Special Service Tool
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number (Kent-Moore No.) Tool name Description KV10115801 (J38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)
Commercial Service Tool
Tool name (Kent-Moore No.) Description Power tool (-) Loosening nuts and bolts Spark plug wrench (-) Removing and installing spark plug a: 14 mm (0.55 in)
Scheme 54
Scheme 54: Commercial Service Tool
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference |
|---|
| Tires | Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear. | SERVICE DATA AND SPECIFICATIONS (SDS) |
| Wheel nuts | When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary. | |
| TIRE ROTATION | Tires should be rotated every 7, 500 miles (12, 000 km). | REAR DIFFERENTIAL GEAR OIL: R230: REFILLING |
| Tire Pressure Monitoring System (TPMS) transmitter components | Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age. | TIRE PRESSURE SENSOR |
| Wheel alignment and balance | If the vehicle should pull to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed. For additional information regarding tires, refer to "Important Tire Safety Information" (US) or "Tire Safety Information" (Canada) in the INFINITI Warranty Information Booklet. | WHEEL ALIGNMENT (2WD) WHEEL ALIGNMENT (AWD) WHEEL ALIGNMENT REAR DIFFERENTIAL GEAR OIL: R230: REFILLING |
| Windshield | Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary. | |
| Windshield wiper blades | Check for cracks or wear if they do not wipe properly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the back door, trunk lid and glass hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. | BODY MAINTENANCE |
| Lamps | Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis. | |
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item | Reference |
|---|
| Warning lamps and chimes | Make sure that all warning lamps and chimes are operating properly. | |
| Windshield wiper and washer | Check that the wipers and washer operate properly and that the wipers do not streak. | |
| Windshield defroster | Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioner. | |
| Steering wheel | Check that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) | |
| Seats | Check seat position controls such as seat adjusters, seatback recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restrains move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seatbacks. | |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly, and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. | BODY MAINTENANCE |
| Accelerator pedal | Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal. | |
| Brakes | Check that the brake does not pull the vehicle to one side when applied. | |
| Brake pedal and booster | Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep the floor mats away from the pedal. | PERIODIC MAINTENANCE BRAKE BOOSTER |
| Parking brake | Check that the pedal has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied. | PERIODIC MAINTENANCE |
| Automatic transmission "Park" mechanism | Check that the lock release button on the selector lever operates properly and smoothly. On a fairly steep hill check that the vehicle is held securely with the selector lever in the P (Park) position without applying any brakes. | |
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
| Item | Reference |
|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. | |
| Engine coolant level | Check the coolant level when the engine is cold. | PERIODIC MAINTENANCE (VQ35) PERIODIC MAINTENANCE (VK50) |
| Radiator and hoses | Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the hoses have no cracks, deformation, deterioration or loose connections. | |
| Brake fluid level | Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the reservoir. | BRAKE FLUID LEVEL AND LEAKS |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level. | BASIC INSPECTION |
| Engine drive belts | Make sure that no belt is frayed, worn, cracked or oily. | ENGINE MAINTENANCE (VQ35HR) (VQ35) ENGINE MAINTENANCE (VK50VE) (VK50) |
| Engine oil level | Check the level on the oil level gauge after parking the vehicle on a level spot and turning off the engine. | PERIODIC MAINTENANCE (VQ35) PERIODIC MAINTENANCE (VK50) |
| Power steering fluid level and lines | Check the level on the dipstick with the engine off. Check the lines for improper attachment, leaks, cracks, etc. | POWER STEERING FLUID AND LINES: INSPECTION |
| Exhaust system | Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it. | CHASSIS MAINTENANCE |
| Underbody | The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate. | |
| Fluid leaks | Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately. | |
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the checks and inspections themselves or they can have their INFINITI dealers do them.
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference |
|---|
| Lamps | Clean the head lamps on a regular basis. Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly installed securely. Also check the aim of the headlamps. | |
| Tires | Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear. | SERVICE DATA AND SPECIFICATIONS (SDS) |
| Wiper blades | Check for cracks or wear if not functioning correctly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the back door, trunk lid and glass hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. | BODY MAINTENANCE |
| Tire rotation | Tires should be rotated every 5, 000 km (3, 000 miles). | REAR DIFFERENTIAL GEAR OIL: R230: REFILLING |
| Tire Pressure Monitoring System (TPMS) Transmitter Components | Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear age. | TIRE PRESSURE SENSOR |
| Windshield | Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary. | |
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item | Reference |
|---|
| Accelerator pedal | Check the pedal for smooth operation and make sure that the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal. | |
| Brake pedal | Check the pedal for smooth operation and make sure that it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep the floor mats away from the pedal. | PERIODIC MAINTENANCE |
| Parking brake | Check that the lever or the pedal has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied. | PERIODIC MAINTENANCE |
| Warning lamps and chimes | Make sure that all warning lamps and chimes are operating properly. | |
| Windshield defogger | Check that the air comes out of the defogger outlets properly and in good quantity when operating the heater or air conditioner. | |
| Windshield wiper and washer | Check that the wipers and washer operate properly and that the wipers do not streak. | |
| Steering wheel | Check that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) | |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly, and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. | BODY MAINTENANCE |
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel.)
