. Remove the fuse-box from the mounting panel. Release the securing latch, upwards (1). Reposition the fuse-box, inwards (2). Remove the fuse-box from the mounting panel. Releases the securing tangs and remove the cover from the fuse-box. (Scheme 19): Removing Fuse-Box From Mounting Panel
6. Remove the fuse-box. Identify and disconnect the harness multi-plugs from the fuse-box. Remove the fuse-box from the vehicle. (Scheme 20): Removing Fuse-Box
7. Remove the fuses and relays. Note the position of each relay and remove them. Identify each fuse and remove them. The value and position of each fuse is illustrated on the lid of the luggage compartment fuse-box - for all fuse-boxes on the vehicle. (Scheme 21): Removing Fuses And Relays
