Automatic Drive Positioner System: Other Infiniti Q45 II

Memory Modules 23 illustrations ~1546 words

FAIL-SAFE SYSTEM

Note. Driver's seat control unit may also be known as Local Control Unit 05 (LCU 05).

The driver's seat control unit (LCU 05) and Body Control Module (BCM) control and monitor ADP system functions. After ADP system has been operated, the appropriate control module monitors position of seat and steering column using input from seat and steering column sensors. If control module detects that seat movement has occurred forward or backward greater than .240" (6 mm) within 2.5 seconds when ignition switch is in RUN position, ADP system will be set in fail-safe mode. Fail-safe mode is also set when seat reclines or steering column tilts greater than one degree within 2.5 seconds when ignition switch is in RUN position. Fail-safe mode is canceled when gear selector lever is moved back to "P" position, or when ADP system is diagnosed using Nissan CONSULT scan tool.

MEMORY BUTTONS

Note. If battery or driver's seat control unit (LCU 05) are disconnected, initialization procedure MUST be performed before memory button can be programmed. See INITIALIZATION.

Ensure gear selector lever is in "P" position. Turn ignition switch to RUN position. Manually adjust driver's seat and steering column to the desired position. Push SET button on driver's door, and within 5 seconds, press button "1" or "2". Indicator light on pressed switch will illuminate for about 5 seconds, indicating successful memory storage.

INITIALIZATION

The ADP system must be initialized and programmed any time a battery cable has been disconnected or when ADP system fuse has blown. Without initialization, the ADP system will not function. To initialize, perform procedure "A" or "B".

Procedure "A"

Insert key into ignition switch. Leave ignition switch in LOCK position. Open, close, then open driver's door. After initialization, reprogram ADP memory. See MEMORY BUTTONS .

Procedure "B"

Drive vehicle at greater than 19 MPH. After initialization, reprogram ADP memory. See MEMORY BUTTONS .

All Seat System Functions Are Inoperative

If all seat functions are inoperative during both manual and automatic operations, perform DIAGNOSTIC PROCEDURE NO. 1: POWER SUPPLY & GROUND CIRCUIT CHECK FOR DRIVER'S SEAT CONTROL UNIT (LCU 05) under SYSTEM TESTS. (Scheme 2)

Seat Sliding Function Is Inoperative

If sliding function is inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See SELF-DIAGNOSTIC SYSTEM.
  2. Test sliding motor. Perform DIAGNOSTIC PROCEDURE NO. 11: SLIDING MOTOR CHECK under SYSTEM TESTS. (Scheme 12)

Seat Reclining Function Is Inoperative

If reclining function is inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test reclining motor. Perform DIAGNOSTIC PROCEDURE NO. 12: RECLINING MOTOR CHECK under SYSTEM TESTS. (Scheme 13)

Seat Lifting (Front) Function Is Inoperative

If front lifting function is inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test front lifting motor. Perform DIAGNOSTIC PROCEDURE NO. 13: LIFTING MOTOR CHECK (FRONT) under SYSTEM TESTS. (Scheme 14)
  3. Test limit switch. Perform DIAGNOSTIC PROCEDURE NO. 15: LIFTING LIMIT SWITCH CHECK under SYSTEM TESTS. (Scheme 16)

Seat Lifting (Rear) Function Is Inoperative

If rear lifting function is inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test rear lifting motor. Perform DIAGNOSTIC PROCEDURE NO. 14: LIFTING MOTOR CHECK (REAR) under SYSTEM TESTS. (Scheme 15)
  3. Test limit switch. Perform DIAGNOSTIC PROCEDURE NO. 15: LIFTING LIMIT SWITCH CHECK under SYSTEM TESTS. (Scheme 16)

All Steering Column Functions Are Inoperative

If all steering system functions are inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test tilt/telescopic motor power supply and ground circuits. Perform DIAGNOSTIC PROCEDURE NO. 2: POWER SUPPLY & GROUND CIRCUIT CHECK FOR TILT/TELESCOPIC MOTOR under SYSTEM TESTS. (Scheme 3)
  3. Test tilt sensor. Perform DIAGNOSTIC PROCEDURE NO. 3: TILT SENSOR CHECK under SYSTEM TESTS. (Scheme 4)
  4. Test telescopic sensor. Perform DIAGNOSTIC PROCEDURE NO. 4: TELESCOPIC SENSOR CHECK under SYSTEM TESTS. (Scheme 5)

Steering Column Tilt Function is Inoperative

If steering column tilt function is inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test tilt motor. Perform DIAGNOSTIC PROCEDURE NO. 9: TILT MOTOR CHECK under SYSTEM TESTS. (Scheme 10)

Steering Column Telescopic Function is Inoperative

If steering column telescopic function is inoperative during both manual and automatic operations, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test telescopic motor. Perform DIAGNOSTIC PROCEDURE NO. 10: TELESCOPIC MOTOR CHECK under SYSTEM TESTS. (Scheme 11)

All Automatic Functions & All Or Some Manual Functions Inoperative

If all functions are inoperative during automatic operation and some or all functions are inoperative during manual operation during both manual and automatic operations, perform the following procedures in order listed.

  1. Test power seat switch. Perform DIAGNOSTIC PROCEDURE NO. 17: POWER SEAT SWITCH CHECK under SYSTEM TESTS.
  2. Test key, detention, door switch and vehicle speed sensor. Perform DIAGNOSTIC PROCEDURE NO. 19: KEY, DETENTION, DOOR SWITCH & VEHICLE SPEED SENSOR (VSS) CHECK under SYSTEM TESTS. (Scheme 20)and (Scheme 21).