| Item | Reference |
|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. | |
| Engine coolant level | Check the coolant level when the engine is cold. | PERIODIC MAINTENANCE (VQ35) PERIODIC MAINTENANCE (VK50) |
| Engine drive belts | Make sure that drive belts are not frayed, worn, cracked or oily. | ENGINE MAINTENANCE (VQ35HR) (VQ35) ENGINE MAINTENANCE (VK50VE) (VK50) |
| Engine oil level | Check the level after parking the vehicle (on a level ground) and turning off the engine. | PERIODIC MAINTENANCE (VQ35) PERIODIC MAINTENANCE (VK50) |
| Brake fluid level | Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the reservoir. | BRAKE FLUID LEVEL AND LEAKS |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level. | BASIC INSPECTION |
| Fluid leaks | Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or if gasoline fumes are evident, check for cause and have it corrected immediately. | /TR> |
| Power steering fluid level and lines | Check the level when the fluid is cold, with the engine off. check the lines for proper attachment, leaks, cracks, etc.. | POWER STEERING FLUID AND LINES: INSPECTION |
Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60, 000 miles (96, 000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals.
| Schedule 1 | Follow Periodic Maintenance Schedule 1 if the driving habits frequently include one or more of the following driving conditions: Repeated short trips of less than 5 miles (8 km). Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing. Operating in hot weather in stop-and-go "rush hour" traffic. Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use. Driving in dusty conditions. Driving on rough, muddy, or salt spread roads. Towing a trailer, using a camper or a car-top carrier. | Emission Control System Maintenance | PERIODIC MAINTENANCE |
|---|
| Chassis and Body Maintenance |
| Schedule 2 | Follow Periodic Maintenance Schedule 2 if none of driving conditions shown in Schedule 1 apply to the driving habits. | Emission Control System Maintenance | FOR NORTH AMERICA: SCHEDULE 2 |
| Chassis and Body Maintenance |
EMISSION CONTROL SYSTEM
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference or Content Title |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 3.75 (6) 3 | 7.50 (12) 6 | 11.25 (18) 9 | 15 (24) 12 | 18.75 (30) 15 | 22.5 (36) 18 | 26.25 (42) 21 | 30 (48) 24 |
| DRIVE BELTS | NOTE (1) | | | | | | | | | ENGINE MAINTENANCE (VQ35HR) (VQ35) ENGINE MAINTENANCE (VK50VE) (VK50) |
| AIR CLEANER FILTER | NOTE (2) | | | | | | | | [R] | FUEL LINES (VQ35) (VK50) |
| EVAP VAPOR LINES | | | | | | | | | I (7) | (VQ35) (VK50) |
| FUEL LINES | | | | | | | | | I (7) | (VQ35) (VK50) |
| Fuel filter | NOTE (3) | | | | | | | | | |
| ENGINE COOLANT (7) | NOTE (4) | | | | | | | | | (VQ35) (VK50) |
| ENGINE OIL | | R | R | R | R | R | R | R | R | (VQ35) (VK50) |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent.) | | R | R | R | R | R | R | R | R | ENGINE OIL (VQ35) INSTALLATION (VK50) |
| Spark plugs (Iridium-tipped type) | NOTE (5) | Replace every 105, 000 miles (168, 000 km). | SPARK PLUG (VQ35) INSTALLATION (VK50) |
| Intake & exhaust valve clearance (7) | NOTE (6) | | | | | | | | | CAMSHAFT VALVE CLEARANCE (VQ35) CAMSHAFT VALVE CLEARANCE (VK50) |
| NOTE: (1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (5) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. (6) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (7) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| NOTE |
|---|
| (1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (5) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. (6) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (7) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (5) | Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. |
| (6) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (7) | Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference or Content Title |
|---|
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 33.75 (54) 27 | 37.5 (60) 30 | 41.25 (66) 33 | 45 (72) 36 | 48.75 (78) 39 | 52.5 (84) 42 | 56.25 (90) 45 | 60 (96) 48 |
| DRIVE BELTS | NOTE (1) | | | | | | | | I (7) | (VQ35) (VK50) |
| AIR CLEANER FILTER | NOTE (2) | | | | | | | | [R] | (VQ35) (VK50) |
| EVAP VAPOR LINES | | | | | | | | | I (7) | (VQ35) (VK50) |
| FUEL LINES | | | | | | | | | I (7) | (VQ35) (VK50) |
| Fuel filter | NOTE (3) | | | | | | | | | |
| ENGINE COOLANT (7) | NOTE (4) | | | | | | | | | (VQ35) (VK50) |
| ENGINE OIL | | R | R | R | R | R | R | R | R | (VQ35) (VK50) |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent.) | | R | R | R | R | R | R | R | R | ENGINE OIL (VQ35) INSTALLATION (VK50) |
