INSPECTION AFTER INSTALLATION

1. Check the engine oil level. Refer to " «INSPECTION»(ref-524020-S41656108772013012500000) ".
2. Start the engine, and check there is no leakage of engine oil.
3. Stop the engine and wait for 10 minutes.
4. Check the engine oil level, and adjust the level. Refer to " «INSPECTION»(ref-524020-S41656108772013012500000) ".

INSPECTION AFTER REMOVAL

Use the standard type spark plug for normal condition.

Spark plug (Standard type): Refer to " SPARK PLUG ".

Scheme 1

Scheme 2

EVAP VAPOR LINES: Inspection

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration. Refer to " «INSPECTION»(ref-524001-S39136629942013012500000) ".
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to " «COMPONENT INSPECTION»(ref-524001-S39402289352013012500000) ".

Scheme 3

1. Check the engine oil level. Refer to " «INSPECTION»(ref-524020-S41656108772013012500000) ".
2. Start the engine, and check there is no leakage of engine oil.
3. Stop the engine and wait for 15 minutes.
4. Check the engine oil level, and adjust the level. Refer to " «INSPECTION»(ref-524020-S41656108772013012500000) ".

Use the standard type spark plug for normal condition.

Spark plug (Standard type): Refer to " SPARK PLUG ".

1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections, chafing and deterioration. Refer to " «INSPECTION»(ref-524019-S38665631462013012500000) ".
2. Inspect fuel tank filler cap vacuum relief valve for clogging, sticking, etc. Refer to " «COMPONENT INSPECTION»(ref-524019-S09858530902013012500000) ".

EXHAUST SYSTEM: Inspection

Check exhaust pipes, muffler and mounting for improper attachment, leakage, cracks, damage or deterioration.

1. If damage is found, repair or replace damaged parts.

Scheme 4

BRAKE FLUID LEVEL AND LEAKS: Inspection

1. If fluid level is extremely low, check brake system for leaks.

Scheme 5

BRAKE LINES AND CABLES: Inspection

1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.

Scheme 6

POWER STEERING FLUID AND LINES: Inspection

Check fluid level in reservoir tank with engine off.

Use "HOT" range at fluid temperatures of 50 to 80°C (122 to 176°F) or "COLD" range at fluid temperatures of 0 to 30°C (32 to 86°F).

Scheme 7

Scheme 8

AXLE AND SUSPENSION PARTS: Inspection

Check front and rear axle and suspension parts for excessive play, cracks, wear or other damage.

1. Shake each wheel to check for excessive play.
2. Check wheel bearings for smooth operation.
3. Check axle and suspension nuts and bolts for looseness.
4. Check strut (shock absorber) for oil leakage or other damage.
5. Check suspension ball joint for grease leakage and ball joint dust cover for cracks or other damage.

Scheme 9

Scheme 10

DRIVE SHAFT: Inspection

Check boot and drive shaft for cracks, wear, damage and grease leakage.

Scheme 11

SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS: Inspection

For front seat belt illustration. Refer to " SEAT BELT RETRACTOR: EXPLODED VIEW ".

For rear seat belt illustration. Refer to " SEAT BELT RETRACTOR: EXPLODED VIEW ".

For details, refer to " SEAT BELT RETRACTOR: INSPECTION " .

1. Check anchors for loose mounting
2. Check belts for damage
3. Check retractor for smooth operation
4. Check function of buckles and tongues when buckled and released
