REMOVAL
| CAUTION | When removing and installing, use shop cloths to protect parts from damage. |
Scheme 4
- Remove the driver seat (1). Refer to " «REMOVAL AND INSTALLATION»(ref-524039-S09461333042013012500000) ".
- Remove the mounting bolts (A).
- Remove driver seat control unit (2).
INSTALLATION
Install in the reverse order of removal.
| CAUTION | Be sure to clump the harness to the right place. |
Note. After installing the driver seat, perform additional service when replacing control unit. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: DESCRIPTION ".
| CAUTION | When removing and installing, use shop cloths to protect parts from damage. |
Scheme 5
- Remove the instrument driver lower panel. Refer to " «REMOVAL AND INSTALLATION»(ref-524023-S04361443702013012500000) ".
- Remove the screws (A).
- Remove automatic drive positioner control unit (1).
Install in the reverse order of removal.
| CAUTION | Be sure to clump the harness to the right place. |
Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: DESCRIPTION ".
| CAUTION | When removing and installing, use shop cloths to protect parts from damage. |
Scheme 6
- Remove the front door finisher (1). Refer to " «REMOVAL AND INSTALLATION»(ref-524011-S09684262812013012500000) ".
- Press pawls and remove seat memory switch (2) from front door finisher (1).
Install in the reverse order of removal.
| CAUTION | Be sure to clump the harness to the right place. |
Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: DESCRIPTION ".
| CAUTION | When removing and installing, use shop cloths to protect parts from damage. |
Scheme 7
- Remove the seat cushion outer finisher (1). Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-524039-S06949182802013012500000) ".
- Remove the screws (A).
- Remove the power seat switch (2) from the seat cushion outer finisher (1).
Install in the reverse order of removal.
| CAUTION | Be sure to clump the harness to the right place. |
Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: DESCRIPTION ".
| CAUTION | When removing and installing, use shop cloths to protect parts from damage. |
Scheme 8
- Remove the steering column mask (1). Refer to " «REMOVAL AND INSTALLATION»(ref-524023-S04361443702013012500000) ".
- Press pawls and remove tilt & telescopic switch (2) from the steering column mask (1).
Install in the reverse order of removal.
| CAUTION | Be sure to clump the harness to the right place. |
Note. After installing the driver seat, perform additional service when removing battery negative terminal. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: DESCRIPTION ".