| Spark plugs (Iridium-tipped type) | NOTE (5) | Replace every 105, 000 miles (168, 000 km). | SPARK PLUG (VQ35) INSTALLATION (VK50) |
| Intake & exhaust valve clearance (7) | NOTE (6) | | | | | | | | | CAMSHAFT VALVE CLEARANCE (VQ35) CAMSHAFT VALVE CLEARANCE (VK50) |
| NOTE: (1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (5) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. (6) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (7) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| NOTE |
|---|
| (1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (5) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. (6) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (7) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (5) | Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. |
| (6) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (7) | Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
CHASSIS AND BODY
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference or Content Title |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 3.75 (6) 3 | 7.50 (12) 6 | 11.25 (18) 9 | 15 (24) 12 | 18.75 (30) 15 | 22.5 (36) 18 | 26.25 (42) 21 | 30 (48) 24 |
| Brake lines & cables | | | | | I | | | | I | BRAKE FLUID LEVEL AND LEAKS |
| Brake pads & rotors | | | I | | I | | I | | I | BRAKE FLUID: CHANGING |
| Brake fluid | | | | | R | | | | R | BRAKE FLUID: CHANGING |
| Automatic transmission fluid | NOTE (1) | | | | | | | | | |
| Transfer fluid & differential gear oil | NOTE (2) | | | | I | | | | I | CHASSIS MAINTENANCE VIBRATION FRONT DIFFERENTIAL GEAR OIL: F160A: REFILLING REAR DIFFERENTIAL GEAR OIL: R200: REFILLING |
| Steering gear & linkage, axle & suspension parts | | | I | | I | | I | | I | DISC BRAKE: REAR DISC BRAKE POWER STEERING FLUID AND LINES: INSPECTION |
| Tire rotation | NOTE (3) | | | | | | | | | PERIODIC MAINTENANCE REAR DIFFERENTIAL GEAR OIL: R230: REFILLING |
| Propeller shaft and drive shaft boots (AWD models) | | | I | | I | | I | | I | TRANSFER FLUID: DRAINING REAR PROPELLER SHAFT: 3S80A-R REAR PROPELLER SHAFT: 3F80A-1VL107 REAR PROPELLER SHAFT: 3F80A-1VL107 DRIVE SHAFT: INSPECTION |
| Exhaust system | | | I | | I | | I | | I | CHASSIS MAINTENANCE |
| In-cabin microfilter | | | | | R | | | | R | PERIODIC MAINTENANCE |
| NOTE: (1) Automatic transmission fluid is maintenance-free. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30, 000 miles (48, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " . |
| NOTE |
|---|
| (1) Automatic transmission fluid is maintenance-free. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30, 000 miles (48, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " . |
| (1) | Automatic transmission fluid is maintenance-free. |
| (2) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30, 000 miles (48, 000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " . |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference or Content Title |
|---|
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 33.75 (54) 27 | 37.5 (60) 30 | 41.25 (66) 33 | 45 (72) 36 | 48.75 (78) 39 | 52.5 (84) 42 | 56.25 (90) 45 | 60 (96) 48 |
| Brake lines & cables | | | | | I | | | | I | BRAKE FLUID LEVEL AND LEAKS |
| Brake pads & rotors | | | I | | I | | I | | I | BRAKE FLUID: CHANGING |
| Brake fluid | | | | | R | | | | R | BRAKE FLUID: CHANGING |
| Automatic transmission fluid | NOTE (1) | | | | | | | | | |
| Transfer fluid & differential gear oil | NOTE (2) | | | | I | | | | I | CHASSIS MAINTENANCE VIBRATION FRONT DIFFERENTIAL GEAR OIL: F160A: REFILLING REAR DIFFERENTIAL GEAR OIL: R200: REFILLING |
| Steering gear & linkage, axle & suspension parts | | | I | | I | | I | | I | DISC BRAKE: REAR DISC BRAKE POWER STEERING FLUID AND LINES: INSPECTION |
| TIRE ROTATION | NOTE (3) | | | | | | | | | |
| Propeller shaft and drive shaft boots (AWD models) | | | I | | I | | I | | I | |
| EXHAUST SYSTEM | | | I | | I | | I | | I | PERIODIC MAINTENANCE |
| In-cabin microfilter | | | | | R | | | | R | PERIODIC MAINTENANCE |
| NOTE: (1) Automatic transmission fluid is maintenance-free. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30, 000 miles (48, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " . |
| NOTE |
|---|
| (1) Automatic transmission fluid is maintenance-free. (2) If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30, 000 miles (48, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " . |
| (1) | Automatic transmission fluid is maintenance-free. |
| (2) | If towing a trailer, using a camper or a car-top carrier, or driving on rough or muddy roads, change (not just inspect) fluid/oil at every 30, 000 miles (48, 000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " . |
