Seat: Overview Infiniti FX50 II рестайлинг

Seats 6 illustrations ~1549 words

System Description

BCM can operate regardless of the ignition switch position, because battery power is supplied at all times to power seat switch.

SLIDING OPERATION

While operating the sliding switch located in power seat switch, sliding motor operates and makes the seat front and back position adjustment possible.

RECLINING OPERATION

While operating the reclining switch located in power seat switch, reclining motor operates and makes the seat back forward and backward position adjustment possible.

LIFTING OPERATION

While operating the lifting switch located in power seat switch, lifting motor operates and makes the seat cushion up and down position adjustment possible.

Scheme 64

Scheme 64: Component Parts Location
Scheme 64: Component Parts Location

Component Description

ItemFunction
BCMSupplies at all times the power received from battery to power seat switch
Power seat switchBuilt-in reclining switch, sliding switch and lifting switch, and controls the power supplied to each motor
Reclining motorWith the power supplied from power seat switch, operates forward and backward movement of seatback
Sliding motorWith the power supplied from power seat switch, operates forward and backward slide of seat
Lifting motor (front/rear)With the power supplied from power seat switch, operates up and down movement of seat cushion

Scheme 65

Scheme 65: System Diagram
Scheme 65: System Diagram
  1. Heated seat is activated by heated seat switch while ignition switch is ON, and has the function to warm seat cushion and seatback.
  2. Heated seat equips the 6-stage temperature adjustment function that adjusts temperature by operating heated seat switch to the optimal position.
  3. Heated seat equips a thermostat in heater unit to prevent heater unit overheating.

OPERATION DESCRIPTION

  1. When operating heated seat switch to any position between 1 and 6 while ignition switch is ON, indicator illuminates, heated seat control unit supplies power supply to heater unit, and warms seat cushion and seatback.
  2. Heat sensor that is built in seat cushion heater detects seat cushion heater temperature and outputs to heated seat control unit.
  3. Heated seat control unit monitors the heated seat switch position and heater sensor temperature, and interrupts power supply to heater unit when the heat sensor temperature reaches preset temperature.
  4. Heated seat control unit adjusts temperature to preset temperature by supplying or interrupting power supply to heater unit.

Scheme 66

Scheme 66: Component Parts Location
Scheme 66: Component Parts Location
ItemFunction
Heated seat switchAdjusts heated seat temperature and deactivates heated seat Equips indicator that indicates the operating condition
Seat cushion heaterWarms seat cushion Contains heater sensor that outputs seat cushion heater temperature to heated seat control unit
Seatback heaterWarms seatback
Heated seat relaySupplies power to the heated seat being controlled by ignition power supply
Heated seat control unitControls heated seat temperature and is independently placed in each seat cushion (driver seat and passenger seat)
  1. While operating the side support switch, the pump located inside side support unit operates and adjusts the air pressure in seat cushion and seatback side support.
  2. It is possible to soften the side support by allowing some air to escape or by deflating the solenoid located inside side support.
  3. It is possible to adjust seat cushion and seatback differently while inflating or deflating solenoid located in side support unit.

Scheme 67

Scheme 67: Component Parts Location
Scheme 67: Component Parts Location
ItemFunction
Side support switchWith a built-in cushion side and seat back side, and controls the power supplied to pump and to each solenoid.
Side support unitBuilt-in pump, pump relay, and solenoid, and operates when pressing ON/OFF on side support switch.
  1. Lumbar support can operate regardless of the ignition switch position because battery power is supplied to it at all times.
  2. While operating the lumbar support switch, lumbar support motor operates which allows forward and backward operation of seatback support.