Seat Sliding Function Inoperative

If sliding seat function is inoperative during automatic operation only, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test sliding sensor. Perform DIAGNOSTIC PROCEDURE NO. 5: SLIDING SENSOR CHECK under SYSTEM TESTS. (Scheme 6)

Seat Reclining Function Inoperative

If reclining seat function is inoperative during automatic operation only, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test reclining sensor. Perform DIAGNOSTIC PROCEDURE NO. 6: RECLINING SENSOR CHECK under SYSTEM TESTS. (Scheme 7)

Seat Lifting (Front) Function Inoperative

If front lifting function is inoperative during automatic operation only, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test front lifting sensor. Perform DIAGNOSTIC PROCEDURE NO. 7: LIFTING SENSOR CHECK (FRONT) under SYSTEM TESTS. (Scheme 8)

Seat Lifting (Rear) Function Inoperative

If rear lifting function is inoperative during automatic operation only, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test front lifting sensor. Perform DIAGNOSTIC PROCEDURE NO. 8: LIFTING SENSOR CHECK (REAR) under SYSTEM TESTS. (Scheme 9)

Some Steering Column Functions Are Inoperative

If some steering system functions are inoperative during automatic operation only, fault may be caused by tilt/telescopic mechanical failure. Repair as necessary.

All Automatic Functions Inoperative

If all automatic system functions are inoperative, perform the following procedures in order listed.

  1. Perform self-diagnostics. See «SELF-DIAGNOSTIC SYSTEM»(ref-96726-S27025746752001092800000).
  2. Test steering column tilt sensor. Perform DIAGNOSTIC PROCEDURE NO. 3: TILT SENSOR CHECK under SYSTEM TESTS. (Scheme 4)
  3. Test steering column telescopic sensor. Perform DIAGNOSTIC PROCEDURE NO. 4: TELESCOPIC SENSOR CHECK under SYSTEM TESTS. (Scheme 5)
  4. Test cancel switch. Perform DIAGNOSTIC PROCEDURE NO. 18: CANCEL SWITCH CHECK under SYSTEM TESTS. (Scheme 19)
  5. Test key, detention, door switch and vehicle speed sensor. Perform DIAGNOSTIC PROCEDURE NO. 19: KEY, DETENTION, DOOR SWITCH & VEHICLE SPEED SENSOR (VSS) CHECK under SYSTEM TESTS. (Scheme 20)and (Scheme 21).

If Only Memory Storage Function Is Inoperative

If only memory storage function is inoperative, perform the following procedures in order listed.

  1. Test key, detention, door switch and vehicle speed sensor. Perform DIAGNOSTIC PROCEDURE NO. 19: KEY, DETENTION, DOOR SWITCH & VEHICLE SPEED SENSOR (VSS) CHECK under SYSTEM TESTS. (Scheme 20)and (Scheme 21).
  2. Test memory switch. Perform DIAGNOSTIC PROCEDURE NO. 20: SEAT MEMORY SWITCH CHECK under SYSTEM TESTS. (Scheme 22)

Memorized Position Set (Procedure "B"), Automatic Exiting & Automatic Set Return Are Inoperative

If memorized position set (procedure "B"), automatic exiting and automatic set return are inoperative, perform initialization. See INITIALIZATION under PROGRAMMING.

Seat Sliding, Reclining And/Or Lifting Functions Inoperative

If sliding, reclining and/or lifting functions are inoperative during manual operation only, perform the following procedures in order listed.

  1. Perform DIAGNOSTIC PROCEDURE NO. 17: POWER SEAT SWITCH CHECK under SYSTEM TESTS. (Scheme 18)
  2. Perform WAKE-UP DIAGNOSIS under SELF-DIAGNOSTIC SYSTEM in appropriate MULTIPLEX CONTROL SYSTEMS article.

Lumbar Support Function Inoperative

If lumbar support function is inoperative during manual operation only, perform DIAGNOSTIC PROCEDURE NO. 22: LUMBAR SUPPORT CHECK under SYSTEM TESTS. (Scheme 24)

Steering Column Tilt And/Or Telescopic Functions Inoperative

If steering column tilt and/or telescopic functions are inoperative during manual operation only, perform DIAGNOSTIC PROCEDURE NO. 16: TILT/TELESCOPIC SWITCH CHECK under SYSTEM TESTS. (Scheme 17)

AUTOMATIC DRIVE POSITION CANCEL SWITCH INOPERATIVE

If automatic operation cannot be canceled, perform DIAGNOSTIC PROCEDURE NO. 18: CANCEL SWITCH TEST under SYSTEM TESTS. (Scheme 19)

MEMORY LIGHTS INOPERATIVE

Note. Ensure automatic drive position cancel switch is operational before trouble shooting memory lights.

If memory lights are inoperative, perform DIAGNOSTIC PROCEDURE NO. 21: MEMORY INDICATOR CHECK under SYSTEM TESTS. (Scheme 23)

Without Nissan CONSULT San Tool

To clear codes, turn ignition switch to LOCK position. Remove fuse No. 14 (7.5-amp) located instrument panel fuse box. Install fuse and retrieved all codes to ensure procedure was successful.

SYSTEM TESTS

Note. If battery or driver's seat control unit (LCU 05) are disconnected, initialization procedure MUST be performed before memory button can be programmed. See INITIALIZATION under PROGRAMMING.

AbbreviationColor
BBlack
GGreen
LBlue
PPink
RRed
WWhite
YYellow
BRBrown
GYGray
LGLight Green
OROrange
SBSky Blue
(1) Listed wire color abbreviations are used in the following diagnostic procedures.
(1)Listed wire color abbreviations are used in the following diagnostic procedures.

WIRE COLOR ABBREVIATIONS (1)

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24