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference or Content Title |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 7.5 (12) 6 | 15 (24) 12 | 22.5 (36) 18 | 30 (48) 24 | 37.5 (60) 30 | 45 (72) 36 | 52.5 (84) 42 | 60 (96) 48 |
| DRIVE BELTS | NOTE (1) | | | | | | | | I (6) | (VQ35) (VK50) |
| AIR CLEANER FILTER | | | | | [R] | | | | [R] | (VQ35) (VK50) |
| EVAP VAPOR LINES | | | | | I (6) | | | | I (6) | (VQ35) (VK50) |
| FUEL LINES | | | | | I (6) | | | | I (6) | (VQ35) (VK50) |
| Fuel filter | NOTE (2) | | | | | | | | | |
| ENGINE COOLANT (6) | NOTE (3) | | | | | | | | | (VQ35) (VK50) |
| ENGINE OIL | | R | R | R | R | R | R | R | R | (VQ35) (VK50) |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent.) | | R | R | R | R | R | R | R | R | ENGINE OIL (VQ35) INSTALLATION (VK50) |
| Spark plugs (Iridium-tipped type) | NOTE (4) | Replace every 105, 000 miles (168, 000 km). | SPARK PLUG (VQ35) INSTALLATION (VK50) |
| Intake & exhaust valve clearance (6) | NOTE (5) | | | | | | | | | CAMSHAFT VALVE CLEARANCE (VQ35) CAMSHAFT VALVE CLEARANCE (VK50) |
| NOTE: (1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (3) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (4) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| NOTE |
|---|
| (1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (3) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. (4) Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (6) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (2) | Maintenance-free item. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . |
| (3) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
| (4) | Replace spark plug when the spark plug gap exceeds 1.4 mm (0.055 in) even if within specified periodic replacement mileage. |
| (5) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (6) | Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference or Content Title |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 7.5 (12) 6 | 15 (24) 12 | 22.5 (36) 18 | 30 (48) 24 | 37.5 (60) 30 | 45 (72) 36 | 52.5 (84) 42 | 60 (96) 48 |
| Brake lines & cables | | | I | | I | | I | | I | BRAKE FLUID LEVEL AND LEAKS |
| Brake pads & rotors | | | I | | I | | I | | I | BRAKE FLUID: CHANGING |
| BRAKE FLUID | | | | | R | | | | R | |
| Automatic transmission fluid | NOTE (1) | | | | | | | | | |
| Transfer fluid & differential gear oil | | | I | | I | | I | | I | CHASSIS MAINTENANCE VIBRATION FRONT DIFFERENTIAL GEAR OIL: F160A: REFILLING REAR DIFFERENTIAL GEAR OIL: R200: REFILLING |
| Steering gear & linkage, axle & suspension parts | | | | | I | | | | I | DISC BRAKE: REAR DISC BRAKE POWER STEERING FLUID AND LINES: INSPECTION |
| TIRE ROTATION | NOTE (2) | | | | | | | | | PERIODIC MAINTENANCE REAR DIFFERENTIAL GEAR OIL: R230: REFILLING |
| Propeller shaft and drive shaft boots (AWD models) | | | I | | I | | I | | I | TRANSFER FLUID: DRAINING REAR PROPELLER SHAFT: 3S80A-R REAR PROPELLER SHAFT: 3F80A-1VL107 REAR PROPELLER SHAFT: 3F80A-1VL107 DRIVE SHAFT: INSPECTION |
| EXHAUST SYSTEM | | | | | I | | | | I | |
| In-cabin microfilter | | | R | | R | | R | | R | PERIODIC MAINTENANCE |
| NOTE: (1) Automatic transmission fluid is maintenance-free item. (2) Refer to " TIRE ROTATION " . |
| NOTE |
|---|
| (1) Automatic transmission fluid is maintenance-free item. (2) Refer to " TIRE ROTATION " . |
| (1) | Automatic transmission fluid is maintenance-free item. |
| (2) | Refer to " TIRE ROTATION " . |
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric conditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent maintenance may be required
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
| Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, E = Check and correct the engine coolant mixture ratio |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference |
| Perform either at number of kilometers (miles) or months, whichever comes first. | Km x 1, 000 (Miles x 1, 000) Months | 10 (6) 6 | 20 (12) 12 | 30 (18) 18 | 40 (24) 24 | 50 (30) 30 | 60 (36) 36 | 70 (42) 42 | 80 (48) 48 |
| Engine compartment and under vehicle |
| Intake & exhaust valve clearance | See NOTE (2) | | | | | | | | | CAMSHAFT VALVE CLEARANCE (VQ35) CAMSHAFT VALVE CLEARANCE (VK50) |
| DRIVE BELTS | See NOTE (3) | | | | I | | | | I | (VQ35) (VK50) |
| Engine oil (Use recommended oil.) (1) | | R | R | R | R | R | R | R | R | ENGINE OIL (VQ35) INSTALLATION (VK50) |
| Engine oil filter (Use Genuine NISSAN Engine oil filter or equivalent.) (1) | | R | R | R | R | R | R | R | R | ENGINE OIL (VQ35) INSTALLATION (VK50) |
