Transmission Link Harness Electrical Connector Layout
| CAUTION | When working with the transmission control module (TCM) and main control valve body, all suitable safety precautions must be taken to protect the component against electrostatic discharge. |
| CAUTION | Do not carry out any electrical tests on the TCM and main control valve body. Failure to follow these instructions may result in component damage. |
| CAUTION | Make sure all suitable safety precautions are taken to protect the transmission control module (TCM) and main control valve body electrical connector pins against electrostatic discharge. |
Scheme 46
| Pin No | Description |
|---|
| 1 | Not used |
| 2 | CAN Low |
| 3 | Not used |
| 4 | Not used |
| 5 | Not used |
| 6 | CAN High |
| 7 | Not used |
| 8 | Not used |
| 9 | Ignition supply |
| 10 | Park/Neutral Signal |
| 11 | Not used |
| 12 | Not used |
| 13 | Ground |
| 14 | Power supply +v |
| 15 | Not used |
| 16 | Ground |
Transmission Link Harness Electrical Connector