Scheme 68

Scheme 68: Component Parts Location
Scheme 68: Component Parts Location
ItemFunction
Lumbar support switchControls the power supplied to lumbar support motor
Lumbar support motorWith the power supplied from lumbar support switch, operates forward and backward movement of seatback support device

Scheme 69

Scheme 69: System Diagram
Scheme 69: System Diagram
  1. The climate controlled seat system is controlled by the climate controlled seat control unit.
  2. Operation of the climate controlled switch sends heated or cooled airflow and adjusts the seat temperature.
  1. One thermal electric device (TED) unit is installed in each seat cushion and seatback. The device heats or cools, sends airflow to the seat surface, and adjusts the seat temperature.
  2. The thermal electric device (TED) is a heat exchanger that has a function to heat or cool the airflow from the climate controlled seat blower motor. (By changing the direction of the current from the power supply, the device takes or gives heat, and adjusts heat exchange process depending on voltage. NOTE: The climate controlled seat blower maintains low speed for approximately 60 seconds after turning the climate controlled seat switch. CAUTION: The thermal electric device has a dual-climate function that allows one side to operate at a high temperature and the other to operate at a low temperature simultaneously. Before starting the work, always turn OFF the switch and check that the thermal electric device is cold.
ItemFunction
Climate controlled seat relaySupplies power to the climate controlled seat control unit in accordance with the key switch position that is ON or OFF
Climate controlled seat control unitInstalled in the seat cushion backside and controls the climate controlled seat blower motor, seatback thermal electric device, and seat cushion thermal electric device in accordance with the input signal
Climate controlled seat switchInstalled in the center console and transmits signals to climate controlled seat control unit in accordance with the HEAT (heated airflow) or COOL (cooled airflow) switch operation and the temperature switch operation
Climate controlled seat blower motorInstalled in the seat cushion backside and sends the airflow to the seatback thermal electric device and seat cushion thermal electric device in accordance with the control from the climate controlled seat control unit
Seatback thermal electric deviceInstalled in the seatback backside and heats or cools the airflow from the climate controlled seat blower motor in accordance with the control from the climate controlled seat control unit
Seat cushion thermal electric deviceInstalled in the seat cushion backside and heats or cools the airflow from the climate controlled seat blower motor in accordance with the control from the climate controlled seat control unit
  1. CHECK FUSE Check that the following fuse is not blown: Signal name Fuse No. Battery power supply 63 (15 A) Is the inspection result normal? YES: GO TO 2. NO: Replace the blown fuse after repairing the affected circuit if fuse is blown.
  2. CHECK HEATED SEAT CONTROL UNIT POWER SUPPLY 1 Turn ignition switch OFF. Disconnect heated seat control unit connector. Turn ignition switch ON. Check voltage between heated seat control unit harness connector and ground. (+) (-) Voltage (V) (Approx.) Heated seat control unit Connector Terminal Driver side B439 60 Ground Battery voltage Passenger side B462 Is the inspection result normal? YES: GO TO 4 . NO: GO TO 3.
  3. CHECK HEATED SEAT CONTROL UNIT POWER SUPPLY CIRCUIT 1 Turn ignition switch OFF. Disconnect heated seat relay. Check continuity between heated seat control unit harness connector and heated seat relay terminal connector. Heated seat control unit Heated seat relay Continuity Connector Terminal Connector Terminal Driver side B439 60 M174 6 Existed Passenger side B462 Check continuity between heated seat control unit harness connector and ground. Heated seat control unit Ground Continuity Connector Terminal Driver side B439 60 Not existed Passenger side B462 Is the inspection result normal? YES: Repair or replace harness between heated seat relay and fuse holder. NO: Repair or replace harness between heated seat control unit and heated seat relay.
  4. CHECK HEATED SEAT CONTROL UNIT POWER SUPPLY 2 Check voltage between heated seat control unit harness connector and ground. (+) (-) Condition Voltage (V) (Approx.) Heated seat control unit Connector Terminal Driver side B439 66 Ground Heated seat switch ON Battery voltage OFF 0 Passenger side B462 ON Battery voltage OFF 0 Is the inspection result normal? YES: GO TO 7 . NO: GO TO 5.