| Engine coolant (Use Genuine NISSAN Engine Coolant or equivalent in its quality.) | See NOTE (4) | | | | E | | | | R | ENGINE MAINTENANCE (VQ35HR) (VQ35) DRIVE BELTS: TENSION ADJUSTMENT (VK50) |
| Cooling system | | | | | I | | | | I | PERIODIC MAINTENANCE (VQ35) RADIATOR (VQ35) RADIATOR (VQ35) PERIODIC MAINTENANCE (VK50) RADIATOR (VK50) RADIATOR (VK50) |
| FUEL LINES | | | | | I | | | | I | FUEL LINES (VQ35) FUEL LINES (VK50) |
| Air cleaner filter (Viscous paper type) (1) | | | | | R | | | | R | FUEL LINES (VQ35) FUEL LINES (VK50) |
| Fuel filter (In-tank type) | See NOTE (5) | | | | | | | | | |
| Spark plugs (Iridium-tipped type) | See NOTE (6) | Replace every 100, 000 km (60, 000 miles) | SPARK PLUG (VQ35) INSTALLATION (VK50) |
| EVAP vapor lines (With carbon canister) | | | | | I | | | | I | EVAP VAPOR LINES: INSPECTION (VQ35) INSTALLATION (VK50) |
| NOTE: (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Periodic maintenance is not required. However, if valve noise increases, check valve clearance. (3) Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (4) Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40, 000 km (24, 000 miles) or 24 months. (5) Fuel filter is maintenance-free. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (6) Replace spark plug when the plug gap exceeds 1.4 mm (0.055 in) even within specified periodic replacement mileage. |
| NOTE |
|---|
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Periodic maintenance is not required. However, if valve noise increases, check valve clearance. (3) Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (4) Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40, 000 km (24, 000 miles) or 24 months. (5) Fuel filter is maintenance-free. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . (6) Replace spark plug when the plug gap exceeds 1.4 mm (0.055 in) even within specified periodic replacement mileage. |
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | Periodic maintenance is not required. However, if valve noise increases, check valve clearance. |
| (3) | Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. |
| (4) | Use Genuine NISSAN Engine Coolant or equivalent in its quality, in order to avoid possible aluminum corrosion within the engine cooling system caused by the use of non-genuine engine coolant. After first replacement, replace every 40, 000 km (24, 000 miles) or 24 months. |
| (5) | Fuel filter is maintenance-free. For service procedures, refer to FUEL SYSTEM - FX35 & FX50 . |
| (6) | Replace spark plug when the plug gap exceeds 1.4 mm (0.055 in) even within specified periodic replacement mileage. |
| Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L=Lubricate |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference |
| Perform either at number of kilometers (miles) or months, whichever comes first. | Km x 1, 000 (Miles x 1, 000) Months | 10 (6) 6 | 20 (12) 12 | 30 (18) 18 | 40 (24) 24 | 50 (30) 30 | 60 (36) 36 | 70 (42) 42 | 80 (48) 48 |
| Underhood and under vehicle |
| Brake line & cables | | | I | | I | | I | | I | BRAKE FLUID LEVEL AND LEAKS |
| Brake fluid (For level & leaks) | | | I | | I | | I | | I | BRAKE FLUID LEVEL AND LEAKS |
| BRAKE FLUID (1) | | | | | R | | | | R | BRAKE FLUID: CHANGING |
| Automatic transmission fluid | NOTE (2) | | | | | | | | | |
| Power steering fluid & lines (For level & leaks) | | | I | | I | | I | | I | POWER STEERING FLUID AND LINES: INSPECTION |
| Exhaust system | | | | | I | | | | I | CHASSIS MAINTENANCE |
| Transfer fluid (For level & leaks) | | | I | | I | | I | | I | CHASSIS MAINTENANCE |
| Differential gear oil (For level & leaks) (1) | | | I | | I | | I | | I | VIBRATION FRONT DIFFERENTIAL GEAR OIL: F160A: REFILLING REAR DIFFERENTIAL GEAR OIL: R200: REFILLING |
| Steering gear & linkage, axle & suspension parts (1) | | | | | I | | | | I | DISC BRAKE: REAR DISC BRAKE POWER STEERING FLUID AND LINES: INSPECTION |
| Propeller shaft & drive shafts (1) | | | I | | I | | I | | I | TRANSFER FLUID: DRAINING REAR PROPELLER SHAFT: 3S80A-R REAR PROPELLER SHAFT: 3F80A-1VL107 REAR PROPELLER SHAFT: 3F80A-1VL107 DRIVE SHAFT: INSPECTION |
| Outside and inside |
| Wheel alignment (If necessary, rotate & balance wheels) | | | I | | I | | I | | I | WHEEL ALIGNMENT WHEEL ALIGNMENT REAR DIFFERENTIAL GEAR OIL: R230: REFILLING |
| Brake pads, rotors, drums & linings (1) | | | I | | I | | I | | I | BRAKE FLUID: CHANGING FRONT DISC BRAKE REAR DISC BRAKE |
| Foot brake & parking brake (For free play, stroke & operation) | | | I | | I | | I | | I | PERIODIC MAINTENANCE PERIODIC MAINTENANCE |
| Air conditioner filter (1) | | | R | | R | | R | | R | PERIODIC MAINTENANCE |
| NOTE: (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Automatic transmission fluid is maintenance-free. |
