Engine Controls - System & Component Testing: Overview Infiniti M45 II

Testing & Diagnostics 1 illustration ~476 words

Description

When the engine is running at low or medium speed, the power valve is fully closed. Under this condition, the effective suction port length is equivalent to the total length of the intake manifold collector's suction port including the intake valve. This long suction port provides increased air intake which results in improved suction efficiency and higher torque generation. The system includes a surge tank and one-way valve.

When engine is running at high speed, the Engine Control Module (ECM) sends the signal to the Variable Induction Air Control System (VIAS) control solenoid valve. This signal introduces the intake manifold vacuum into the power valve actuator and therefore opens the power valve to 2 suction passages together in the collector. Under this condition, the effective port length is equivalent to the length of the suction port provided independently for each cylinder. This shortened port length results in enhanced engine output with reduced suction resistance under high speeds.

The power valve is installed in intake manifold collector and is used to control the suction passage of the variable induction air control system. It is set in the fully closed or fully opened position by the power valve actuator operated by the vacuum stored in the surge tank. The vacuum in the surge tank is controlled by the VIAS control solenoid valve.

The VIAS control solenoid valve cuts the intake manifold vacuum signal for power valve control. It responds to ON/OFF signals from the ECM. When the solenoid is off, the vacuum signal from the intake manifold is cut. When the ECM sends an ON signal, the coil pulls the plunger downward and feeds the vacuum signal to the power valve actuator.

From the beginning of refueling, the fuel tank pressure goes up. When the pressure reaches the setting value of the Refueling Control Valve (RCV) opening pressure, the RCV is opened. After RCV opens, the air and vapor inside the fuel tank go through refueling EVAP vapor cut valve, RCV and refueling vapor line to the EVAP canister. The vapor is absorbed by the EVAP canister and the air is released to the atmosphere. When the refueling has reached the full level of the fuel tank, the refueling EVAP vapor cut valve is closed and refueling is stopped because of auto shut-off. The vapor which was absorbed by the EVAP canister is purged during driving. The RCV is always closed during driving and the evaporative emission control system is operated the same as a conventional system. (Scheme 17)

Scheme 17

Scheme 17: Description

The refrigerant pressure sensor is installed at the receiver drier of the A/C system. The sensor uses an electrostatic volume pressure transducer to convert refrigerant pressure to voltage. The voltage signal is sent to ECM, and ECM controls cooling fan system.