  5. CHECK HEATED SEAT CONTROL UNIT POWER SUPPLY CIRCUIT 2 Turn ignition switch OFF. Disconnect heated seat switch connector. Check continuity between heated seat control unit harness connector and heated seat switch harness connector. Heated seat control unit Heated seat switch Continuity Connector Terminal Connector Terminal Driver side B439 66 M172 1 Existed Passenger side B462 M173 Check continuity between heated seat control unit harness connector and ground. Heated seat control unit Ground Continuity Connector Terminal Driver side B439 66 Not existed Passenger side B462 Is the inspection result normal? YES: GO TO 6. NO: Repair or replace harness.
  6. CHECK HEATED SEAT SWITCH Check heated seat switch. Driver side: Refer to " «DRIVER SIDE: COMPONENT INSPECTION»(ref-524039-S35965674902013012500000) ". Passenger side: Refer to " «PASSENGER SIDE: COMPONENT INSPECTION»(ref-524039-S17135429962013012500000) ". Is the inspection result normal? YES: GO TO 8 . NO: Replace heated seat switch. Refer to " «REMOVAL AND INSTALLATION»(ref-524039-S34977644012013012500000) ".
  7. CHECK HEATED SEAT CONTROL UNIT GROUND CIRCUIT Turn ignition switch OFF. Check continuity between heated seat control unit harness connector and ground. Heated seat control unit Ground Continuity Connector Terminal Driver side B439 59 Exists Passenger side B462 Is the inspection result normal? YES: INSPECTION END NO: Repair or replace harness.
  8. CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END
  1. CHECK FUSE Check that the following fuse is not blown: Signal name Fuse No. Ignition power supply 3 (10 A) Is the inspection result normal? YES: GO TO 2. NO: Replace the blown fuse after repairing the affected circuit if fuse is blown.
  2. CHECK HEATED SEAT SWITCH POWER SUPPLY Turn ignition switch OFF. Disconnect heated seat switch connector. Turn ignition switch ON. Check voltage between heated seat switch harness connector and ground. (+) (-) Voltage (V) (Approx.) Heated seat switch Connector Terminal Driver side M172 5 Ground Battery voltage Passenger side M173 Is the inspection result normal? YES: INSPECTION END NO: GO TO 3.
  3. CHECK HEATED SEAT SWITCH POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect fuse block (J/B) connector. Check continuity between heated seat switch harness connector and fuse block (J/B) harness connector. Heated seat switch Fuse block (J/B) Continuity Connector Terminal Connector Terminal Driver side M172 5 M1 2A Existed Passenger side M173 Check continuity between heated seat switch harness connector and ground. Heated seat switch Ground Continuity Connector Terminal Driver side M172 5 Not existed Passenger side M173 Is the inspection result normal? YES: GO TO 4. NO: Repair or replace harness.
  4. CHECK FUSE BLOCK (J/B) Turn ignition switch ON. Check voltage between fuse block (J/B) connector (fuse block side) and ground. (+) (-) Voltage (V) (Approx.) Fuse block (J/B) Connector Terminal M1 2A Ground Battery voltage Is the inspection result normal? YES: GO TO 5. NO: Repair or replace fuse block (J/B).
  5. CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ". : INSPECTION END

Description

Installed in the center console and transmits signals to climate controlled seat control unit in accordance with the HEAT or COOL switch operation and the temperature switch operation.

Installed in the seatback backside and heats or cools the airflow from the climate controlled seat blower motor in accordance with the control from the climate controlled seat control unit.

Measures seatback temperature.

Installed in the seat cushion backside and heats or cools the airflow from the climate controlled seat blower motor in accordance with the control from the climate controlled seat control unit.

Measures seat cushion temperature.

Sends air flow to the seat cushion and seatback.

Turns ON the indicator that indicates the operating status of climate controlled seat HEAT or COOL mode.

DRIVER SIDE: Description

Adjusts heated seat temperature and deactivates heated seat.

PASSENGER SIDE: Description

Adjusts heated seat temperature and deactivates heated seat.

Power is supplied to the heated seat using ignition power supply control.

Detects seat cushion heater temperature and outputs to heated seat control unit.

Detects seat cushion heater temperature and outputs to heated seat control unit.

Warms the seat cushion.

Warms the seat cushion.

Warms the seat back heater.

Warms the seat back heater.

Illuminates the indicator that indicates the operating status of heated seat.

Illuminates the indicator that indicates the operating status of heated seat.