| NOTE |
|---|
| (1) Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (2) Automatic transmission fluid is maintenance-free. |
| (1) | Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". |
| (2) | Automatic transmission fluid is maintenance-free. |
The maintenance intervals shown above are for normal operating conditions. If the vehicle is mainly operated under severe driving conditions as shown below, more frequent maintenance must be performed on the following items as shown in the table
Severe driving conditions
- Driving under dusty conditions
- Driving repeatedly short distances
- Towing a trailer or caravan
- Extensive idling
- Driving in extremely adverse weather conditions or in areas where ambient temperatures are either extremely low or extremely high
- Driving in high humidity or mountainous areas
- Driving in areas using salt or other corrosive areas
- Driving on rough and/or muddy roads or in the desert
- Driving with frequent use of braking or in mountainous areas
| Maintenance operation: Inspect = Check and correct or replace as necessary. |
|---|
| Driving condition | Maintenance item | Maintenance operation | Maintenance interval | Reference |
| A | . | . | . | . | . | . | . | . | Air cleaner filter (Viscous paper type) | Replace | More frequently | FUEL LINES (VQ35) FUEL LINES (VK50) |
| A | B | C | D | . | . | . | . | . | Engine oil & engine oil filter | Replace | Every 5, 000 km (3, 000 miles) or 3 months | ENGINE OIL (VQ35) INSTALLATION (VK50) ENGINE OIL (VQ35) INSTALLATION (VK50) |
| . | . | . | . | . | F | . | . | . | Brake fluid | Replace | Every 20, 000 km (12, 000 miles) or 12 months | BRAKE FLUID: CHANGING |
| . | . | C | . | . | . | . | H | . | Differential gear oil | Replace | Every 40, 000 km (24, 000 miles) or 24 months | VIBRATION FRONT DIFFERENTIAL GEAR OIL: F160A: REFILLING REAR DIFFERENTIAL GEAR OIL: R200: REFILLING |
| . | . | . | . | . | . | G | H | . | Steering gear & linkage, axle & suspension parts | Inspect | Every 20, 000 km (12, 000 miles) or 12 months | DISC BRAKE: REAR DISC BRAKE POWER STEERING FLUID AND LINES: INSPECTION |
| . | . | . | . | . | . | G | H | . | Propeller shaft & drive shafts | Inspect | Every 10, 000 km (6, 000 miles) or 6 months | TRANSFER FLUID: DRAINING REAR PROPELLER SHAFT: 3S80A-R REAR PROPELLER SHAFT: 3F80A-1VL107 REAR PROPELLER SHAFT: 3F80A-1VL107 DRIVE SHAFT: INSPECTION |
| A | . | C | . | . | . | G | H | I | Brake pads, rotors, drums & linings | Inspect | Every 10, 000 km (6, 000 miles) or 6 months | BRAKE FLUID: CHANGING FRONT DISC BRAKE REAR DISC BRAKE |
| A | . | . | . | . | . | . | . | . | Air conditioner filter | Replace | More frequently | PERIODIC MAINTENANCE |
FOR NORTH AMERICA: Engine Oil Recommendation
NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.
Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.
Scheme 55
Scheme 55: FOR NORTH AMERICA: Engine Oil Recommendation
FOR NORTH AMERICA: Anti-Freeze Coolant Mixture Ratio
The engine cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide year-round anti-freeze and coolant protection. The antifreeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary.
| WARNING | Never remove the radiator or coolant reservoir cap when the engine is hot. Wait until the engine and radiator cool down. Serious burns could be caused by high pressure fluid escaping from the radiator. The radiator is equipped with a pressure type radiator cap. To prevent engine damage, use only a genuine NISSAN radiator cap. |
| CAUTION | When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to -34°F (-37°C). If additional freeze protection is needed due to weather where you operate your vehicle, add Genuine NISSAN Long Life Antifreeze/Coolant (blue) concentrate following the directions on the container. If an equivalent coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) is used, follow the coolant manufacturer's instructions to maintain minimum antifreeze protection to -34°F (-37°C). The use of other types of coolant solutions other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent may damage the engine cooling system. The life expectancy of the factory-fill coolant is 105, 000 miles (168, 000 km) or 7 years. Mixing any other type of coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue), including Genuine NISSAN Long Life Antifreeze/Coolant (green), or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. Refer to the Nissan Service and Maintenance Guide for more details. |
GASOLINE ENGINE
- 10W-30 is preferable. If 10W-30 is not available, select the viscosity, from the chart, that is suitable for the outside temperature range.
