Maintenance: Removal & Installation Infiniti FX50 II рестайлинг

Procedures 7 illustrations ~312 words

INSTALLATION

Note the following item, and install in the reverse order of removal

  1. Install the air cleaner filter by aligning the seal with the notch of air cleaner case.

REMOVAL

CAUTIONOil filter is provided with relief valve. Use genuine NISSAN oil filter or an equivalent. Be careful not to get burned when engine and engine oil may be hot. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Never allow engine oil to adhere to drive belt. Completely wipe off any engine oil that adheres to engine and vehicle.
  1. Remove engine undercover with power tool.
  2. Using oil filter wrench [SST: KV10115801 (J38956)] (B), remove oil filter.

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14: INSTALLATION
Scheme 14: INSTALLATION
  1. Remove foreign matter adhering to oil filter installation surface.
  2. Apply engine oil to the oil seal contact surface of new oil filter.
  3. Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn (A). Or tighten to the specification. Oil filter: Torque: 17.7 N.m (1.8 kg-m, 13 ft-lb)

Scheme 15

Scheme 15
Scheme 15
  1. Remove engine cover with power tool. Refer to " «EXPLODED VIEW»(ref-523999-S31632000922013012500000) ".
  2. Remove air duct. Refer to " «EXPLODED VIEW»(ref-523999-S24906424812013012500000) ".
  3. Remove electric throttle control actuator. Refer to " «EXPLODED VIEW»(ref-523999-S16714123482013012500000) ".
  4. Remove ignition coil. Refer to " «REMOVAL AND INSTALLATION»(ref-523999-S12355688662013012500000) ".
  5. Remove spark plug with a spark plug wrench (commercial service tool).

Scheme 16

Scheme 16
Scheme 16

Installation is the reverse order of removal.

Note the following item, and install in the reverse order of removal

  1. Install the air cleaner filter by aligning the seal with the notch of air cleaner case.
CAUTIONOil filter is provided with relief valve. Use genuine NISSAN oil filter or an equivalent. Be careful not to get burned when engine and engine oil may be hot. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Never allow engine oil to adhere to drive belts. Completely wipe off any engine oil that adheres to engine and vehicle.
  1. Remove engine undercover with power tool.
  2. Using oil filter wrench [SST: KV10115801 (J38956)] (A), remove oil filter.

Scheme 17

Scheme 17
Scheme 17
  1. Remove foreign matter adhering to oil filter installation surface.
  2. Apply engine oil to the oil seal contact surface of new oil filter.
  3. Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn (A). Or tighten to the specification. Oil filter: Torque: 17.7 N.m (1.8 kg-m, 13 ft-lb)
  1. Remove engine cover. Refer to " «EXPLODED VIEW»(ref-524013-S33137113562013012500000) ".
  2. Remove ignition coil. Refer to " «EXPLODED VIEW»(ref-524013-S21667729372013012500000) ".
  3. Remove spark plug with a spark plug wrench (commercial service tool).

Scheme 18

Scheme 18
Scheme 18

Installation is the reverse order of removal.
