Bluetooth

2006 model year (MY) sees the introduction of a Bluetooth® communications network system.

Note: In common with previous cellular phones it is the drivers responsibility to comply with local legislation regarding cellular phone use.

Bluetooth is a way of communicating with various electronic devices that are equipped with specialized chips using a short-range radio link. It allows most devices to communicate with one another by creating a universal language. The devices then form a private network known as a 'personal area network'.

Interaction between Bluetooth devices can take place without direct human intervention whenever two or more Bluetooth devices are within each other's range. This enables the Bluetooth transceiver chip to trigger an automatic connection to deliver and accept a flow of data.

Bluetooth devices operate on a radio frequency band knows as the Industrial, Scientific, and Medical frequency. The Industrial, Scientific, and Medical radio frequency band is 2.40 GigaHertz (GHz) to 2.48 GHz which is divided into 79 channels, each carrying a bandwidth of 1 MegaHertz (MHz).

The devices use the 79 individual randomly chosen channels within the frequency band, changing from one to another on a regular basis. The Bluetooth transmitters change frequencies approximately 1,600 times every second, meaning that more devices can utilize the limited slice of the radio frequency.

Since every Bluetooth transmitter uses this technique automatically, it's most unlikely that two transmitters will be on the same frequency at the same time. This technique minimizes the risk of disruption to Bluetooth devices, as any interference on a particular frequency will last only a fraction of a second.

The Bluetooth system consists of

1. A Bluetooth upgrade module
2. A Portable Support Electronics (PSE) module
3. A voice activated control module
4. A microphone
5. Steering wheel telematics control switches
6. An audio unit

The Bluetooth upgrade module allows the driver to integrate their personal cellular phone to the vehicle. When a cellular phone is paired to the vehicle, it allows the storage of up to 500 individual phone numbers and 40 related voice tags to the voice activated control module. These stored phone numbers can then be accessed using the audio unit control buttons, the audio unit touch screen (if equipped) or steering wheel telematics control switches. The voice tags can be accessed by using the steering wheel telematics control switches when utilizing the voice activation facility.

If a cellular phone has been matched/programmed to the vehicle and a second cellular phone is added, the stored phone numbers and voice tags from the second cellular phone will overwrite the original phones' stored data.

Phone numbers stored to the PSE and voice tags stored to the voice activated control module need to be manually updated should alterations be required. If a new phone number has been added to the cellular phone memory, it will need to be added manually to the vehicle memory.

Once stored to the vehicle, the phone numbers can be viewed on the audio unit screen. The audio unit and touch-screen operate as previous models.

For vehicles fitted with a touch-screen controlled audio unit it is possible to redial the last 10 dialed phone numbers from the vehicle. For vehicles without a touch-screen controlled audio unit it is only possible to redial the last dialed phone number from the vehicle. These dialed phone numbers are stored in the PSE module memory and not from the cellular phone's memory.

The Bluetooth system does not include a phone cradle or it's own individual vehicle antenna. As a consequence of this, there is no cellular phone signal amplification and no in-car charging facilities.

In-car charging can be achieved using a suitable lead to the cigar lighter or auxiliary power socket.

Portable Support Electronics (PSE) Module

The Portable Support Electronics (PSE) module is located in the left-hand side of the luggage compartment.

Scheme 33

The PSE module is fixed to a bracket which also supports the Voice Activation Control Module (VACM) and the navigation control module.

The PSE module has one electrical connector and one optical connector. The module is unique to Jaguar, but utilizes carry over hardware.

The PSE module stores up to 500 phone numbers and the last 10 dialed phone numbers from the vehicle.

Bluetooth Upgrade Module

The Bluetooth upgrade module is located under the center console and is attached to the center console using velcro.

Scheme 34

The Bluetooth upgrade module communicates with the drivers cellular phone and integrates it into the vehicle system transferring information such as call status and phonebook information to the PSE.

Voice Activated Control Module

The voice activated control module is located in the left-hand side of the luggage compartment.

Scheme 35

The voice activated control module is fixed to a bracket which also supports the PSE and the navigation control module.

The voice activated control module stores up to 40 voice tags.

Scheme 36

The microphone is located above the driver and is attached to the headliner.

Steering Wheel Telematics Control Switches

To ensure minimum disruption to concentration when driving, limited control of audio, telephone and voice activation systems is possible using the steering wheel telematics control switches.

The control switches provide the following phone functionality

1. Answer phone call/end handsfree calls.
2. Increase or decrease volume.
3. Cycle through phone memory.

Scheme 37

Refer to the Cellular Phone user guide for complete operating instructions.

System/Carrier Concerns - All Systems

Dropped calls, bad connections, noisy audio and other intermittent symptoms usually indicate a system or cellular carrier concern, and are not the fault of the phone itself. Such symptoms may occur in situations such as the following

1. In certain geographic areas (for example: areas of excessive foliage or hills) or at the edge of coverage areas.
2. At the same place each day.
3. At the same time each day.
4. Under bridges, tunnels, in lower freeways, or in congested downtown areas.

If the customer phone exhibits any of the above symptoms or symptoms occur under the above conditions, the customer or the dealer should contact customer assistance at their particular cellular provider/carrier or call the assistance number provided in the Jaguar Cellular System Dealer kit.

Other Possible Concerns - All Systems

1. If, for some reason, the customer's electronic serial number was incorrectly recorded in the carrier switch, the phone will not work. Call the assistance number provided in the Jaguar Cellular System Dealer kit to check the electronic serial number CDMA/TDMA only.
2. A customer initial call must be made in his/her home coverage area for correct activation of the Jaguar Cellular System.
3. A customer may have to wait until after 24 hours of the coverage activation before making a call from outside of his/her home coverage area or the phone might be reported stolen and coverage stopped.
4. There may be a slight delay in activation after leaving the dealership from initial delivery.

If, after checking these possibilities, the phone still does not function, do not attempt to repair the phone. Call the cellular phone distributor.

Pinpoint Tests

Note. When performing voltage or resistance tests, always use a digital multimeter (DMM) accurate to three decimal places, and with an up-to-date calibration certificate. When testing resistance always take the resistance of the DMM leads into account.

Note. Inspect connectors for signs of water ingress, and pins for damage and/or corrosion.

Note. If a control module or component is suspect and the vehicle remains under manufacturer warranty, refer to the Warranty Policy and Procedures manual (section B1.2), or determine if any prior approval program is in operation, before the replacement of a component.