Scheme 56
DIFFERENTIAL GEAR OIL
- 80W-90 for the front differential gear is preferable.
Scheme 57
FOR MEXICO: Engine Coolant Mixture Ratio
The engine cooling system is filled at the factory with a high-quality, year-round and extended life engine coolant. The high quality engine coolant contains the specific solutions effective for the anti-corrosion and the anti-freeze function. Therefore, additional cooling system additives are not necessary.
| CAUTION | When adding or replacing coolant, be sure to use only a Genuine NISSAN Engine Coolant or equivalent in its quality with the proper mixture ratio. See the examples shown in the figure. The use of other types of engine coolant may damage the engine cooling system. |
- When checking the engine coolant mixture ratio by the coolant hydrometer, use the chart below to correct your hydrometer reading (specific gravity) according to coolant temperature
Scheme 58
| Engine coolant mixture ratio | Coolant temperature °C (°F) |
|---|
| 15 (59) | 25 (77) | 35 (95) | 45 (113) |
| 30% | 1.046 - 1.050 | 1.042 - 1.046 | 1.038 - 1.042 | 1.033 - 1.038 |
| 50% | 1.076 - 1.080 | 1.070 - 1.076 | 1.065 - 1.071 | 1.059 - 1.065 |
MIXED COOLANT SPECIFIC GRAVITY UNIT REFERENCE CHART
| WARNING | Never remove the radiator cap when the engine is hot. Serious burns could be caused by high pressure fluid escaping from the radiator. Wait until the engine and radiator cool down. |
Scheme 59
Scheme 59: DRIVE BELT: Exploded View
DRIVE BELT: Checking
| WARNING | Be sure to perform this step when engine is stopped. |
- Check that the indicator (C) (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A). NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (B) in the figure.
- Visually check entire drive belt for wear, damage or cracks.
- If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.
DRIVE BELTS: Checking
| WARNING | Be sure to perform the these steps when engine is stopped. |
- Remove air duct (inlet) when inspecting alternator, water pump and A/C compressor belt.
- Remove engine undercover with power tool when inspecting power steering oil pump belt.
- Check that the indicator (A) (notch on fixed side) of each auto-tensioner is within the possible use range (B). NOTE: Check the each auto-tensioners indication when the engine is cold. When new drive belts is installed, the indicator (notch on fixed side) should be within the range (C) in the figure.
- Visually check all drive belts for wear, damage or cracks.
- If the indicator (notch on fixed side) is out of the possible use range or drive belts are damaged, replace drive belts.
OIL LEAKAGE
Make sure that oil is not leaking from final drive assembly or around it.
OIL LEVEL
- Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
- Set a gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-524017-S07333604972013012500000) ".
| CAUTION | Never reuse gasket. |
Scheme 60
- Make sure that oil is not leaking from final drive assembly or around it.
- Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
- Set a gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-524046-S36948175582013012500000) " (2WD), " «AWD: EXPLODED VIEW»(ref-524046-S19539603542013012500000) " (AWD).
| CAUTION | Never reuse gasket. |
Scheme 61
Make sure that differential gear oil is not leaking from the rear final drive assembly or around it.
- Check the differential gear oil level from the filler plug hole as shown in the figure. CAUTION: Never start engine while checking differential gear oil level.
- Install the filler plug with a new gasket on it to the rear final drive assembly. Tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-524048-S10128326542013012500000) ".
| CAUTION | Never reuse gasket. |
Scheme 62
BALANCING WHEELS (BONDING WEIGHT TYPE)
Preparation Before Adjustment
Using releasing agent, remove double-faced adhesive tape from the road wheel.
| CAUTION | Be careful not to scratch the road wheel during removal. After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road wheel. |
- The details of the adjustment procedure are different for each model of wheel balancer. Therefore, refer to each instruction manual.
- If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select and adjust a drive-in weight mode suitable for road wheels.
- Set road wheel on tire balance machine using the center hole as a guide. Start the tire balance machine.
- When inner and outer unbalance values are shown on the tire balance machine indicator, multiply outer unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install to the designated outer position of, or at the designated angle in relation to the road wheel.
| CAUTION | Never install the inner balance weight before installing the outer balance weight. Before installing the balance weight, always to clean the mating surface of the road wheel. |
Scheme 63
Scheme 64
- Indicated unbalance value x 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz) x 5/3 = 38.33 g (1.35 oz) => 37.5 g (1.32 oz) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 36.2 => 35 g (1.23 oz) 36.3 => 37.5 g (1.32 oz)
- Installed balance weight in the position. When installing balance weight (1) to road wheels, set it into the grooved area (A) on the inner wall of the road wheel as shown in the figure so that the balance weight center (B) is aligned with the tire balance machine indication position (angle) (C). CAUTION: Always use genuine NISSAN adhesion balance weights. Balance weights are non-reusable; always replace with new ones. Never install three or more sheets of balance weight.
- If calculated balance weight value exceeds 50 g (1.76 oz), install two balance weight sheets in line with each other as shown in the figure. CAUTION: Never install one balance weight sheet on top of another.
- Start the tire balance machine again.
- Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position (angle). CAUTION: Never install three or more balance weight.
- Start the tire balance machine. Check that inner and outer residual unbalance values is within the allowable unbalance value.
Scheme 65
| CAUTION | If either residual unbalance value exceeds limit, repeat installation procedures. |
Allowable unbalance value
Dynamic (At flange): Refer to " ROAD WHEEL ".
Static (At flange): Refer to " ROAD WHEEL ".
TIRE ROTATION
- Follow the maintenance schedule for tire rotation service intervals. Refer to " «FOR NORTH AMERICA: EXPLANATION OF GENERAL MAINTENANCE»(ref-524008-S32247168272013012500000) " (For North America), " «FOR MEXICO: GENERAL MAINTENANCE»(ref-524008-S02749089662013012500000) " (For Mexico).
- When installing the wheel, tighten wheel nuts to the specified torque. Refer to " «EXPLODED VIEW»(ref-524050-S06101991112013012500000) ". CAUTION: Never include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria for preventing strain of disc rotor. Use NISSAN genuine wheel nuts for aluminum wheels.
- Perform the ID registration, after tire rotation. Refer to " «WORK PROCEDURE»(ref-524050-S39470825892013012500000) ".
Scheme 66
DISC ROTOR
Check condition, wear, and damage.
CALIPER
Scheme 67
BRAKE PAD
- Check for wear or damage.
Scheme 68
2 PISTON TYPE
| Item | Limit |
|---|
| Brake pad | Wear thickness | 2.0 (0.079) |
| Disc rotor | Wear thickness | 32.0 (1.260) |
| Thickness variation (measured at 8 positions) | 0.015 (0.0006) |
| Runout (with it attached to the vehicle) | 0.035 (0.0014) |
FRONT DISC BRAKE ITEM SPECIFICATIONS CHART (2 PISTON TYPE)
4 PISTON TYPE
| Item | Limit |
|---|
| Brake pad | Wear thickness | 2.0 (0.079) |
| Disc rotor | Wear thickness | 30.0 (1.181) |
| Thickness variation (measured at 8 positions) | 0.015 (0.0006) |
| Runout (with it attached to the vehicle) | 0.035 (0.0014) |
FRONT DISC BRAKE ITEM SPECIFICATIONS CHART (4 PISTON TYPE)
1 PISTON TYPE
| Item | Limit |
|---|
| Brake pad | Wear thickness | 2.0 (0.079) |
| Disc rotor | Wear thickness | 14.0 (0.551) |
| Thickness variation (measured at 8 positions) | 0.015 (0.0006) |
| Runout (with it attached to the vehicle) | 0.055 (0.0022) |
REAR DISC BRAKE ITEM SPECIFICATIONS CHART (1 PISTON TYPE)
| Item | Limit |
|---|
| Brake pad | Wear thickness | 2.0 (0.079) |
| Disc rotor | Wear thickness | 18.0 (0.709) |
| Thickness variation (measured at 8 positions) | 0.015 (0.0006) |
| Runout (with it attached to the vehicle) | 0.055 (0.0022) |
REAR DISC BRAKE ITEM SPECIFICATIONS CHART (2 PISTON TYPE)
STEERING GEAR
- Check gear housing and boots for looseness, damage and grease leakage.
- Check connection with steering column for looseness.
Scheme 69
STEERING LINKAGE
Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.
DRIVE BELT
| Tension of drive belt | Belt tension is not necessary, as it is automatically adjusted by drive belt auto-tensioner. |
| Tension of drive belts | Belt tension is not necessary, as it is automatically adjusted by drive belt auto-tensioner. |
SPARK PLUG
| Make | DENSO |
|---|
| Standard type | FXE22HR11 |
| Gap | Standard | 1.1 (0.043) |
| Limit | 1.4 (0.055) |
SPARK PLUG SPECIFICATION CHART (VQ35HR)
| Make | DENSO |
|---|
| Standard type | FXE22HR11 |
| Gap | Standard | 1.1 (0.043) |
| Limit | 1.4 (0.055) |
SPARK PLUG SPECIFICATION CHART (VK50VE)
ALUMINUM WHEEL (CONVENTIONAL)
| Item | Limit |
|---|
| Radial runout | Lateral deflection | Less than 0.3 mm (0.012 in) |
| Vertical deflection |
| Allowable unbalance | Dynamic (At flange) | Less than 5 g (0.17 oz) (one side) |
| Static (At flange) | Less than 10 g (0.35 oz) |
STEEL WHEEL (FOR EMERGENCY USE)
| Item | Limit |
|---|
| Radial runout | Lateral deflection | Less than 1.5 mm (0.059 in) |
| Vertical deflection |
